Cisco BTS 10200 Softswitch
Cabling, VLAN, and IRDP Procedures
The purpose of this procedure is to explain how to:
This procedure is applicable to a Cisco BTS 10200 Softswitch with active and standby components
colocated in the same office.
This procedure is applicable only to systems with Continuous Computing hardware. If you are using
Note
other hardware, contact your Cisco account team for procedures.
This procedure is not applicable to Cisco BTS 10200 Softswitch systems that are already in service.
Do not use this procedure to change the cabling of an in-service Cisco BTS 10200 Softswitch, because
Caution
that will cause interruption of service. It is not necessary to change the cabling of in-service systems to
match this document.
Front View of Rack-Mounted Equipment
The front view of the standard Cisco BTS 10200 Softswitch system rack is shown in
Corporate Headquarters:
Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
Copyright © 2003. Cisco Systems, Inc. All rights reserved.
C I S C O C O N F I D E N T I A L
Cable a new Cisco BTS 10200 Softswitch system
Provision the virtual local area network (VLAN) on the Cisco 2924M Ethernet Switches (hubs)
Enable Internet Control Protocol (ICMP) Router Discovery Protocol (IRDP) functionality on the
Cisco BTS 10200 Softswitch and on the Cisco routers adjacent to the Cisco BTS 10200 Softswitch
Figure 1 on page
2.

Advertisement

Table of Contents
loading

Summary of Contents for Cisco BTS 10200

  • Page 1 Cisco account team for procedures. This procedure is not applicable to Cisco BTS 10200 Softswitch systems that are already in service. Do not use this procedure to change the cabling of an in-service Cisco BTS 10200 Softswitch, because Caution that will cause interruption of service.
  • Page 2 Front View of Rack-Mounted Equipment C I S C O C O N F I D E N T I A L Figure 1 Standard Cisco BTS 10200 Softswitch Rack Configuration Alarm panel, PDU power feed 8A Filler panel PDU (DC systems)
  • Page 3: Network Vlan Diagram

    Network VLAN Diagram C I S C O C O N F I D E N T I A L Network VLAN Diagram Figure 2 shows the physical interfaces and VLAN connections. Figure 2 Network VLAN Diagram First uplink for external communications (connect to router). Uplink for external access to hosts (connect to router).
  • Page 4: Labeling The Cables

    Step 1 Obtain the 10 Ethernet cables needed for connections between the rear panel of the Element Management Systems (EMS A and EMS B) and the two Cisco 2924M Ethernet Switches (Hub A and Hub B). These cables are listed in...
  • Page 5: Connect Console Ethernet Cables To Alarm Panel

    Obtain the 18 Ethernet cables needed for connections between the rear panel of the Call Agents (CA A Step 3 and CA B) and the two Cisco 2924M Ethernet Switches (Hub A and Hub B). These cables are listed in Table 1...
  • Page 6: Connect Ccpunet Cables And Terminating Resistors

    “switch” end must connect to the Hub and the “net CCN” end must connect to the Alarm Panel. Refer to Figure 1 on page 2 to identify which Cisco 2924M Ethernet Switch (Hub) is designated Step 1 Ethernet Switch A and which is Ethernet Switch B.
  • Page 7: Connect External Network Uplink Cables To Ethernet Switches

    Switch A and which is Ethernet Switch B. Step 2 If your local network documentation calls for gigabit Ethernet, contact Cisco TAC for assistance. Step 3 If your local network documentation calls for 100 Mb Ethernet, connect the applicable network uplink...
  • Page 8: Connect Internal Power And Grounding Cables

    DC power cables and ground cables from the power distribution unit (PDU) to the other devices in the Cisco BTS 10200 Softswitch rack. If you need to connect an AC system, contact your Cisco account team for assistance. Note...
  • Page 9: Connect Site Power And Grounding Cables To Pdu

