TOOLS NEEDED
Cloth
PARTS
[228-1015]
[216-1120]
Sink Box
Sink Hardware Bag
[203-1337]
(4) Acorn Nut
[1193643]
(4) Bracket
(not needed
Sink
[210-1100]
[207-1065]
[203-1335]
for this model)
Stone Top
(2, 4, or 6) Bracket
Silicone Sealant
(4) #10-24 x 1.5" Screw
[216-1073]
[VM2SKH2D21##]
Mounting Hardware Bag
Side kit
[203-1256]
(4) 5/16" x 2-1/2"
Structural Bolt
(1) 24", 30", or 36" Cartesian frame
(1) Drawer front
[SS674]
[203-1270]
30" shown here
Side kit
(5) #10 x 2" Screw
T-30 Driver
24", 30", or 36" Plumbing Drawer
[216-1074]
Drawer front Hardware Bag
[203-1219]
(4) #8-32 x 1/2" Screw
[202-1179]
(1) Glass Center Bin
[211-1095]
[203-1198]
(4) Washer
(2) Screw cover
[225-1039] = 24" [225-1040] = 30" [225-1041] = 36"
Divider Set Plumbing Drawer
[211-1098]
[211-1073]
(4) Divider Clip Shoe
Divider Glass
(4) Divider Clip
Part no. 209-1274-rA rev. 06/06/17
Curated Cartesian H2
© 2017 Robern, Inc. 701 N. Wilson Ave. Bristol, PA 19007 U.S.A.
800.877.2376
www.robern.com
2
Installation instructions
