  • Page 1 C o m m u n i c a t i o n s C o m m u n i c a t i o n s C o m m u n i c a t i o n s EX-2.4i 2.4GHz Digital Microwave Radio Installation and Maintenance Manual...
  • Page 2 The contents of this document are current as of the date of publication. Exalt reserves the right to change the contents without prior notice. In no event will Exalt be liable for any special, incidental, or consequential damages or for commercial losses in connection with...

  • Page 3: Revision History

    EX-2.4i Installation and Maintenance Manual About this Document This manual provides a complete description of the Exalt EX-2.4i Digital Microwave Radio and related software. The purpose of this manual is to provide the planner, engineer, installer, system administrator, and technician with general and specific information related to the planning, installation, operation, management and maintenance of the device.

  • Page 4: General Compliance And Safety

    Exalt or your dealer for assistance. This device may not be modified in any way without the express written consent of Exalt. Modification will not only void the manufacturer warranty, but may also be expressly illegal in accordance to government regulations.
  • Page 5 Shielded cables and I/O cords must be used for this equipment to comply with the relevant FCC regulations. Changes or modifications not expressly approved in writing by Exalt may void the user’s authority to operate this equipment. This device must be professionally installed.

  • Page 6: Safety Notices

    Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual Gabriel P-24A48 4-foot Grid Parabolic Dish 27.7 Gabriel SSP2-23 2-foot Solid Parabolic Dish 20.7 Gabriel SSP4-23 4-foot Solid Parabolic Dish 26.7 Gabriel SSP6-23 6-foot Solid Parabolic Dish 30.3 Gabriel HSSP2-23 2-foot Solid HP Parabolic Dish 20.5...
  • Page 7 Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual • Proper ventilation and/or airflow shall be provided surrounding the equipment. Do not block any intake or exhaust vents. Items shall not come in contact with heat-sinking materials. Assure that ambient operational and storage temperature specifications are maintained at all times.

  • Page 8: Warranty

    For warranty returns, cost of shipment to Exalt’s authorized service center shall be borne by the customer. Cost of return shipment shall be borne by Exalt and will be made by Exalt’s choice of carrier and method/schedule of shipment. Customers may expedite return shipments, upon request, at their own expense.

  • Page 9: Table Of Contents

    Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual Table of Contents Legal Notice............................. i About this Document ........................ii Revision History ......................... ii Icons............................ii General Compliance and Safety..................... iii Regulatory Notices......................... iii Safety Notices ..........................v Warranty ............................vii Section 1 - Introduction ........................
  • Page 10 Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual Configuration Using the Command Line Interface (CLI) ..........25 4.5.1 Connecting to the Radio..................25 4.5.2 CLI construction ....................26 Appendix A – Specifications ......................31 Physical Specifications ....................31 System Specifications ....................31 Interfaces........................

  • Page 11: Section 1 - Introduction

    Section 1 - Introduction Introduction to Exalt Communications Exalt Communications Inc. wishes to thank you for your purchase of the EX-2.4i Digital Microwave Radio. Our charter is to build the highest quality, highest reliability products that meet or exceed all of your expectations. This commitment to quality and reliability extends to our employees and partners as well.

  • Page 12: Ex-2.4I Basic Features

    Engineering and Site Planning of Terrestrial Wireless Links” for detailed information on these activities. The EX-2.4i utilizes radio frequencies in the range of 2400 to 2483.5MHz. In most countries this frequency band is considered as ‘license-exempt’ or ‘unlicensed.’ This means that virtually any user may use these frequencies freely, without paying for access, or any type of pre-notification, post-notification or registration.

  • Page 13: Figure 1-2: Indoor Radio Mount Interconnection

    RF connector of the EX-2.4i. In turn, the communications interfaces and power connections are directly applied to the EX-2.4i, or in some cases, also with an egress through the structure or radio enclosure with proper lightning or surge suppression devices and associated grounding.
  • Page 14 Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual The EX-2.4i provides the following features and benefits: • Computer-free link initiation for fast system initiation • Low-latency optimization for voice and data connections • Very high throughput and flexible interface configuration with voice+data combinations •...

  • Page 15: Section 2 - Before Installation

    • Radio grounding • Anticipated Received Signal Level (RSL) at each end With respect to radio path and site planning, the EX-2.4i is generally identical to any other microwave terrestrial wireless system. Engineering of these systems may not require significant specific knowledge about the EX-2.4i itself.

  • Page 16: Rf Output Power Setting

    Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual o RF link can connect in both directions o Traffic can be passed across the link • Configure connected equipment and cabling o Test Ethernet (CAT5) cabling, and/or T1/E1/DS3 cabling, any auxiliary connector...

  • Page 17: United States

    4.3. 2.2.1 United States The EX-2.4i operates under FCC Rule Parts 15.247 as a license-exempt device, and must be professionally installed. It may only be used as a point-to-point transmission device for fixed or temporary-fixed (non-mobile) installations. The device is subject to the following restrictions: •...

