- Page 1 REV.2011.7.30 90/ 95 SERIES Advanced Remote Starters & Vehicle Security Systems AUTOMATIC AND MANUAL TRANSMISSION MODELS* *MUST USE M SERIES REMOTE STARTER! WARING: NEVER USE AN AUTOMATIC TRANSMISSION STARTER IN A MANUAL TRANSMISSION VEHICLE...
-
Page 2: Table Of Contents
90 & 95 SERIES IMPORTANT NOTES...................PAGE 3 QUICK VIEW OPERATIONS LCD 2WAY............PAGES 4-8 LOCK UNLOCK TRUNK START STOP ETC. QUICK VIEW OPERATIONS 1WAY REMOTE............PAGES 8-9 LOCK UNLOCK TRUNK START STOP ETC. QUICK VIEW OPERATIONS LED 2WAY............PAGES 10-11 LOCK UNLOCK TRUNK START STOP ETC. -
Page 3: Important Notes
90 & 95 SERIES IMPORTANT NOTES BEFORE YOU START... -
Page 4: Quick View Operations Lcd 2Way
90 & 95 SERIES PAGE 4 LCD 2 WAY REMOTE Basic Remote Functions THE LCD REMOTE DISPLAYS THE CURRENT STATUS OF YOUR SYSTEM USING BOTH ICONS AND TEXT ON ITS UNIQUE LCD DISPLAY. Basic Remote Functions LOCK/ ARM ALARM UNLOCK/ DISARM ALARM 1 2 3 ON OFF REMOTE START/ STOP UNLOCK... -
Page 5: Trunk
90 & 95 SERIES PAGE 5 2 WAY REMOTE OPERATIONS DISPLAY BUTTON PRESS AUDIBLE FUNCTION LOCK 1 BEEP LOCK - PRESS & RELEASE LOCK THE DOORS & ARM THE ALARM* / 1 BEEP *ALARM MODELS ONLY. PANIC LOCK - PRESS & HOLD SERIES OF ACTIVATES THE PANIC MODE FEATURE. - Page 6 90 & 95 SERIES PAGE 6 2 WAY REMOTE OPERATIONS DISPLAY BUTTON PRESS AUDIBLE FUNCTION AUX 1 1 BEEP / AUXILIARY 1 OUTPUT. ACTIVATES AS LONG AS THE BUTTONS PRESS AND HOLD TOGETHER 3 BEEPS ARE HELD (5 SECONDS MAX). AUX 2 1 BEEP / AUXILIARY 2 OUTPUT.
-
Page 7: Start
90 & 95 SERIES PAGE 7 2 WAY REMOTE OPERATIONS DISPLAY BUTTON PRESS AUDIBLE FUNCTION KEY- PRESS AND HOLD FOR 1 BEEP ACTIVATES THE REMOTE CAR STARTER FUNCTION. START PAUSE 3 SECONDS TILL REMOTE BEEPS THE DEFAULT RUNTIME IS 15 MINUTES. TONE THEN RELEASE MANUAL TRANSMISSION- RESERVATION MODE MUST BE SET TO REMOTE START THE VEHICLE... -
Page 8: Quick View Operations 1Way Remote
90 & 95 SERIES PAGE 8 1 WAY REMOTE OPERATIONS HONKS/ DISPLAY BUTTON PRESS FUNCTION FLASH 1 SECOND LOCK DOORS/ ARM ALARM* 3 SECONDS ACTIVATE PANIC MODE PRESS 2 TIMES ACTIVATE CONSTANT LOCK MODE LOCK 1 SECOND UNLOCK DOORS/ DISARM ALARM* PRESS 2ND TIME ACTIVATES DRIVER’S DOOR WITHIN 3 SECONDS... - Page 9 90 & 95 SERIES PAGE 9 1 WAY REMOTE OPERATIONS HONKS/ DISPLAY BUTTON PRESS FUNCTION FLASH PRESS TOGETHER ACTIVATES SILENT LOCK WITHOUT THEN RELEASE HONKS PRESS TOGETHER ACTIVATES SILENT UNLOCK THEN RELEASE WITHOUT HONKS PRESS TOGETHER ACTIVATES THE AUXILIARY 1 FOR 3 SECONDS OUTPUT FOR 5 SECONDS.