    After obtaining approval from a supervisor, an authorized power installer should follow these steps to connect the DC power from the office batteries to the PDU. For DC systems the nominal current rating for a complete Cisco BTS 10200 Softswitch system Note is 26A at -48 VDC, and the maximum current rating is 40A at -48 VDC.
  • Page 10 Connect Site Power and Grounding Cables To PDU C I S C O C O N F I D E N T I A L This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the absence of a suitably installed ground conductor.
  • Page 11: Provision Vlans

    C I S C O C O N F I D E N T I A L Provision VLANs Follow the procedures in this section to provision the VLANs on the Cisco 2924M Ethernet Switches (Hubs). You will need to enter a password to log on to these hubs.
  • Page 12 Provision VLANs C I S C O C O N F I D E N T I A L interface FastEthernet0/4 description 120-Network Name-Redundancy1 switchport access vlan 146 interface FastEthernet0/5 description 122-Network Name-Billing1 switchport access vlan 147 interface FastEthernet0/6 description 122-Network Name-Billing1 switchport access vlan 147 interface FastEthernet0/7 description 122-Network Name-Billing1...
  • Page 13 Provision VLANs C I S C O C O N F I D E N T I A L description 225-Network Name-MGCP1 switchport access vlan 149 interface FastEthernet0/14 description 225-Network Name-MGCP1 switchport access vlan 149 interface FastEthernet0/15 description 225-Network Name-MGCP1 switchport access vlan 149 interface FastEthernet0/16 description 224-Network Name-Telnet...
  • Page 14 Provision VLANs C I S C O C O N F I D E N T I A L interface FastEthernet0/23 description 224-Network Name-Telnet switchport access vlan 150 interface FastEthernet0/24 Step 6 Add the VLANs to the database using the following commands: switch-a#vlan database switch-a(vlan)#vlan 146 switch-a(vlan)#vlan 147...
  • Page 15: Provision Vlans On Hub B

    C I S C O C O N F I D E N T I A L Provision VLANs On Hub B Follow these steps to provision the VLANs on Cisco 2924M Ethernet Switch B (Hub B): Connect a console cable to the Hub B console port. Use...
  • Page 16 Provision VLANs C I S C O C O N F I D E N T I A L interface FastEthernet0/5 description 123-Network Name-Billing2 switchport access vlan 147 interface FastEthernet0/6 description 123-Network Name-Billing2 switchport access vlan 147 interface FastEthernet0/7 description 123-Network Name-Billing2 switchport access vlan 147 interface FastEthernet0/8 description 123-Network Name-Billing2...
  • Page 17 Provision VLANs C I S C O C O N F I D E N T I A L switchport access vlan 149 interface FastEthernet0/15 description 226-Network Name-MGCP2 switchport access vlan 149 interface FastEthernet0/16 interface FastEthernet0/17 interface FastEthernet0/18 interface FastEthernet0/19 interface FastEthernet0/20 interface FastEthernet0/21 interface FastEthernet0/22...
  • Page 18 Provision VLANs C I S C O C O N F I D E N T I A L Verify that the status display includes response lines exactly as shown in the following system Step 9 response: switch-b#show vlan VLAN Name Status Ports ---- -------------------------------- --------- -------------------------------...
  • Page 19: Enable Irdp

    C I S C O C O N F I D E N T I A L Enable IRDP This section discusses how to enable IRDP functionality on the Cisco BTS 10200 Softswitch and on the network router. Enable IRDP on the Cisco BTS 10200 Softswitch Follow these steps to enable IRDP on the Cisco BTS 10200 Softswitch.
  • Page 20: Enable Irdp On Adjacent Cisco Routers

    Enable IRDP on Adjacent Cisco Routers If you are enabling IRDP on Cisco routers adjacent to the Cisco BTS 10200 Softswitch, follow these steps. If you have any questions about setup of these routers, contact your system administrator. If you need additional assistance, contact Cisco TAC.
  • Page 21: Verify Interfaces

    B CA. Verify Interfaces Follow these steps to verify that all interfaces are configured on all computing elements: If the Cisco BTS 10200 Softswitch application software has already been installed on the system, go to Step 1 Step 2.
  • Page 22: Appendix A: Cable Labeling