  • Page 18: Canada

    Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual 2.2.2 Canada The EX-2.4i operates under RSS-210 of Industry Canada regulations. Operation is subject to the following conditions, unless express permission is granted by Industry Canada to operate in a different manner: •...

  • Page 19: Section 3 - System Installation And Initiation Process

    Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual Section 3 - System Installation and Initiation Process This section briefly describes the process for system initiation and turn-up. Outline of Tasks The process of radio installation and initiation is outlined here.
  • Page 20 Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual • Designed RSL per original design • RSL reading with far-end power off • Spectrum analyzer plot with far end off • VSWR/Return Loss at Radio’s antenna connector • Radio’s network management IP address •...

  • Page 21: Section 4 - Installation And Configuration

    Section 4 - Installation and Configuration Mechanical Configuration and Mounting The EX-2.4i is a one-piece radio design intended for deployment in a telecom equipment rack indoors or in an appropriate environmental enclosure. The device must be deployed within an ambient temperature range as specified and properly ventilated with no obstructions to the air intake and exhaust.

  • Page 22: Wall Mounting The System

    Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual If mounting in a 23-inch rack, the rack mount extensions must be affixed to the standard rack brackets. Simply attach these extensions using the screws supplied. Figure 4-2: 23-inch Rack Mount 4.0.2 Wall Mounting the System If mounting on a wall, a wall-mount kit is required.

  • Page 23: Connector Overview

    T1/E1 ANTENNA - ++ - MAIN Figure 4-4: Front Panel 4.1.1 Connector Overview The following table provides detail of the connectors on the front panel of the EX-2.4i. Label Type Gender Function Antenna Transmission line connection to antenna Primary ports for User DS3 circuits to traverse link...
  • Page 24 Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual Red Blink = No remote information available Off = System is not properly powered/system failure Status 3-color Indicates system status: Green Solid = No alarm conditions (normal operation) Yellow Solid = Alarm conditions, not traffic effecting...

  • Page 25: Control Overview

    Indicators 4.1.3 Control Overview There is only one external control on the EX-2.4i, a button labeled “RMT” (Remote). This button allows the user to easily and quickly evaluate the status of the remote end radio. Press and hold the button and, while held, all local end status LEDs (Link, Status, T1/E1, DS3) represent the status of the LEDs on the remote end radio.

  • Page 26: Ac Power

    Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual • Connect a fixed (or a series of fixed) 50-ohm attenuator(s) to the RF connector, either directly or at the end of an RF transmission line. The attenuator should be at least 20dB as specified at 2400 MHz, and rated for a minimum of 1W input power.

  • Page 27: Dc Power

    Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual can be significant. In some cases, there can also be a risk to human life by not protecting against lightning entering a building through wiring or improper grounding. If you do not have experience in this type of installation practice, it is strongly suggested that a qualified electrician and/or telecoms professional is consulted during the installation of the equipment and wiring.

  • Page 28: Backup Or Emergency Power

    In addition to traditional backup power systems, such as battery supply, UPS or generator-driven central supply, the EX-2.4i is designed to accommodate a multi-source DC supply, if desired, for backup power source connection. If your primary source of power is not backed up directly, you can alternatively connect a second source of power supply to a second set of pins on the DC connector.

  • Page 29: Table 4-3: Recommended Antennas

    Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual The following list of antennas is recommended in conjunction with this product. In some countries, antennas exceeding a certain level of gain may be unlawful. Refer to section 2.2 for details on regulatory limits.

  • Page 30: Initial Antenna Mounting

    Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual 4.3.1 Initial Antenna Mounting The antenna should be the exact model recommended by the path and site planning engineer(s). The antenna should be mounted at the proper height, mast/mounting location and polarization orientation also as determined by the path and site planning engineer(s).

  • Page 31: Transmission Line From Antenna To Egress

    Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual measures can be taken to keep the connector clear. Extra care must be taken if the antenna is installed during inclement weather to be certain that no moisture gets inside the antenna connector at any time.
  • Page 32 Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual connectors. For waveguide, the waveguide flange can typically accommodate a direct adapter to an N connector, or alternatively, the antenna can be purchased with a direct waveguide connection. But often a flexible coaxial jumper is needed to connect between the waveguide to the antenna, as waveguide is generally inflexible and can be mechanically challenging to align to the exact antenna connector location.

  • Page 33: Rf Lightning Arrestor

    Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual Once again, a drip loop may be required, and proper securing hardware and grounding needs to be accommodated. As soon as practical, the connected ends of the transmission line to the antenna and lightning arrestor should be weatherproofed.

  • Page 34: Antenna Alignment

    Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual needed to allow for ease of connection to the radio’s RF connector. A properly specified 90- degree connector can often eliminate this need. Or an installation with space accommodated around the radio for a gentle bend radius of the transmission line can also accommodate a direct connection.

