Snapper NP216012 Parts Manual page 7

Handles & Controls
Item Part No Qty
20A 7051698
21 7010937
22 7090895
23 7012114
24 7090595
25 7090238
26 7090799
27 7091601
28 7091606
28 7091606
29 7023813
30 7091740 4
31 7035744
32 7079577
33 7090053
34 7091576
35 7090505
36 7014343 4
37 7023792
38 7091020
39 7024211
7029782
7029785
40 7026141
41 7075634
7022460
42 7024087
7029783
43 7023153
44 7090391
45 7090545
46 7022779
47 7029217
47A 7029233
48 7029217
48A 7029189
49 7029217
49A 7029190
Footnotes:
Note 1: RP215012T2, RP216012, NP216012, EP216012, P216012, P216012E, P216012TV, P216512BV, FRP216012TV,
EFRP216012TV, FRP216012, FRP216016, EFRP216512TV, EFRP216516TV & EFRP216516BV.
Note 2: N215012, 215012, 216015, NR215012, 8215012.
21" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16
Description
ASSEMBLY, Transfer Rod
CLIP, Transfer Rod
TEE-NUT, 5/16-18
BUSHING, Differential
BOLT, 5/16-18 x 3/4" Flange Lock, Grade 5
SCREW, 5/16-24 x 1" Hex Cap, Grade 5
BOLT, 5/16-18 x 5/8" Carriage, Grade 5
NUT, 5/16-18 Hex Flange Lock, Grade 5
NUT, 5/16-24 Center Lock, Grade 5
NUT, 5/16-24 Center Lock, Grade 5
CLIP, Cable/Wiring
SCREW, 5/16-18 x 1-7/8 Curved Head, Grade 2
T-KNOB, 5/16-18
SCREW, 1/4-20 x 1-1/2 Hex Cap, Grade 5
WASHER, 1/4 Internal Tooth Lock
NUT, 1/4-20 Hex, Grade 5 or B
SCREW, 1/4-20 x 2" Hex Cap, Grade 5
BUSHING
PIN, 1/4" X 1-1/2"
PUSH-NUT, 1/4"
DECAL, Blade Control (L.H. Side)
DECAL, Operator's Presence Control
DECAL, Handle International Warning
GUIDE, Rope
GRIP, Foam
GRIP, Foam
DECAL, Speed Select
DECAL, Speed Select
CLAMP, Casing
WASHER, 5/16 Internal Tooth Lock
SCREW, 5/16-24 x 1-1/2" Machine, Grade 5
GUIDE, Rope
ASSEMBLY, Speed Control Lever
ASSEMBLY, Speed Control Lever
ROD, Upper
ROD, Upper
ROD, Intermediate
ROD, Intermediate
7
Note
European models
Self-Propelled Models
Self-Propelled Models
Self-Propelled Models
Was 91026 (Used on All Models)
Was 91070 (Used on All Models)
Was 91074 (Used on All Models)
Was 91074 (Used on All Models)
Was 91189 (Used on All Models)
Was 91023 (Used on All Models)
Was 91100 (Used on All Models)
Used on All (Except European)
Used on European Models
Used on European Models
Was 73115, Note #1
Used on P216012E &
P216512BV
Except European
European Models
Used on Grass Bag Models
(Includes Items 48 thru 51),
Note #1
Includes Items 48A, 49A, 50A &
51
Was 29153, Note #1
NRP215012, RP215012
Was 29154, Note #1
NRP215012, RP215012
Manual No. 7006059
TP 400-5137-7-WB-N
