2.
Description
2.1 Overview of the Alinker
The Alinker consists of:
A. Handlebar
B. Handlebar riser
C. Folding frame
D. Stand
E. Two large front wheels
F. Quick release hub
G. Small rear wheel
2.2 Delivery
The Alinker is delivered nearly completely assembled. Only wheels, saddle and steering needs to be
put in place. (Follow the assembly instructions).
J
I
H
G
F
E
Description
M
N
L
K
H. Rear brake
I. Quick release for saddle
J. Saddle
K. Saddle pin
L. Hinge
M. Handbrake
N. Parking brake catch
15
A
B
C
D