  • Page 35: Configuration Using The Command Line Interface (Cli)

    Configuration Using the Command Line Interface (CLI) The EX-2.4i utilizes a CLI as the primary user interface for configuration and management of the system. The Console port may be used for serial devices, or the Ethernet MAIN or AUX ports may be used for a Telnet session over a network connection.

  • Page 36: Cli Construction

    • Enter the following at the command line of the command prompt window: C:\>Telnet <IP Address> Note: The default IP address of the EX-2.4i is 10.0.0.1 Note: You may reset the default address through serial CLI or by radio reset (as described in section 4.1.3)
  • Page 37 Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual The CLI number sequence is not often used, but can be helpful for writing command scripts to pre-configure radios, or get a series of values from the device for management or monitoring.
  • Page 38 Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual 9. Help 4.5.2.2 The Configuration menu The following list is an illustration of the tree structure of the configuration menu. 1. Configuration/Status <menu> 1. Configuration wizard, 1.1, <configwiz> 2. IP setting 1.2, <IPconfig>...
  • Page 39 Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual 4. Set DS3 Line Code, 1.4.1.4.4, [setDS3code A:B:H] (A=AMI, B=B3ZS, H=HDB3) 5. Display All Interface Configuration, 1.4.1.5 <dispconfigall> 2. System Configuration, 1.4.2, <configsys> 1. Transmit Power, 1.4.2.1, <pwr> 1. Display Transmit Power, 1.4.2.1.1, <disppwr>...
  • Page 40 Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual 3. File Transfer, 1.4.3.3 <file> 1. Download Configuration File from Radio, 1.4.3.3.1, [downloadconfig c:\\directory\filename.cfg] 2. Upload Radio Boot Software to Radio, 1.4.3.3.2, [uploadboot c:\\directory\filename.bot] 3. Upload Radio Application Software to Radio, 1.4.3.3.3, [uploadapp c:\\directory\filename.app]...

  • Page 41: Appendix A - Specifications

    Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual Appendix A – Specifications Physical Specifications Physical Configuration Single-piece Indoor Unit (IDU) Dimensions (H x W x D) 1RU: 1.75 x 17 x 14 inches; 4.5 x 43.2 x 35.6 cm Weight 8 pounds;...

  • Page 42: Interfaces

    Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual IC ID 6254A-102P40I Emission Designator(s) QPSK 16QAM 64QAM 8MHz 10M2W7D 9M9W7D 10M2W7D 16MHz 17M3W7D 19M0W7D 20M2W7D 32MHz 34M7W7D 36M0W7D 38M1W7D 64MHz 60M7W7D 61M3W7D 61M7W7D Interfaces Connector N-type Female Impedance 50 ohms T1/E1 (x4)
  • Page 43 Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual Sync (In and Out) Connector RJ45, Female Signal 1pps (GPS) Power Connector 6-pin barrier strip Input Voltage 40-60Vdc Consumption <0.7A @ 48V (<34 Watts) Page 33 MAN-002400, Revision 001 2005-12-01...

  • Page 44: Appendix B - Back-To-Back Testing

    Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual Appendix B - Back-to-back Testing Introduction Back-to-back testing is used to bench test the radio before installation, pre-configure the radio and connected equipment before installation, or in the trouble-shooting process to identify if the radio hardware is the source of a system issue.

  • Page 45: Specification Performance Verification

    Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual RF Ports Console Port Attenuation Radio Radio (60-90dB) Serial Port Power Power Computer (connect last) (connect last) Figure B-1: Basic Back-to-Back Test Configuration After connecting and powering one, the front panel LEDs can be observed to verify that the Link and Status LEDs are both green.
  • Page 46 Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual In this test, it is highly desirable to RF cables that are pre-tested, known good and known loss at the operating frequency. If the cables are short (in the range of 6 feet or less), you can estimate the loss, including connectors, to be less than 1dB each.
  • Page 47 Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual system gain performance – however, any combination of settings may be tried to gain confidence in the radio performance parameters. Page 37 MAN-002400, Revision 001 2005-12-01...

  • Page 48: Appendix C - Dc Coupler For Antenna Alignment

    Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual Appendix C - DC Coupler for Antenna Alignment Introduction One challenge associated with an all-indoors radio construction is the alignment of the antennas. It can sometimes be challenging to place the radio near the antenna alignment personnel, and can also be challenging to run a separate set of wires for the voltmeter to be in view of the alignment personnel.

  • Page 49: Figure C-1: Dc Coupler Interconnection

    Exalt Communications Inc. EX-2.4i Installation and Maintenance Manual Coupler (DC side toward radio) Antenna Primary Transmission Line Jumper cable or adapter (in place of lightning arrestor) Structure Penetration Secondary Transmission Line Coupler (DC side toward antenna) Radio To RSL port...
