Summary of Contents for Snapper 1662-0
-
Page 1: Pressure Washer
3500PSI Pressure Washer Owner’s Manual Questions? Help is just a moment away! Contact the Local Snapper Service Center Web: www.snapper.com or www.briggsandstratton.com Model No. 1662-0 (3500 PSI Pressure Washer) Manual No. 190667GS Revision 1 (01/17/2002) -
Page 2: Table Of Contents
Safety Rules........2-3 Know Your Pressure Washer ..... . 4 Assembly. - Page 3 • Keep spray nozzle between 8 to 24 inches away from cleaning surface. • Be extremely careful if you must use the pressure washer from a ladder, scaffolding or any other relatively unstable location. • The cleaning area should have adequate slopes and drainage to reduce the possibility of a fall due to slippery surfaces.
-
Page 4: Know Your Pressure Washer
KNOW YOUR PRESSURE WASHER Read this owner’s manual and safety rules before operating your high pressure washer. Compare the illustrations with your high pressure washer to familiarize yourself with the locations of various controls and adjustments. Save this manual for future reference. -
Page 5: Carton Contents
WASHER FOR USE If you have any problems with the assembly of your pressure washer or if parts are missing or damaged, contact the local Snapper service center. To prepare your pressure washer for operation, you will need to perform these tasks: •... -
Page 6: Add Engine Oil
Remove shipping cap and install oil dipstick here. Pump Oil Dipstick Snapper 3500 PSI Pressure Washer • Install the oil dipstick. NOTE: The pump is pre-lubricated and sealed, requiring no additional lubrication for the life of the pump. Add Engine Oil... -
Page 7: Assembly
PRESSURE WASHER IF THE SCREEN IS DAMAGED. Figure 7 — Connect the Garden Hose to Water Inlet Snapper 3500 PSI Pressure Washer • Run water through your garden hose for 30 seconds to clean out any debris. Turn off water. -
Page 8: Operation
HOW TO USE YOUR PRESSURE WASHER If you have any problems operating your pressure washer, please contact the local Snapper service center. How to Start Your Engine The best way to start your pressure washer for the first time is to follow these instructions step–by–step. This starting information also applies if have let the pressure washer sit idle for at least a day. -
Page 9: How To Stop Your Pressure Washer
Low Pressure Use to apply chemical Black Snapper 3500 PSI Pressure Washer How to Use the Nozzles CAUTION! locking the safety latch on the trigger. The quick–connect on the nozzle extension allows you to switch between five different nozzles. The nozzles vary the spray pattern as shown below (Figure 14). -
Page 10: Automatic Cool Down System
The high pressure spray could cause you to fall if you are too close to the cleaning surface. Snapper 3500 PSI Pressure Washer After you have applied detergent, scour the surface and rinse it clean as follows: • Apply safety latch to spray gun. -
Page 11: Product Specifications
• Check detergent siphoning tube and filter for damage. • Check spray gun, nozzle extension, and nozzles for leaks. • Rinse out garden hose to flush out debris. Snapper 3500 PSI Pressure Washer PRESSURE WASHER MAINTENANCE Check and Clean Inlet Screen Examine the screen on the water inlet. -
Page 12: Nozzle Maintenance
Purge Pump of Air and Contaminants To remove air from the pump, follow these steps: • Set up the pressure washer as described in “Preparing Pressure Washer For Use”. Connect the water supply and turn water on. • Pull the trigger on the spray gun and hold. -
Page 13: Engine Maintenance
Reconnect the nozzle extension to the spray gun. Reconnect the water supply, turn on the water, and start the engine. Test the pressure washer by operating with each of the Quick Connect nozzles. O–Ring Maintenance Through the normal operation of your pressure washer, o–rings, which keep the connections of the hoses and spray... - Page 14 Snapper 3500 PSI Pressure Washer NOTES...
-
Page 15: Troubleshooting
Engine will not start; or starts and runs rough. Engine shuts down during operation. Engine lacks power. Engine “hunts” or falters. Snapper 3500 PSI Pressure Washer Cause Low pressure nozzle installed. Water inlet is blocked. Inadequate water supply. Inlet hose is kinked or leaking. -
Page 16: Exploded View - Unit
Snapper 3500 PSI Pressure Washer EXPLODED VIEW — UNIT... -
Page 17: Parts List - Unit
23 190667GS MANUAL, Owners 24 B3858GS ASSY., Wand Ext. with QD 25 MS6321 MANUAL, B&S, Vanguard 26 BB3061BGS OIL BOTTLE Snapper 3500 PSI Pressure Washer Item Part # 27 188287GS 28 B5830GS 29 188194GS 30 71693GS 31 27007GS 33 185805GS... - Page 18 Snapper 3500 PSI Pressure Washer EXPLODED VIEW — PUMP...
- Page 19 Screw 186385GS Plug 134B2327GS O-Ring 116B2126GS O-Ring 142B2126GS Screw 150B2126GS Flange 139B1410GS O-Ring 138B1410GS Seal 137B1410GS Bearing 152B2126GS Grub Screw 186386GS Shaft 136B2327GS Plug 139B2327GS Pump Head 159B2327GS Washer 140B2327GS Screw B1554GS Thermal Relief Valve Snapper 3500 PSI Pressure Washer...
- Page 20 Snapper 3500 PSI Pressure Washer EXPLODED VIEW — UNLOADER...
- Page 21 Suction Fitting 240B2327GS O-Ring 239B2327GS Washer 238B2327GS Bypass Fitting 237B2327GS Washer 236B2327GS Inlet Bolt 248B2327GS Plug 155B2327GS Screw 246B2327GS 245B2327GS Knob 243B2327GS Housing 244B2327GS 242B2327GS Spring Guide 95320GS Garden Hose Connector 95458GS Quick Connect Connector Snapper 3500 PSI Pressure Washer...
-
Page 22: Notes
Snapper 3500 PSI Pressure Washer NOTES... - Page 23 Snapper 3500 PSI Pressure Washer NOTES...
-
Page 24: Limited Warranty
SNAPPER™ OWNER WARRANTY POLICY Effective October 1, 2001 “This Snapper™ product is distributed under license by Generac Portable Products, LLC, a subsidiary of Briggs & Stratton. Generac Portable Products LLC will repair or replace, free of charge, any part, or parts of the equipment that are defective in material or workmanship or both.
