4.

Transport the Alinker

The Alinker is foldable. The wheels can be clicked off the Alinker and the saddle (bike seat) can be
removed. This makes the Alinker easy to transport.

4.1 The front wheels

Put the front wheels on

4.1.1
1. Hold the wheel (A) with one hand at the hub.
2. Place your fingers around the spokes. Press and
hold the black button (B) with your thumb.
3. Slide the wheel unto the frame (C).
4. Release the black button (B).
5. Pull the wheel outward to be sure it has
"clicked" in. It should feel secure.
6. Double check to see if the wheel is securely
fastened.
Contact your dealer or service@thealinker.com
• If you cannot properly fasten the wheel, the dealer can adjust the mechanism.
Transport the Alinker
When the ball (D) is visible and
the black button (B) does not
stick out, the wheel is correctly
fastened.
C
20
B
D
A
