IMPORTANT NOTES This guide is an aid for the professional installation of the device. Please note the following notes before installation: • Always handle all parts of the device and the components of your vehicle with care. • Under all circumstances observe the regulations of the vehicle manufacturer and do not make any changes to the vehicle which could impair driving safety.
RECOMMENDED TOOLS: Ø 20 mm Plastic drill Plastic mounting wedges Unlock devices Phillips screwdriver or bit Cable ties Torx screwdriver or bit RECOMMENDED ACCESSORIES: Steering wheel control adapters: VNA-LFB-FD2 FIAT DUCATO IV, PEUGEOT BOXER III, CITROËN JUMPER III (Type 290, since 2015) with radio preparation, ISO connection VNA-LFB-FD3 FIAT DUCATO IV, PEUGEOT BOXER III, CITROËN JUMPER III (Type 290, since...
INSTALLATION GUIDE Only with radio ex-factory: Only with radio ex-factory: Pull the radio out of the slot Remove the connectors on the back of the radio. using the release tools. Only with radio ex-factory: Loosen the 2 screws underneath. Loosen the 4 screws. Open the storage tray and loosen the 2 Pull the storage tray upwards.
Page 5
INSTALLATION GUIDE Loosen the 2 screws underneath. Remove the ventilation ducts on the left and right with a screwdriver and leverage as shown. The dashboard should now look like this. Loosen the 2 screws. Lift the rubber tray and remove the screw underneath.
Page 6
INSTALLATION GUIDE Remove the original panel. Release the plugs. Remove the original panel Loosen the 2 screws. by lifting it and pulling it forward. PRELIMINARY...
Page 7
INSTALLATION GUIDE Remove all marked clips from the Loosen the 2 screws. original panel and attach them to the supplied enclosed panel. Pull the cover out from back to top (as Loosen the 2 screws and put the speedome- shown). ter display on top (The plugs can stay).
Page 8
INSTALLATION GUIDE Then install the supplied enclosed panel, Pay attention to the GPS cable and fasten the where the GPS antenna is integrated. 2 screws. Then insert the cable of the GPS antenna to the device and connect it to the GPS socket as described on page 14.
Page 9
Lay the OBD connection cable. Lay the microphone cable as shown. (like shown) (Picture shows cable with factory installed radio) (Picture shows cable without factory installed radio) Connect the respective cables to the ESX device as described on page 10. * Optional accessories...
Page 10
INSTALLATION GUIDE Put in the speedometer display and the cover. Slide the ESX device into the slot. Attach the screws. ESX device after the installation. Attach the screw and set in the rubber tray.
Press on the desired function on the screen and then on the regarding button on the multifunc- tion steering wheel via which this function is to be controlled. After you have successfully assigned a function, the field is highlighted. Restart and turn on/off the ESX device Restart Press and hold the multifunction button for 10 seconds.
SCOPE OF DELIVERY ITEM IMAGE AMOUNT Main Device Panel incl. GPS Antenna MicroSD Memory Card 8 GB Navigation Software Remote Controller Microphone Antenna Splitter (active) for FM/DAB + Radio Reception...
Page 13
SCOPE OF DELIVERY ITEM IMAGE AMOUNT Audio Cables Camera/AUX/Video Cables Video Cables USB Extension System Cable Steering Wheel Control Adapter...
Page 15
WIRING DIAGRAM Steering CVBS-IN AMP TURN wheel control VEHICLE Currently without use ANTENNA OPTIONAL + 12 V ANTENNA SPLITTER (ACTIVE) FOR FM/DAB + RADIO RECEPTION...
