QT-CD111H/110H
IC701 RH-iX0105AWZZ (IX0105AW): System Control Microcomputer
Pin No. Terminal Port Name
Name
1* P03 MTCONT2
2*-5* P10-P13 POWER-IN,
DATA (VOL),
STB (VOL)
6* D0 POWER-ON
7 D1 MUTE
8*-12 D2-D6 SYNC-OUT,
RES,CQCK,
COIN,REC
13,14 D7,D8 SL+,SL-
15*,16* D9,D10 SRS2,SRS1
17 P20 DRF
18 P21 SQOUT
19 P22 WRQ
20 P23 PU-IN
21 RESET
22 XIN
23 XOUT
24 VSS
25 VDD
26* XCOUT
27 XCIN
28 AVSS
29 VREF
30 P30 REMOCONINT2
31 P31 TORAY1
32 P32 TORAY2
33 P33
34 P40
35-37 AIN5-AIN7
38-40 VLC3-VLC1
41-44 COM3-COM0
45-61* SEG16-SEG0
(45*-56*)
62*-64* P00-P02
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.

FUNCTION TABLE OF IC

Input/
Output
Input/Output Used to input or output 4 bits at a time. When the output latch is set to "1", the unit will be in the
input mode. The key-on wakeup function, which can be switched on or off by the software, and a
pull-up transistor, which can be turned on or off by the software, are built in.
Input/Output Used to input or output 4 bits at a time. When the output latch is set to "1", the unit will be in the
input CK (VOL), mode.The key-on wakeup function, which can be switched on or off by the software,
and a pull-up transistor,which can be turned on or off by the software, are built in.
Input/Output Each terminal can be used to input or output 1 bit at a time. The output section has a latch which
holds 1 bit. One of the D ports is assigned by register Y as a data point, to execute input or output.
To use the port for input, set the output latch for that bit to "1". All of the output latches on port D can
be set to "1" using the CLD command.
Input/Output Each terminal can be used to input or output 1 bit at a time. The output section has a latch which
holds 1 bit. One of the D ports is assigned by register Y as a data point, to execute input or output.
To use the port for input, set the output latch for that bit to "1". All of the output latches on port D can
be set to "1" using the CLD command.
Input/Output Each terminal can be used to input or output 1 bit at a time. The output section has a latch which
holds 1 bit. One of the D ports is assigned by register Y as a data point, to execute input or output.
To use the port for input, set the output latch for that bit to "1". All of the output latches on port D can
be set to "1" using the CLD command.
Input/Output Each terminal can be used to input or output 1 bit at a time. The output section has a latch which
holds 1 bit. One of the D ports is assigned by register Y as a data point, to execute input or output.
To use the port for input, set the output latch for that bit to "1". All of the output latches on port D can
be set to "1" using the CLD command.
Input/Output Each terminal can be used to input or output 1 bit at a time. The output section has a latch which
holds 1 bit. One of the D ports is assigned by register Y as a data point, to execute input or output.
To use the port for input, set the output latch for that bit to "1". All of the output latches on port D can
be set to "1" using the CLD command.
Input/Output Used to receive 4 bits at a time.
Input/Output Used to receive 4 bits at a time.
Input/Output Used to receive 4 bits at a time.
Input/Output Used to receive 4 bits at a time.
Input/Output Reset pulse input/output terminal. When a reset is caused by the watch dog timer, an "L" level will
be output. The output is an N channel open drain.
Input Input/output terminals for the main clock generation circuit. Used by connecting a ceramic resonator
between the XIN and XOUT terminals. There is a built-in feedback resistor between the XIN and
XOUT terminals.
Output Input/output terminals for the main clock generation circuit. Used by connecting a ceramic resonator
between the XIN and XOUT terminals. There is a built-in feedback resistor between the XIN and
XOUT terminals.
— GND input terminal.
— Positive power supply terminal.
Output Input/output terminals for the sub clock generation circuit. Used by connecting a crystal oscillator
between the XCIN and XCOUT terminals. There is a built-in feedback resistor between the XCIN
and XCOUT terminals.
Input Input/output terminals for the sub clock generation circuit. Used by connecting a crystal oscillator
between the XCIN and XCOUT terminals. There is a built-in feedback resistor between the XCIN
and XCOUT terminals.
Input GND input terminal for the A-D converter.
Input Reference voltage input terminal for the A-D converter.
Input Used to receive 4 bits at a time.
Input Used to receive 4 bits at a time.
Input Used to receive 4 bits at a time.
Input Used to receive 4 bits at a time.
Input Used to receive 4 bits at a time.
Input Used to receive 4 bits at a time.
Input LCD power input terminals. To use the internal resistor, connect VLC3 to VDD (if a brightness
control is needed, connect VLC3 to VDD through a resistor). When an external power supply is
used, applyvoltages as follows: 0<VLC1<VLC3<VLCD<VDD.
Output LCD common output terminals.
Output LCD segment output terminals.
Input/Output Used to input or output 4 bits at a time. When the output latch is set to "1", the unit will be in the
input mode. The key-on wakeup function, which can be switched on or off by the software, and a
pull-up transistor, which can be turned on or off by the software, are built in.
– 22 –
