Electric Start - Snapper NP216012 Parts Manual

Electric Start

Item Part No Qty
7067012
1 7067012
2 7015488
3 7043977 2
4 7090932 2
7058120
5 7011138
6 7023506
7 7071972
8 7029080
9 7012685
10 7028765
11 7016132
12 7090053 2
13 7090095 2
14 7029081
15 7032906
16 7036132
17 7090731 2
18 7091601 3
19 7012652
20 7061188
7018977
21 7090799
22 7011791
23 7091025 2
Footnotes:
21" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16
Description
KIT, Battery
BATTERY, 12 Volt, 35 CCA
HARNESS, Battery
SCREW, #10-24 x 1/2" Hex Head Cap
NUT, #10-24 Square
ASSEMBLY, Switch/Brkt.
KEY, (Set of Two)
ASSEMBLY, Seal & Face Nut
BRACKET, Ignition Switch
COVER, Switch
NUT, 3/4-20 Hex Lock
SWITCH, Ignition-(spring loaded ON/OFF 2 prong)
SPACER
WASHER, 1/4 Internal Tooth Lock
NUT, 1/4-28 Hex Grade 5 or B
HARNESS, Wiring
BRACKET, Battery
COVER, Battery
BOLT, 5/16-18 x 1/2" Short Neck. Carr., Gr. 5
NUT, 5/16-18 Hex Flange Lock Grade 5
CLIP, Wiring
CHARGER, Battery (120 Volt - 60 Hertz)
CHARGER, Battery (230 Volt - 50 Hertz)
BOLT, 5/16-18 x 5/8" Short Neck. Carriage, Gr. 5
RETAINER, 5/16 Bolt
SCREW, 1/4-28 x 1-3/8" Hex Hd. Cap, Gr. 5
49
Note
(Includes Items 1 Thru 4)
Was 19763
(Incl. Items 5 Thru 10)
Was 91023
Was 91024
Was 90585
Was 18834
Was 91026
Manual No. 7006059
TP 400-5137-7-WB-N
