Summary of Contents for AirLive WN-220ARM

  • Page 1 User Manual WN-220ARM Wireless 11N 150Mbps ADSL2+M Router...
  • Page 2: Copyright

    Copyright The contents of this publication may not be reproduced in any part or as a whole, stored, transcribed in an information retrieval system, translated into any language, or transmitted in any form or by any means, mechanical, magnetic, electronic, optical, photocopying, manual, or otherwise, without the prior written permission.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS COPYRIGHT ......................... 2 FCC INTERFERENCE STATEMENT..........錯誤! 尚未定義書籤。 1.1 PACKAGE LIST ......................4 HARDWARE INSTALLATION ..................5 CHAPTER 2. GETTING STARTED..................8 2.2 EASY SETUP BY CONFIGURING WEB PAGES............12 CHAPTER 3. MAKING CONFIGURATION ..............16 START TO CONFIGURE ..................16 3.2 SYSTEM STATUS......................
  • Page 4: Package List

    CHAPTER 1. Introduction Congratulations on your purchase of this outstanding product: WN-220ARM Wireless 11N . This product is specifically designed for home and small office 150Mbps ADSL2+M Router needs. It provides a complete solution for Internet surfing. Instructions for installing and configuring this product can be found in this manual.
  • Page 5: Hardware Installation

    1.2 Hardware Installation 1.2.1 Hardware configuration LAN1~LAN4 ADSL Connection WPS Button LEDs Status Wireless Status LED WLAN LED Power Switch On/Off Button Reset: Press “Wireless on/off” and “WPS” button for 5 sec simultaneously.
  • Page 6: Step

    Receptor for Auto MDI/MDIX RJ-45 Ports Power adapter Automatically sense the types of WAN and LAN when connecting to Ethernet RJ-11 Port 1.2.2 LED indicators LED color Description Green in flash power is on Status Green in fast flash Reset mode Green in flash xDSL connection is established ADSL...
  • Page 7: Step

    1.2.3 Installation Steps Step 1. Connect with the Ethernet patch cable: Insert the Ethernet cable into RJ45 Ethernet Port on the back panel. And then plug the other end of RJ45 into the computer or Laptop computer. The LED of Internet connection will show green color if the Ethernet connection is normally connected.
  • Page 8: Chapter 2. Getting Started

    CHAPTER 2. Getting Started 2.1 Easy Setup by Windows Utility Step 1: Install the Easy Setup Utility from CD then follow the steps to configure it. Step 2: Select Language then click “Next” to continue. Step 3: Then click the “Wizard” to continue. Or click “advanced”...
  • Page 9 Step 7: Configure your wireless interface. Step 8: Insert SSID, Channel and Security options, and then click “Next” to continue. Step 9: Auto detect the WAN service, just click the [Next] button. Or you could select the WAN type by yourself via select the check box [Let me select WAN service by myself] jump...
  • Page 10 Step 10: Select the WAN type by yourself. You can get this information by asking your ISP. Step 12: The WiFi ADSL Router is rebooted to make your entire configuration take effect. Step 13: Click “Next” to test the Internet connection.
  • Page 11 Step 14: Click “Next” to test WAN Networking service or you can ignore test. Step 15: Congratulations! Setup is completed. Now you have already connected to Internet successfully.
  • Page 12: Easy Setup By Configuring Web

    2.2 Easy Setup by Configuring Web Pages You can also browse UI of the web to configure the device. Browse to Activate the Setup Wizard Type in the IP Address (http://192.168.123.254) Type the default password ‘admin’ in the System Password and then click ‘login’...
  • Page 13 Step 2: Setup Wan Type. Step 3: Type in WAN information and go ‘next’ step. Step 4: Wireless Set up.
  • Page 14 Step 5: Wireless security setup. Step 6: Confirm your information and apply the settings. Step 7: Setup completed.
  • Page 15 Step 8: Click Finish to complete it.
  • Page 16: Chapter 3. Making Configuration

    CHAPTER 3. Making Configuration 3.1 Start to configure Whenever you want to configure your network or this device, you can access the Configuration Menu by opening the web-browser and typing in the IP Address of the device. The default IP Address is: 192.168.123.254. Enter the default password “admin”...
  • Page 17: System Status

    3.2 System Status This option provides the function for observing this product’s working status: WAN Port Status. If the WAN port is assigned a dynamic IP, there may appear a “Renew” or “Release” button on the Sidenote column. You can click this button to renew or release IP manually. Statistics of WAN: enables you to monitor inbound and outbound packets...
  • Page 18: Advanced

