4.3 The saddle (bike seat)

Putting the saddle (bike seat) on

4.3.1
1. Fold the quick release (A) outward.
2. Place the saddle (bike seat) with the saddle
pin (B) in the frame (C).
3. Slide the saddle (B) to the correct height.
See 5.1.2. Height and position of the saddle
(bike seat).
4. Fold the quick release (A) inward.

Remove the saddle (bike seat)

4.3.2
1. Pull the quick release (A) outward.
2. Remove the saddle and the saddle pin (B) from
the frame (C).
3. Fold the quick release (A) inward.

4.4 Place the Alinker into the car

1. Fold the Alinker.
2. Remove the wheels.
3. Remove the saddle (bike seat), if necessary.
4. Place the frame,wheels and saddle (bike seat)
in the car.
Transport the Alinker
23
B
C
A
B
A
x
