Normal Operation Display

Press and hold 'Enter' key to enter the program menu or get to the security menu. Then use the "Enter"
key to move right from Main Menu to Sub Menu to the Adjustable Setting. Use the "Back" key to move left.
Main Menu
Power Settings
Frequency Settings
Timer Settings
I/O Interface
Diagnostics
Security
Defaults
Language
Status Line Message
CFR Set Point
Amplitude
Frequency
The normal operating display shows the status of the control with regard to input signals and control settings. They are
listed from highest to lowest in priority. The highest priority message takes precedence over the other messages.
Stop/Run - The 1/0 button has been pushed to disable control operation.
Override - The 1/0 button has been pushed and held so the control feeds while ignoring the "Sensor" or "Run" inputs.
Run Input - The run jumper has not been not made.
Parts Sens - The parts sensor and control logic is telling the control to stay off.
Empty/jam - Empty bowl timer has timed out because parts did not pass by the parts sensor to reset the timer.
Analog - An external signal is in control of the speed input.
Low - Low Speed used when 2 speed has been selected and the sensor is not made.
Zero Speed - The output is off because the output is set to 0.0%.
Run – The feeder is running normally.
Run/CFR – Constant Feed Rate sensor is regulating the feed rate (Autotune®).
Control Menu Layout for VF-3, VF-9
Sub Menu
Amplitude
Max Amplitude
Min Amplitude
Soft Start Time
Amplitude Source
CFR Positive Gain
CFR Negative Gain
Frequency
Max Frequency
Min Frequency
Frequency Mode
Auto Scan
Resonate Threshold Level [ 200 Default ]
Auto Track Dead Band
On Delay
Off Delay
Empty Bowl Timer
Sensor Polarity
Sensor Type
Run Mode
Empty Bowl
Aux Output Mode
Software Version
Accelerometer
Over Amps
DC Volts
Internal Temperature
Keypad Lock
Security Code
Restore Settings 1
Restore Settings 2
Restore Settings 3
Save Settings 1
Save Settings 2
Save Settings 3
Factory Reset
Pick Language
Normal Display Message Priority
Run/CFR
CFR=024.5
A= 40.0%
F= 60.0Hz
Adjustable Setting
[ 0.0 to 100.0 ] %
[ 100.0 to 40.0 ] %
[ 0.0 to 95.0 ] %
[ 0.0 to 10.0 ] Seconds (0.5 Default)
[ Auto Tracking Manual, 0-10V, 4-20mA,]
[ 25 Default ]
[ 5 Default ]
[ 5.0 to 300.0 ] Hz (60.0 Hertz Default)
[ 15.0 to 300.0 ] Hz (140.0 Hertz Default)
[ 5.0 to 290.0 ] Hz (45.0 Hertz Default)
[ Auto Tracking, Manual ]
[ Press ENTER to perform an automatic frequency scan ]
[ 64 Default ]
[ 0.0 to 20.0 ] Seconds (0.5 Default)
[ 0.0 to 20.0 ] Seconds (0.5 Default)
[ 5 to 255 ] Seconds (10 Default)
[ Inverted, Normal ]
[ Auto, NPN, PNP ]
[ Normal, Always On, 2-Speed, High/Low ]
[ Normal, Stop ]
[ Normal, Inverted, Alarm, Inv Alarm, Air Jet ]
[ Software Revision Level ]
[ data ]
[ data, data ]
[ data ]
[ data ] °C
[ Unlocked, Amplitude Only, Locked ]
[ 000 to 999 ]
[ 'Enter' Restores User Settings 1 ]
[ 'Enter' Restores User Settings 2 ]
[ 'Enter' Restores User Settings 3 ]
[ 'Enter' Saves User Settings 1 ]
[ 'Enter' Saves User Settings 2 ]
[ 'Enter' Saves User Settings 3]
[ 'Enter' Resets Control to Factory Default Settings (Shown in bold) ]
[ , Español (Spanish), Français (French), Deutsch (German) ]
English
R=1 Run Input: 1= on /closed & 0= off/open
Sensor Input: 1= on /closed & 0= off/open
S=1
Output to vibratory feeder: 1= on & 0= off
O=1
A=1 Aux Output: 1= on & 0= off
VF-3-9 Menu Ver1_28.doc 10/30/2013
