S P E C I F I C AT I O N S C O N T I N U E D

DIMENSIONAL DRAWINGS

FIG. 2-1 CHA™ SENSOR
A
B
E
F
TABLE 2-2 FLANGE SIZE AND CLASS (SL)
150
"
INCHES MM
2
8.40 213
3
8.60 218
4 8.60 218
TABLE 2-3 DIMENSIONS
INCHES MM
A 1.25 32
3.5 90
B
7 .1 180
C
4.6 117
D
.47 12
E
1 25
F
CHAMANUAL 0917
SL
Seal Housing
Shaft Length ± .5"
Sensor Profile
300
INCHES MM
8.50 216
8.75 222
8.90 226
Shaft Lengths are available in .5" (12.7
mm) increments.
Standard sizes are 24", 30", 36", 48",
and 60". (609.6 mm, 762 mm, 914.4
mm, 1219 mm, 1524 mm)
600
INCHES MM
8.90 226
9.15 232
9.40 240
5
C
D
¾" FNPT
900
INCHES MM
9.40 240
9.40 240
9.65 245
