Product Bulletin - Flexible Assembly Conveyors
WT2 Exciter Plate Repair Instructions
Like all TSplus modules, the WT2 workpiece pallets are constructed from
modular components, which allow for effortless assembly, repair, or replace-
ment. One of the main components to all workpiece pallets are wear strips.
As pallet wear strips start to show signs of wear, most users simply replace
them. Exciters plates, which are part of the wearstrip and are integral in
sensing the location of a pallet, also can wear out. For those users that
would like to repair worn vertical exciter plates, replacement exciter plates
and hammer head screws are now available. To assist in replacing exciter
plates, the following 5 page instruction guide has been created. For further
assistance in replacing exciter plates or for any service/spare parts assis-
tance, please contact our Service Department at:
paul.zielbauer@boschrexroth-us.com.