-
Page 10: Quick View Operations Led 2Way
90 & 95 SERIES PAGE 10 LED 2WAY REMOTE’S LED & DISPLAY BUTTON PRESS FUNCTION BEEPS 1 SECOND LOCK DOORS/ ARM ALARM* 3 SECONDS ACTIVATE PANIC MODE PRESS 2 TIMES ACTIVATE CONSTANT LOCK MODE LOCK 1 SECOND UNLOCK DOORS/ DISARM ALARM* PRESS 2ND TIME ACTIVATES DRIVER’S DOOR WITHIN 3 SECONDS... - Page 11 90 & 95 SERIES PAGE 11 LED 2WAY REMOTE’S LED & DISPLAY BUTTON PRESS FUNCTION BEEPS PRESS TOGETHER ACTIVATES SILENT LOCK WITHOUT THEN RELEASE HONKS PRESS TOGETHER ACTIVATES SILENT UNLOCK THEN RELEASE WITHOUT HONKS PRESS TOGETHER ACTIVATES THE AUXILIARY 1 FOR 3 SECONDS OUTPUT FOR 5 SECONDS.
- Page 12 90 & 95 SERIES PAGE 12 PRESS & HOLD 1. Press and Hold the Start button for 3 seconds. 2. The park lights will flash and the siren**/ horn will chirp once. 3. The vehicle will remote start. The park lights will stay on during run time*** See diagnostic chart if your vehicle fails to start.
- Page 13 90 & 95 SERIES PAGE 13 PRESS & HOLD PRESS & HOLD PRESS & RELEASE PRESS & HOLD *Press # twice on manual transmission models.
-
Page 14: System Operations Detailed
90 & 95 SERIES PAGE 14 OWNER'S MANUAL SYSTEM PROGRAMMING - Menu 1 SYSTEM OPERATIONS RESERVATION MODE REQUIRED ON MANUAL TRANSMISSION VEHICLES ONLY. RESERVATION MODE MUST BE SET TO REMOTE START THE VEHICLE. RESERVATION MODE TYPE -1 (DEFAULT SETTING) 1) PLACE THE TRANSMISSION INTO NEUTRAL (VEHICLE RUNNING). 2) APPLY THE PARKING BRAKE. - Page 15 90 & 95 SERIES PAGE 15 SYSTEM OPERATIONS OWNER'S MANUAL SYSTEM PROGRAMMING - Menu 1 PRESS & RELEASE ARM SYSTEM / LOCK DOORS Programmable. 1. Press and hold the Trunk Release button on *Hold the Trunk button on LCD 2way models. See 2way operations.
- Page 16 90 & 95 SERIES PAGE 16 OWNER'S MANUAL SYSTEM PROGRAMMING - Menu 1 SYSTEM OPERATIONS...
-
Page 17: Service Mode
90 & 95 SERIES PAGE 17 SYSTEM OPERATIONS OWNER'S MANUAL SYSTEM PROGRAMMING - Menu 1 SERVICE MODE This feature is to be used when the vehicle is being serviced or if the remote transmitter is lost or is not communicating with the system. This will disable the remote starter from activating and disable the alarm of alarm models. -
Page 18: Temp Start Mode
90 & 95 SERIES PAGE 18 OWNER'S MANUAL SYSTEM PROGRAMMING - Menu 1 SYSTEM OPERATIONS TEMP START MODE STEP 1- TURN ON LOW TEMP MODE TO SET LOW TEMP MODE HOLD LOCK AND START FOR 5 SECONDS. THE PARK LIGHTS WILL TURN ON. THE REMOTE WILL DISPLAY TEMP ON. -
Page 19: Run Time And Clock Adjustment
90 & 95 SERIES PAGE 19 SYSTEM OPERATIONS OWNER'S MANUAL SYSTEM PROGRAMMING - Menu 1 RUN TIME ADJUSTMENT TO ENTER PROGRAM MODE PRESS AND HOLD THE # BUTTON ON THE M-1234 REMOTE FOR 4 SECONDS. PROGRAM THE REMOTE WILL BEEP 3 TIMES THEN DISPLAY “PROGRAM”... -
Page 20: Shock Sensor Programming (Alarm Models)
90 & 95 SERIES PAGE 20 OWNER'S MANUAL SYSTEM PROGRAMMING - Menu 1 SYSTEM OPERATIONS SHOCK SENSOR ADJUSTMENTS (2WAY ALARM MODELS) THE SHOCK SENSOR SENSITIVITY IS SET USING THE REMOTE PROGRAM MODE FEATURE. ALARM MODELS ONLY. ENTER REMOTE PROGRAM MODE TO ENTER PROGRAM MODE PRESS AND HOLD THE # BUTTON ON THE M-1234... -
