Adjust the saddle (bike seat) to the correct height.

3.1.3
1. Pull the quick release (A) outward.
2. Raise or lower the saddle (bike seat) (B) to the
required height.
3. Fold the quick release (A) inward to lock the
saddle (bike seat) in place.

3.2 Adjust or change out the handlebar if needed

Select handlebar and a handlebar stem riser for your comfort and need

3.2.1
The default handlebar for the Alinker is the butterfly handlebar.
Contact your dealer or local bike shop if you want a different handlebar configuration.
• Virtually every type of handlebar is suitable for the Alinker.
• Choose the handlebar most comfortable for you.
Choose the correct handlebar stem riser for the handlebar. Most handlebar stem risers can be
removed for stowage or travel.

Position of the handlebars

3.2.2
The handlebars are in the correct position when:
• Your arms are slightly bent when you are sitting up straight,
• Your hands can easily reach the handbrake,
• When walking, using the handbrake and steering feels easy.
Contact your dealer or local bike shop
The correct adjustment of the handlebar may vary depending on the surrounding
area and your speed. Your dealer or service@thealinker.com can offer advice. The
dealer can make modifications to help you experience what happens when you
lower the saddle and/or tilt the handlebar.

Adjust the handlebar to the correct position

3.2.3
The handlebar can be adjusted at two places:
1. The handlebars themselves can be raised or lowered using a 4mm allen key.
2. The handlebar stem riser can be raised or lowered using a 5mm allen key.
Adjust the Alinker
Caution! The saddle (bike seat)
can be raised a maximum of 12
cm or 4.75 " (X) from the lowest
position. The higher the saddle,
the higher your center of gravity
and the less stable you are on the
Alinker. For stability it is better
to use a lower saddle on a larger
frame than a higher saddle on a
smaller frame.
A
18
B
x
