WARNINGS
The exclamation point within the triangle is a warning sign alert-
ing the user of important instructions accompanying the
product.
The lightening flash with arrowhead symbol within the triangle
is a warning sign alerting the user of "dangerous voltage" inside
the unit.
To reduce the risk of electric shock, do not remove the cover. No
user serviceable parts inside the unit. Refer all servicing to
qualified personnel.
This unit employs a laser. Only a qualified service person should
remove the cover or attempt to service this device, due to
possible eye injury.
Invisible laser radiation when the unit is opened or interlocks
defeated. Avoid exposure to laser beam. Use of controls,
adjustments or procedures other than those specified herein
may result in hazardous radiation exposure.
This unit operates on 230V ~ 50Hz. If the unit is not used for a
long period of time, remove the plug from the AC mains.
This unit must not be exposed to moisture or rain.
The power switch in this unit is mounted on the secondary
circuit and does not disconnect the whole unit from the mains in
OFF position.
Ensure all connections are properly made before operating the
unit.
This unit should be positioned so that it is properly ventilated.
Avoid placing it, for example, close to curtains, on the carpet or in
a built-in installation such as a bookcase.
Do not expose this unit to direct sunlight or heat radiating sources.
Make sure all batteries are inserted according to the proper
polarity.
If the unit is not used for a long period of time (more than 1
month), remove all batteries from their compartment to avoid
possible leaking.
English 1
HIF-6880USMPT
MICRO HIFI SYSTEM WITH TOP LOADING CD/MP3 PLAYER, USB AND SD/MMC
READER, ENCODING FUNCTION, 2-BAND TUNER, AUTOSTOP CASSETTE AND
FULL FUNCTION REMOTE CONTROL.
INSTRUCTION MANUAL
Please read this instruction manual carefully and familiarize yourself with your new HiFi
System before using it for the first time. Please retain this manual for future reference.

LOCATION OF CONTROLS

1. SPEAKER
2. CASSETTE DOOR
3. LCD DISPLAY
4. STANDBY INDICATOR
5. STANDBY BUTTON
6. PROG/MEMORY/ERASE BUTTON
7. IR SENSOR
8. HEADPHONES JACK
9. CD PLAY/PAUSE BUTTON
10. SKIP/SEARCH/TUNING DOWN BUTTON
11. ENCODING BUTTON
12. SKIP/SEARCH/TUNING UP BUTTON
13. MENU BUTTON
14. CD STOP/BAND BUTTON
15. BEAT-CUT BUTTON
16. VOLUME KNOB
17. M-DN / RANDOM BUTTON
18. CD DOOR OPEN/CLOSE BUTTON
19. M-UP / REPEAT BUTTON
20. FUNCTION BUTTON
21. MEMORY CARD JACK
22. USB IN JACK
23. CASSETTE RECORD BUTTON
24. CASSETTE PLAY BUTTON
25. CASSETTE REWIND BUTTON
26. CASSETTE FAST FORWARD BUTTON
27. CASSETTE STOP/ELECT BUTTON
28. CASSETTE PAUSE BUTTON II
29. CD DOOR
