Snapper P216012E Safety Instructions & Operator's Manual

Snapper P216012E Safety Instructions & Operator's Manual

21" steel deck walk mowers series 12 electric start
Hide thumbs Also See for P216012E:
Table of Contents

Advertisement

Quick Links

MODEL DESIGNATION
SELF-PROPELLED
CUTTING WIDTH
Thank you for buying a SNAPPER Product! Before operating your Walk Behind, read this manual carefully and pay
particular attention to the "IMPORTANT SAFETY INSTRUCTIONS" on Pages 2 & 3. Remember that all power
equipment can be dangerous if used improperly. Also keep in mind that SAFETY requires careful use in accordance
with the operating instructions and common sense.
COPYRIGHT © 1999
SNAPPER INC.
ALL RIGHTS RESERVED
Safety Instructions & Operator's Manual for
MODEL NUMBER EXPLANATION
N
F
R
N – California Model
R – Recycling Mower
21 – 21" Cutting Width
60 – 6.0 HP (Engine Horse Power)
12 - Series Designation
21" STEEL DECK
WALK MOWERS

ELECTRIC START

P
21
60
F – Flange Deck
P – Self-Propelled Mower
E -Electric Start
SERIES 12
MODELS
PROPELLED MODELS
P216012E
FRP216012E
NFRP216012E
12
E
ENGINE OPTIONS
SERIES DESIGNATION
ENGINE HORSE POWER
MANUAL No. 3-5769 (REV. 1, 9/2/99)
