Indicators
Use the following primary indicators to determine link status and radio alarm status. Refer to the
I&M manual for details on other indicators and troubleshooting information.
LINK
3-color
Indicates RF link status:
LED
Green Solid = Error-free connection (BER<10e-6)
Yellow Solid = Errored connection (10e-3>BER >10e-6)
Red Solid = No link (BER>10e-3)
Red Flashing = No remote information available (when RMT button is pressed and held)
Off = Improperly powered or fatal system failure
STATUS
3-color
Indicates system status:
LED
Green Solid = No alarm conditions (normal operation)
Yellow Solid = Alarm conditions, not traffic effecting
Red Solid = Alarm conditions, traffic effecting
Red Flashing = No remote information available (when RMT button is pressed and held)
Off = Improperly powered or fatal system failure
RADIO
3-color
Indicates radio orientation:
A
LED
Green Solid = Radio is configured as Radio A (source), based on software setting (desired)
Green Flashing = Radio is configured as Radio A (source), based on temporary hardware
configuration key or DIP switch
Off = Radio is configured as Radio B
Register the Product
Register the product to obtain full benefits of the warranty. Products registered within 90 days of
purchase receive 2 full years of warranty coverage for no extra charge. Unregistered products and
products registered after the 90-day period, only receive a 1-year warranty. Register the product
according to the instructions on the provided registration card. See the I&M manual for the full
warranty statement.
For More Information
Refer to the I&M manual, which can be downloaded from the radio or from the Internet at:
http://www.exaltcom.com/support/downloads.htm
user ID: go_exalt; password: wexmaltux
If you require support, contact Exalt Customer Care:
Phone: (408) 871-9890
Toll-Free (USA): (877) EXALT-01 (392-5801)
Support email:
support@exaltcom.com
Sales email:
sales@exaltcom.com
Exalt Communications, Inc.
580 Division St.
Campbell, CA 95008 USA
(408) 871-1804
www.exaltcom.com
© 2007 Exalt Communications, Inc. All rights reserved.
201131
7
2007-10-10
Digital Microwave Radios
Quick Start Guide
Part Number: 201131
2007-10-10
i-Series
Models:
EX-2.4i
EX-2.4i-16
EX-4.9i
EX-5i
EX-5i-16
EX-5i-DS3
