AWM2P
MICROMODULE
U
S
R E
M
A
N
U
A
L
3
20262 / 20101011 • AWM2P
TM
© ALL RIGHTS RESERVED MARMITEK®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AWM2P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Marmitek AWM2P

  • Page 1 AWM2P ™ AWM2P MICROMODULE 20262 / 20101011 • AWM2P © ALL RIGHTS RESERVED MARMITEK®...
  • Page 2 MICROMODULE AWM2P ENGLISH NEDERLANDS Phase clamp (230V) Fase aansluiting (230V) Load clamp Aansluiting voor belasting Neutral clamps Nulklemmen Indicator light (LED) LED indicator Set up button Programmeerknopje Wire connections to wall switches Aansluitdraden voor schakelaars © MARMITEK...
  • Page 3: Safety Warnings

    MARMITEK MICROMODULE AWM2P Marmitek X-10 transmitter for 2 addresses with a built-in appliance module. SAFETY WARNINGS • The wiring of your electrical installation is live (230 V) and extremely dangerous. Never connect the module when plugged into the mains. Always turn off the main switch before starting the installation.
  • Page 4: Signal Range

    The Marmitek X-10 System is based on power line communication. The range of the Marmitek X-10 signals very much depends on the local circumstances. On average the range is a cable length of 80 meters. If you have difficulties with the range of your Marmitek X-10 signals, please pay attention to the following facts: 1.
  • Page 5 (several groups is no problem for the Marmitek X-10 signal). 2. It is possible that Marmitek X-10 signals are attenuated by devices and lights which are connected to the power line. In a normal home situation this effect is negligible (the Marmitek X-10 system is using active gain control to eliminate the effects).
  • Page 6 The address to be set up can be programmed through the power line with every Marmitek X-10 remote control (e.g. Marmitek EasyControl8™ remote control withTM13 transceiver). • The AWM2P can react to one or more group commands (ALL LIGHTS ON, ALL UNITS OFF). These functions are disabled by default. © MARMITEK...
  • Page 7 Due to this Marmitek X-10 transmission you are able to switch other Marmitek X-10 modules (set to the same address). The new status will also be recognized by other MicroModuls or e.g.
  • Page 8 When the red wire is connected to the phase wire, the programmed “address +1” will be transmitted (e.g. when A3 is programmed as the base address then the Marmitek X-10 address A4 will be sent by using input 2). If the status in the MicroModule was ON, an OFF command will be transmitted.
  • Page 9 Figure 2 • Connect the phase, neutralize and load wire to the terminals of the MicroModule AWM2P. • Connect the thin wires of the built-in module to the wall switch. Connect the phase wire to clamp P of the wall switch.
  • Page 10 60 seconds. Exit setup mode • Press the setup button once shortly; The red LED will turn off now. You can also wait for at least 60 seconds so that the MicroModule will exit the setup mode automatically. © MARMITEK...
  • Page 11 2x “All Units Off” “All Units Off” Units Off” For programming the Marmitek X-10 address and options you will be able to use any Marmitek X-10 controller or remote control. For the following explanation we used a Marmitek 8-in-1 remote control to AWM2P™...
  • Page 12 • If you have programmed the address, but you wish to change it again you need to switch the AWM2P out of the programming mode and put it in the programming mode again. • When programming the AWM2P, do not give the commands with too little time in between, keep 1 second pauses in between the commands.
  • Page 13: Freqently Asked Questions

    FREQENTLY ASKED QUESTIONS What is the reason for modules to switch on/off spontaneously? It is possible that a Marmitek X-10 System is installed at one of your neighbours using the same House Code. To solve this problem try to change the House Code of your system, or have FD10 Phase Coupler/ Filter installed at your incoming mains.
  • Page 14: Technical Data

    TM13 is transmitting. TM13’s will wait for a quite power line before transmitting their data. To prevent your Marmitek X-10 System to become slow or to prevent dimming from becoming less smooth, make sure that the TM13 units are placed as far away from each other as possible.
  • Page 15 Correct disposal and recycling will help prevent potential negative consequences to the environment and human health. For more detailed information about the disposal of your old equipment, please contact your local authorities, waste disposal service, or the shop where you purchased the product. AWM2P™...
  • Page 16 Copyright and all other proprietary rights in the content (including but not limited to model numbers, software, audio, video, text and photographs) rests with Marmitek B.V. Any use of the Content, but without limitation, distribution, reproduction, modification, display or transmission without the prior written consent of Marmitek is strictly prohibited.
  • Page 17: Declaration Of Conformity

    Richtlijn 2002/95/EG van het Europees Parlement en de Raad van 27 januari 2003 betreffende beperking van het gebruik van bepaalde gevaarlijke stoffen in elektrische en elektronische apparatuur MARMITEK BV - P.O. BOX 4257 - 5604 EG EINDHOVEN – THE NETHERLANDS AWM2P™...