Page 21: Shock Sensor Bypass
90 & 95 SERIES PAGE 21 SYSTEM OPERATIONS OWNER'S MANUAL SYSTEM PROGRAMMING - Menu 1 3295 - PAGER MODE ON/OFF To increase battery duration on non alarm 2way systems it is recommended that the user switches the Pager Mode feature of the remote to OFF. Hold for 4 seconds. -
Page 22: Lcd 2Way Remote
90 & 95 SERIES PAGE 22 OWNER'S MANUAL SYSTEM PROGRAMMING - Menu 1 LCD 2WAY REMOTE PROGRAM MODE REMOTE PROGRAM MODE ALLOWS THE USER TO SET FEATURES ON OR OFF FROM THE REMOTE TRANSMITTER. SEE THE INSTRUCTIONS BELOW TO CHANGE A USER SETTING. - Page 23 90 & 95 SERIES PAGE 23 LCD 2WAY OWNER'S MANUAL SYSTEM PROGRAMMING - Menu 1 REMOTE PROGRAM MODE SWITCH FROM CAR 1 TO CAR 2 PRESS THE LOCK BUTTON TO SELECT CAR MODE CAR 1 PRESS THE UNLOCK BUTTON TO SELECT CAR 1 PROGRAM PRESS THE START BUTTON TO SELECT CAR 2 PRESS LOCK TO GO TO NEXT SETTING OR STATUS TO EXIT.
- Page 24 90 & 95 SERIES PAGE 24 OWNER'S MANUAL SYSTEM PROGRAMMING - Menu 1 LCD 2WAY ALARM TRIGGERS & PAGER MODE WHEN THE ALARM IS TRIGGERED THE SYSTEM WILL PAGE THE REMOTE WITH THE SPECIFIC ALARM TRIGGER. THE REMOTE WILL START TO BEEP AND THE LCD WILL ALTERNATE BETWEEN “ALARM”...
- Page 25 90 & 95 SERIES PAGE 25 LCD 2WAY OWNER'S MANUAL SYSTEM PROGRAMMING - Menu 1 FAULT CODE VIA PAGER IF THE STARTER FAILS TO START THE REMOTE WILL DISPLAY A FAULT CODE ON THE LCD DISPLAY. THE TEXT “FAULT” WILL BE FOLLOWED BY THE INPUT OR CONDITION BRAKE FAULT THIS FAULT WOULD OCCUR IF FAULT...
-
Page 26: Diagnostics
90 & 95 SERIES PAGE 26 OWNER'S MANUAL SYSTEM PROGRAMMING - Menu 1 DIAGNOSTICS ALARM STATUS / DIAGNOSTICS Diagnostic Mode is a tool that can help trouble shoot a start fault. If the remote starter fails to start i.e.: the hood is open the park likes will flash a diagnostic code. i.e.: 5 flashes = start attempt with hood open. -
Page 27: Warranty
90 & 95 SERIES PAGE 27 WARRANY OWNER'S MANUAL SYSTEM PROGRAMMING - Menu 1 WARRANTY Applicated Security Technologies, Inc. ("AST") promises to the original purchaser to repair or replace with a comparable reconditioned model any AST control module ("module") excluding without limitation the any other accessories, including but not limited to the antenna, remote, siren and wiring harness, proves to be defective in workmanship or material under reasonable use during the lifetime of the vehicle it was originally installed, provided the following conditions have been met: the module was professionally... -
Page 28: Contact Info
90 & 95 SERIES PAGE 28 OWNER'S MANUAL **FOR DETAILED VEHICLE WIRING INFORMATION GO TO: http://www.ultrastarters.com/wiring_diagrams.html This site is for registered and authorized dealer only. If you are an authorized dealer but have been registered, please fill out the service request form at http://www.ultrastarters.com/wiring_diagrams.html PRODUCT INFORMATION: www.ultrastarters.com TECHNICAL SUPPORT: support@ultrastarters.com...
