- Page 1 WIRELESS-FLOW-SENSOR Hunter Wireless-Flow-Sync Owner’s Manual and Installation Guide Wireless Flow Sensor for Use with Compatible Hunter Controllers...
-
Page 2: Table Of Contents
WFS COMPONENTS ......................4 SYSTEM OVERVIEW AND WFS OPERATION ..............6 INSTALLING THE WFS SENSOR & FCT TEE ..............8 INSTALLING THE WFS SENSOR INTO THE FCT FITTING ..........12 CONNECTING THE WFS TO THE IRRIGATION SYSTEM ..........14 SYSTEM CONSIDERATIONS ....................17 TROUBLESHOOTING GUIDE ..................20... -
Page 3: Introduction
With proper setup at the controller, this allows the controller to record and report actual flow in liters or gallons. Flow learning controllers can also use WFS to learn typical flow for each zone of irrigation, and monitor during watering for high and low flow conditions. -
Page 4: Wfs Components
WFS COMPONENTS This section will give you a brief overview of some of the components of the Wireless-Flow-Sync system. Impeller: Rotates when flow is occurring O-rings: Provides sealing of sensor in sensor body Wire: Black wire connects to the sensor... - Page 5 WFS TEE ASSEMBLY Flow-Sync Tee: The Tee is installed into the irrigation system and houses the WFS O-rings: Provides sealing of plug in sensor body Plug: (replace with WFS at Installation) Cap: To seal plug to Flow-Sync-Tee...
-
Page 6: System Overview And Wfs Operation
SYSTEM OVERVIEW AND WFS OPERATION The WFS is typically installed near the point of almost always installed in conjunction with a connection, in an appropriately-sized FCT Tee. Master Valve, which can stop flow in a damaged pipe when high flow conditions are detected. - Page 7 ® WFS I-CORE WIRING...
-
Page 8: Installing The Wfs Sensor & Fct Tee
INSTALLING THE WFS SENSOR AND FCT TEE The WFS Sensor is designed to install within an For international applications, optional slip-BSP FCT tee fitting, sized for the pipe in which it will adapters are available separately for sizes up to be installed. - Page 9 10 times the diameter of the pipe upstream to the impeller. from the WFS (toward the water supply). • Always install WFS together with a Master • There must be a length of straight pipe at least Valve, to provide overflow protection.
- Page 10 Metric thread adapters are available and are irrigation valve box. listed in this manual on page 8. • WFS has an impeller which will turn in the flow Avoid excess glue when attaching of water. If the water source is not a public fittings.
- Page 11 EXAMPLE OF INSTALL *NOTE: Not to scale.
-
Page 12: Installing The Wfs Sensor Into The Fct Fitting
INSTALLING THE WFS SENSOR INTO THE FCT FITTING The FCT tee fitting comes with a plug that allows To install the sensor into the body: for installation of the FCT into the irrigation Turn the system pressure off. system prior to installing the Sensor. This allows the FCT tee to be installed separately from the Unscrew the cap from the top of the FCT (figure 1). - Page 13 INSTALLING THE WFS SENSOR INTO THE FCT FITTING 5. Hand tighten the WFS sensor cap. (figure 3). NOTE: Never glue the HFS sensor into the fitting! The threaded cap is designed to seal under pressure Figure 1 Figure 2 Figure 2...
-
Page 14: Connecting The Wfs To The Irrigation System
Do not install in high-voltage 110V or 230V circuits. WFS has one wire lead which leads to the transmitter. The transmitter may be placed up to 500ft/152m from the controller. Connecting the Receiver... - Page 15 ® ACC & I-CORE INSTALLATION ACC Controller I-Core Controller Use terminals S1 or S2...
- Page 16 WFS is primarily designed to shut off the irriga- ism. The following may be helpful in making your tion system in the event of a catastrophic system WFS operate at its optimum level.
-
Page 17: System Considerations
SYSTEM CONSIDERATIONS Working With WFS Hunter flow-capable controllers are designed active stations, to see if there is an unacceptable to measure and record actual flow, shut off difference, indicating a leak or break. irrigation when a high flow condition occurs, and Consult the controller documentation closely for identify which stations caused the condition. - Page 18 Some water sources may have varying pressure Additionally, excess air in irrigation piping causes depending upon the demand for water upstream the WFS impeller to spin freely during of the point of connection. During times of heavy station startup, which may cause temporarily demand, system pressure through the mainline high readings.
- Page 19 Proper System Maintenance and Operation It is important that your irrigation system be maintained and is functioning properly for optimum performance. Check your irrigation system for any broken components or leaks also, making sure that all sprinklers are operating within the pressure ranges recommended by the manufacturer.
- Page 20 Hunter controllers equipped with flow terminals When flow begins, the voltage will pulse. On a will have approximately 20 VDC present on the standard voltmeter, the voltage will appear to flow sensor terminals, with no flow input. drop, or pulsate. On voltmeters equipped with a frequency counter, the pulse frequency can be measured in Hz.
-
Page 21: Troubleshooting Guide
Controller not configured Check controller flow sensor setup. Enter sensor size (and location, for sensor decoders) and other sensor information as required. Damaged sensor- Impeller damage Replace sensor. (debris in water) or WFS electronics damage (lightning) - Page 22 TROUBLESHOOTING Problem Cause Solution WFS not reading correctly Controller configured incorrectly Set correct flow sensor size and type at controller. Turbulent flow at sensor Insure that straight pipe is on either side of flow meter. Frequent false alarms Station settings too sensitive Increase overflow percentage (and underflow if available).
-
Page 23: Specifications And Calibration
SPECIFICATIONS Flow Range Operating Specifications Flow-Sync Operating Range (Gpm) Temperature Pressures Humidity Sensor 0 to 140ºF/60ºC up to 200 psi/13.7 bar up to 100% Minimum* Suggested Maximum** Diameter 1" 1½" 2" 3" 4" Minimum recommended flow for the highest flow zone for your system Good design practice dictates the maximum flow not to exceed 5ft/sec. - Page 24 FCT TEE FITTING SPECS. Maximum Distance Between WFS Transmitter and Receiver 500ft/152m Dimensions Straight Pipe Straight Pipe FCT Tee Fitting Height Width Length upstream (Ø x 10) downstream (Ø x 5) FCT 100 4.8″/12 cm 2.3"/6 cm 4.5"/11 cm 10"/25 cm 5"/13 cm...
- Page 25 WFS Calibration Factors Flow Sensor Values Hunter controllers allow selection of the correct Hunter Flow Sensor K-Factor Offset pipe size by FCT model number. No further HFSFCT100 0.44 0.39 HFSFCT150 1.13 0.00 calibration is needed. HFSFCT158 0.92 1.22 HFSFCT200 2.13 0.23...
- Page 27 FCC Notice: This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 28 RESIDENTIAL & COMMERCIAL | Built on Innovation ® 1940 Diamond Street | San Marcos, California 92078 USA © 2016 Hunter Industries Incorporated Learn more. Visit hunterindustries.com LIT-699-OM-WFS-US A 6/16...