    3.3 Advanced 3.3.1 Basic Setting Please Select “Advanced Setup” to Setup 3.3.1.1 Primary Setup – WAN Type, Virtual Computers...
  • Page 19 Press “Change” on WAN type to change the type you want. This option is primary to enable this product to work properly. The setting items and the web appearance depend on the WAN type. Choose correct WAN type before you start. 1.
  • Page 20 Dynamic IP Address: Obtain an IP address from ISP automatically. Host Name: optional. Required by some ISPs, for example, @Home. Renew IP Forever: this feature enables this product to renew your IP address automatically when the lease time is expiring-- even when the system is idle. PPP over Ethernet: Some ISPs require the use of PPPoE to connect to their services.
  • Page 21 Maximum Idle Time: the amount of time of inactivity before disconnecting your PPPoE session. Set it to zero or enable Auto-reconnect to disable this feature. Maximum Transmission Unit (MTU): Most ISP offers MTU value to users. The most common MTU value is 1492. Connection Control: There are 3 modes to select: Connect-on-demand: The device will link up with ISP when the clients send outgoing packets.
  • Page 22 L2TP: Some ISPs require the use of L2TP to connect to their services First, please check your ISP assigned and Select Static IP Address or Dynamic IP Address. For example: Use Static My IP Address and My Subnet Mask: the private IP address and subnet mask your ISP assigned to you.
  • Page 24 Virtual Computers(Only for Static and dynamic IP address WAN type) Virtual Computer enables you to use the original NAT feature, and allows you to setup the one-to-one mapping of multiple global IP address and local IP address. • Global IP: Enter the global IP address assigned by your ISP. •...
  • Page 25 3.3.1.2 DHCP Server Press “More>>” DHCP Server: Choose “Disable” or “Enable.” Lease time: This is the length of time that the client may use the IP address it has been Assigned by DHCP server. IP pool starting Address/ IP pool starting Address: Whenever there is a request, the DHCP server will automatically allocate an unused IP address from the IP address pool to the requesting computer.
  • Page 26 3.3.1.3 Wireless Setting Wireless settings allow you to set the wireless configuration items. Wireless : The user can enable or disable wireless function. Network ID (SSID): Network ID is used for identifying the Wireless LAN (WLAN). Client stations can roam freely over this product and other Access Points that have the same Network ID. (The factory setting is “default”) SSID Broadcast: The router will Broadcast beacons that have some information, including SSID so that the wireless clients can know how many ap devices by scanning function in the network.
  • Page 28 WDS(Wireless Distribution System) WDS operation as defined by the IEEE802.11 standard has been made available. Using WDS it is possible to wirelessly connect Access Points, and in doing so extend a wired infrastructure to locations where cabling is not possible or inefficient to implement. Security: Select the data privacy algorithm you want.
  • Page 29 WPA-PSK 1. Select Encryption and Pre-share Key Mode If you select HEX, you have to fill in 64 hexadecimal (0, 1, 2…8, 9, A, B…F) digits If ASCII, the length of pre-share key is from 8 to 63. 2. Fill in the key, Ex 12345678...
  • Page 30 Check Box was used to switch the function of the WPA. When the WPA function is enabled, the Wireless user must authenticate to this router first to use the Network service. RADIUS Server IP address or the 802.1X server’s domain-name. Select Encryption and RADIUS Shared Key If you select HEX, you have to fill in 64 hexadecimal (0, 1, 2…8, 9, A, B…F) digits.
  • Page 31 WPA/WPA2 Check Box was used to switch the function of the WPA. When the WPA function is enabled, the Wireless user must authenticate to this router first to use the Network service. RADIUS Server The router will detect automatically which Security type (Wpa-psk version 1 or 2) the client uses to encrypt.
  • Page 32: Forwarding Rules

    3.3.2 Forwarding Rules...
  • Page 33 3.3.2.1 Virtual Server This product’s NAT firewall filters out unrecognized packets to protect your Intranet, so all hosts behind this product are invisible to the outside world. If you wish, you can make some of them accessible by enabling the Virtual Server Mapping. A virtual server is defined as a Service Port, and all requests to this port will be redirected to the computer specified by the Server IP Virtual Server can work with Scheduling Rules, and give user more flexibility on Access control.
  • Page 34 3.3.2.2 Special AP Some applications require multiple connections, like Internet games, Video conferencing, Internet telephony, etc. Because of the firewall function, these applications cannot work with a pure NAT router. The Special Applications feature allows some of these applications to work with this product.
  • Page 35 3.3.2.3 Miscellaneous Items IP Address of DMZ Host DMZ ( Demilitarized Zone) Host is a host without the protection of firewall. It allows a computer to be exposed to unrestricted 2-way communication for Internet games, Video conferencing, Internet telephony and other special applications. NOTE: This feature should be used only when needed.
  • Page 36: Security Settings

