Resetting the switch to default
To reset the IP address to the default IP address
"192.168.0.100" and the user password to factory default mode
(default password is "admin"), press the hardware reset button
on the front panel for about 10 seconds. After the device is
rebooted, log in to the management Web interface within the
same subnet of 192.168.0.xx and default password. Note that
all the previous setups are erased after the factory default
reset.
Figure 11: Reset button
LCD touch screen
The managed switch has a 2.4-inch color LCD touch screen
with management functions. Tap the LCD touch screen to
wake the LCD touch interface.
Figure 12: LCD touch screen
Default LCD: Enable
Default Touch Screen: Enable
Default Backlight Timeout: Enable
Default Backlight Timeout Time: 300
Default Read Only Mode: Disable
Default Screen: Main Menu
Default Time Interval: 10
Default Color Scheme: Dark
Default PIN Number: 1234
4 / 4
Click LCD in the main menu of the the web interface (see
Figure 10 on page 3) to bring up the LCD Management page.
LCD functionality can be configured on this page.
Refer to the User Manual or click the
information about using LCD management and the web
management interface.