    Appendix A: Cable Labeling C I S C O C O N F I D E N T I A L Appendix A: Cable Labeling Cables are labeled at both ends with the cable numbers listed in Table 1. Follow these steps to create and attach the labels.
  • Page 23: Appendix B: Cable List

    Appendix B: Cable List C I S C O C O N F I D E N T I A L Appendix B: Cable List Table 1 lists the cable numbers and connections. Table 1 Cable List (See Procedure for Descriptions and Drawings) From (Unit, Port) To (Unit, Port) Cable No.
  • Page 24 Appendix B: Cable List C I S C O C O N F I D E N T I A L Table 1 Cable List (See Procedure for Descriptions and Drawings) (continued) From (Unit, Port) To (Unit, Port) Cable No. HUB-B 15 Uplink for MGCP2 (see footnote 1)
  • Page 25 100Mb Ethernet, contact Cisco TAC for assistance. 2. To (Unit, Port) and Cable No. for SS7 signaling (T1) connections are customer-defined. In some networks, SS7 cables do not need to be connected to the Cisco BTS 10200 Softswitch. See the procedure for more information.
  • Page 26: Appendix C: Translated Safety Warnings

    Appendix C: Translated Safety Warnings C I S C O C O N F I D E N T I A L Appendix C: Translated Safety Warnings Warning Definition IMPORTANT SAFETY INSTRUCTIONS Warning This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents.
  • Page 27: Importantes Informations De Sécurité

    Appendix C: Translated Safety Warnings C I S C O C O N F I D E N T I A L Attention IMPORTANTES INFORMATIONS DE SÉCURITÉ Ce symbole d'avertissement indique un danger. Vous vous trouvez dans une situation pouvant causer des blessures ou des dommages corporels.
  • Page 28: Viktige Sikkerhetsinstruksjoner

    Appendix C: Translated Safety Warnings C I S C O C O N F I D E N T I A L Advarsel VIKTIGE SIKKERHETSINSTRUKSJONER Dette varselssymbolet betyr fare. Du befinner deg i en situasjon som kan forårsake personskade. Før du utfører arbeid med utstyret, bør du være oppmerksom på farene som er forbundet med elektriske kretssystemer, og du bør være kjent med vanlig praksis for å...
  • Page 29 Appendix C: Translated Safety Warnings C I S C O C O N F I D E N T I A L OL-2906-01...
  • Page 30: Ground Conductor Warning

    Appendix C: Translated Safety Warnings C I S C O C O N F I D E N T I A L Ground Conductor Warning This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the absence of a suitably installed ground conductor.
  • Page 31 Appendix C: Translated Safety Warnings C I S C O C O N F I D E N T I A L Varning! Denna utrustning måste jordas. Koppla aldrig från jordledningen och använd aldrig utrustningen utan en på lämpligt sätt installerad jordledning. Om det föreligger osäkerhet huruvida lämplig jordning finns skall elektrisk besiktningsauktoritet eller elektriker kontaktas.
  • Page 32: Obtaining Documentation

    Obtaining Documentation These sections explain how to obtain documentation from Cisco Systems. World Wide Web You can access the most current Cisco documentation on the World Wide Web at this URL: http://www.cisco.com Translated documentation is available at this URL: http://www.cisco.com/public/countries_languages.shtml...
  • Page 33: Obtaining Technical Assistance

    Priority level 1 (P1)—Your production network is down, and a critical impact to business operations • will occur if service is not restored quickly. No workaround is available. The Cisco TAC resource that you choose is based on the priority of the problem and the conditions of service contracts, when applicable. OL-2906-01...
  • Page 34 Net Readiness Scorecard, Networking Academy, and ScriptShare are trademarks of Cisco Systems, Inc.; Changing the Way We Work, Live, Play, and Learn, The Fastest Way to Increase Your Internet Quotient, and iQuick Study are service marks of Cisco Systems, Inc.; and Aironet, ASIST, BPX,...