    3.3.3 Security Settings...
  • Page 37 3.3.3.1 Packet Filters Packet Filter enables you to control what packets are allowed to pass the router. Outbound filter applies on all outbound packets. However, Inbound filter applies on packets that destined to Virtual Servers or DMZ host only. You can select one of the two filtering policies: 1.
  • Page 38 Each rule can be enabled or disabled individually. Inbound Filter: To enable Inbound Packet Filter click the check box next to Enable in the Inbound Packet Filter field. Suppose you have SMTP Server (25), POP Server (110), Web Server (80), FTP Server (21), and News Server (119) defined in Virtual Server or DMZ Host.
  • Page 39 Example 2: (1.2.3.100-1.2.3.119) Remote hosts can do everything except read net news (port 119) and transfer files via FTP (port 21) behind Router Server. Others are all allowed. After Inbound Packet Filter setting is configured, click the save button.
  • Page 40 Outbound Filter: To enable Outbound Packet Filter click the check box next to Enable in the Outbound Packet Filter field. Example 1: Router LAN IP is 192.168.12.254 (192.168.12.100-192.168.12.149) Located hosts are only allowed to send mail (port 25), receive mail (port 110), and browse Internet (port 80); port 53 (DNS) is necessary to resolve the domain name.
  • Page 41 Example 2: Router LAN IP is 192.168.12.254 (192.168.12.100 and 192.168.12.119) Located Hosts can do everything except read net news (port 119) and transfer files via FTP (port 21) Others are allowed After Outbound Packet Filter setting is configured, click the save button.
  • Page 42 3.3.3.2 Domain filters Domain Filter Let you prevent users under this device from accessing specific URLs. Domain Filter Enable Check if you want to enable Domain Filter. Log DNS Query Check if you want to log the action when someone accesses the specific URLs. Privilege IP Addresses Range Setting a group of hosts and privilege these hosts to access network without restriction.
  • Page 43 In this example: 1. URL include “www.msn.com” will be blocked, and the action will be record in log-file. 2. URL include “www.sina.com” will not be blocked, but the action will be record in log-file. 3. URL include “www.baidu.com” will be blocked, but the action will not be record in log-file. 4.
  • Page 44 3.3.3.3 URL Blocking URL Blocking will block LAN computers to connect to pre-defined Websites. The major difference between “Domain filter” and “URL Blocking” is Domain filter require user to input suffix (like .com or .org, etc), while URL Blocking require user to input a keyword only. In other words, Domain filter can block specific website, while URL Blocking can block hundreds of websites by simply a keyword.
  • Page 45 In this example: 1. URL include “msn” will be blocked, and the action will be record in log-file. 2. URL include “sina” will be blocked, but the action will be record in log-file...
  • Page 46 3.3.3.4 MAC control MAC Address Control allows you to assign different access right for different users and to assign a specific IP address to a certain MAC address. MAC Address Control Check “Enable” to enable the “MAC Address Control”. All of the settings in this page will take effect only when “Enable”...
  • Page 47 "Control table" is the table at the bottom of the "MAC Address Control" page. Each row of this table indicates the MAC address and the expected IP address mapping of a client. There are four columns in this table: MAC Address MAC address indicates a specific client.
  • Page 48 Example: In this scenario, there are three clients listed in the Control Table. Clients 1 and 2 are wireless, and client 3 is wired. 1. The "MAC Address Control" function is enabled. 2. "Connection control" is enabled, and all of the wired and wireless clients not listed in the "Control table"...
  • Page 49 3.3.3.5 MiscelLANeous Items Remote Administrator Host/Port In general, only Intranet user can browse the built-in web pages to perform administration task. This feature enables you to perform administration task from remote host. If this feature is enabled, only the specified IP address can perform remote administration. If the specified IP address is 0.0.0.0, any host can connect to this product to perform administration task.
  • Page 50: Advanced Settings

    3.3.4 Advanced Settings...
  • Page 51 3.3.4.1 System Time Get Date and Time by NTP Protocol Selected if you want to Get Date and Time by NTP Protocol. Time Server Select a NTP time server to consult UTC time Time Zone Select a time zone where this device locates. Set Date and Time manually Selected if you want to Set Date and Time manually.
  • Page 52 3.3.4.2 System Log This page support two methods to export system logs to specific destination by means of syslog(UDP) and SMTP(TCP). The items you have to setup including: IP Address for Syslog Host IP of destination where syslogs will be sent to. Check Enable to enable this function.
  • Page 53 3.3.4.3 System Log To host your server on a changing IP address, you have to use dynamic domain name service (DDNS). So that anyone wishing to reach your host only needs to know the name of it. Dynamic DNS will map the name of your host to your current IP address, which changes each time you connect your Internet service provider.
  • Page 54 3.3.4.4 SNMP In brief, SNMP, the Simple Network Management Protocol, is a protocol designed to give a user the capability to remotely manage a computer network by polling and setting terminal values and monitoring network events. Enable SNMP You must check Local, Remote or both to enable SNMP function. If Local is checked, this device will response request from LAN.
  • Page 55 3.3.4.5 Routing Routing Tables allow you to determine which physical interface address to use for outgoing IP data grams. If you have more than one routers and subnets, you will need to enable routing table to allow packets to find proper routing path and allow different subnets to communicate with each other.
  • Page 56 Configuration on NAT Router Destination SubnetMask Gateway Enabled 192.168.1.0 255.255.255.0 192.168.123.216 ˇ 192.168.0.0 255.255.255.0 192.168.123.103 ˇ So if, for example, the client3 wanted to send an IP data gram to 192.168.0.2, it would use the above table to determine that it had to go via 192.168.123.103 (a gateway), And if it sends Packets to 192.168.1.11 will go via 192.168.123.216 Each rule can be enabled or disabled individually.
  • Page 57 3.3.4.6 Schedule Rule You can set the schedule time to decide which service will be turned on or off. Select the “enable” item. Press “Add New Rule” You can write a rule name and set which day and what time to schedule from “Start Time” to “End Time”.
  • Page 58 Schedule Enable Selected if you want to Enable the Scheduler. Edit To edit the schedule rule. Delete To delete the schedule rule, and the rule# of the rules behind the deleted one will decrease one automatically. Schedule Rule can be apply to Virtual server and Packet Filter, for example: Exanple1: Virtual Server –...
  • Page 60 3.3.4.7 QoS Rule Local IP: Please input Client IP,ex192.168.12.33. Remote Priority: Please input Global IP and port,ex:168.96.2.3 and port 21...
  • Page 61: Toolbox

    3.3.5 Toolbox...
  • Page 62 3.3.5.1 View Log can View system log by clicking the View Log button...
  • Page 63 3.3.5.2 Firmware Upgrade You can upgrade firmware by clicking Firmware Upgrade button. 3.3.5.3 Backup Setting You can backup your settings by clicking the Backup Setting button and save it as a bin file. Once you want to restore these settings, please click Firmware Upgrade button and use the bin file you saved.
  • Page 64 3.3.5.4 Reset to default You can also reset this product to factory default by clicking the Reset to default button. 3.3.5.5 Reboot You can also reboot this product by clicking the Reboot button. 3.3.5.6 MiscelLANeous Items MAC Address for Wake-on-LAN Wake-on-LAN is a technology that enables you to power up a networked device remotely.
  • Page 65 router to send the wake-up frame to the target device immediately. Domain Name or IP Address for Test Allow you to configure an IP, and ping the device. You can ping a secific IP to test whether it is alive.
  • Page 66: Chapter 4. Troubleshooting

    CHAPTER 4. Troubleshooting This Chapter provides solutions to problems for the installation and operation of the WiFi ADSL Router. You can refer to the following if you are having problems. 1 Why can’t I configure the router even the cable is plugged and the LED is lit? Do a Ping test to make sure that the WiFi Combo Note: It is recommended that you use...
  • Page 67 Select Properties to ensure that all drivers are installed properly. Look under Device Status to see if the device is working properly. Click “OK”. 2 What can I do if my Ethernet connection does not work properly? Make sure the RJ45 cable connects with the router. Ensure that the setting on your Network Interface Card adapter is “Enabled”.
  • Page 68 information. Why does my 3G connection keep dropping? Please check 3G signal strength from your ISP in your environment is above middle level. 4 Something wrong with the wireless connection? Can’t setup a wireless connection? Ensure that the SSID and the encryption settings are exactly the same to the Clients.
  • Page 69 III. Keep your product away from electrical devices that generate RF noise, like microwaves, monitors, electric motors, etc. 5 What to do if I forgot my encryption key? 1. Go back to advanced setting to set up your Encryption key again. 2.
  • Page 70: Appendix A. Spec Summary Table

    Appendix A. Spec Summary Table Device Interface WN-220ARM ADSL Line xDSL port (Annex A) Ethernet LAN RJ-45 port, 10/100Mbps, auto-MDI/MDIX 1-port ADSL2+ connector ADSL2 /2+ ITU 992.1 (G.dmt) Annex A, ITU 992.2 ● Standard Module (G.lite), ITU 992.3 ADSL2 (G.dmt.bis), 992.5 ADSL2+...
  • Page 71 Temp.: -10~70oC, Humidity: 0~95% ● Storage Temp. non-condensing ● EMI Certification CE/FCC compliance ● RoHS RoHS compliance *Specifications are subject to change without notic...
