- Page 1 USER MANUAL VSW-HDMI2-3X1 HDMI 2.0 VIDEO SWITCH — 3 X 1 24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM IR EXT. HDMI OUT DC 5V HDMI IN1 HDMI IN2 HDMI IN3...
-
Page 2: Table Of Contents
4.2 IR Remote Control ....................................11 4.3 Automatic Switch Control ..................................12 5. TROUBLESHOOTING ................................... 13 5.1 Troubleshooting Steps ................................... 13 5.2 Contacting Black Box .....................................13 APPENDIX A. REGULATORY INFORMATION ..........................14 A.1 FCC Statement .......................................14 A.2 NOM Statement ..................................... 15 APPENDIX B. -
Page 3: Important Safety Instructions
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 IMPORTANT SAFETY INSTRUCTIONS TECHNICAL SUPPORT 1.877.877.2269 1. Do not expose this apparatus to rain, moisture, dripping or splashing liquids. Do not place any objects filled with liquids, such as vases, on the apparatus. -
Page 4: Specifications
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 1: SPECIFICATIONS TECHNICAL SUPPORT 1.877.877.2269 TABLE 1-1. SPECIFICATIONS SPECIFICATION DESCRIPTION Video Input (3) HDMI Type A female Output (1) HDMI Type A female Input/Output Signal Type HDMI with 4K VESA: 640 x 480, 800 x 600, 1024 x 768, 1280 x 768, 1280 x 800, 1280 x 960, 1280 x 1024, 1360 x 768, 1366 x 768, Input/Output Resolution 1400 x 1050, 1440 x 900, 1600 x 900, 1600 x 1200, 1680 x 1050, 1920 x 1200, Support... -
Page 5: Overview
Š Supports locking HDMI cables to prevent accidental cable disconnects Š 2.3 WHAT’S INCLUDED Your package should include the following items. If anything is missing or damaged, contact Black Box Technical Support at 877-877-2269 or info@blackbox.com VSW-HDMI2-3X1 includes: Š (1) HDMI 2.0 Video Switch — 4K60, HDCP, 3 x 1 Š... -
Page 6: Hardware Description
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: OVERVIEW TECHNICAL SUPPORT 1.877.877.2269 2.4 HARDWARE DESCRIPTION 2.4.1 TOP PANEL Figure 2-1 shows the top panel of the switch. Table 2-1 describes its components. POWER SWITCH HDMI IN HDMI OUT POWER FIGURE 2-1. -
Page 7: Front Panel
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: OVERVIEW TECHNICAL SUPPORT 1.877.877.2269 2.4.2 FRONT PANEL Figures 2-2 shows the front panel of the switch. Table 2-2 describes its components. IR EXT. HDMI OUT DC 5V FIGURE 2-2. SWITCH FRONT PANEL TABLE 2-2. -
Page 8: Back Panel
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: OVERVIEW TECHNICAL SUPPORT 1.877.877.2269 2.4.3 BACK PANEL Figures 2-3 shows the back panel of the switch. Table 2-3 describes its components. HDMI IN1 HDMI IN3 HDMI IN2 FIGURE 2-3. SWITCH BACK PANEL TABLE 2-3. -
Page 9: Installation And Wiring
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 3: INSTALLATION AND WIRING TECHNICAL SUPPORT 1.877.877.2269 3.1 INSTALLATION STEPS NOTE: Before installation, make sure the device is disconnected from the power source. Follow these steps: 1. Remove the four screws that secure the side panels to the device. FIGURE 3-1. -
Page 10: Wiring
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 3: INSTALLATION AND WIRING TECHNICAL SUPPORT 1.877.877.2269 3.2 WIRING WARNINGS: Before wiring, disconnect the power from all devices. During wiring, connect and disconnect the cables gently. Follow these steps: 1. Connect HDMI IN: Connect HDMI source devices to HDMI IN (1-3) of the switch using high-quality HDMI cables (e.g. -
Page 11: Control Of The Switch
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 4: CONTROL OF THE SWITCH TECHNICAL SUPPORT 1.877.877.2269 You can choose to control the HDMI 2.0 Video Switch at your convenience through the top panel button, IR remote or automatic switch function. -
Page 12: Automatic Switch Control
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 4: CONTROL OF THE SWITCH TECHNICAL SUPPORT 1.877.877.2269 TABLE 4-1. IR REMOTE CONTROL BUTTON FUNCTIONS BUTTON IR CODES DESCRIPTION 0X02 0X0A Switch to next active source input (Cycle 1 —> 3) 0X02 0X08 Switch to previous active source input (Cycle 3 —>... -
Page 13: Troubleshooting
If you determine that your switch is malfunctioning, do not attempt to alter or repair the unit. It contains no user-serviceable parts. Contact Black Box Technical Support at 877-877-2269 or info@blackbox.com. Before you do, make a record of the history of the problem. We will be able to provide more efficient and accurate assistance if you have a complete description, including: Š... -
Page 14: Appendix A. Regulatory Information
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 APPENDIX A: REGULATORY INFORMATION TECHNICAL SUPPORT 1.877.877.2269 A.1 FCC STATEMENT This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause inter ference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart B of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference when the equipment is operated in a commercial environment. -
Page 15: Nom Statement
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 APPENDIX A: REGULATORY INFORMATION TECHNICAL SUPPORT 1.877.877.2269 A.2 NOM STATEMENT 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura. 3. -
Page 16: Appendix B. Disclaimer/Trademarks
B.1 DISCLAIMER Black Box Corporation shall not be liable for damages of any kind, including, but not limited to, punitive, consequential or cost of cover damages, resulting from any errors in the product information or specifications set forth in this document and Black Box Corporation may revise this document at any time without notice. - Page 17 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 NOTES TECHNICAL SUPPORT 1.877.877.2269 ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ 1.877.877.2269 BLACKBOX.COM...
- Page 18 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 NOTES TECHNICAL SUPPORT 1.877.877.2269 ________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ _________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________\ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ 1.877.877.2269 BLACKBOX.COM...
- Page 19 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 NOTES TECHNICAL SUPPORT 1.877.877.2269 __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ _________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________\ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ 1.877.877.2269 BLACKBOX.COM...
- Page 20 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TECHNICAL SUPPORT 1.877.877.2269 © COPYRIGHT 2018 BLACK BOX CORPORATION. ALL RIGHTS RESERVED. VSW-HDMI2-3X1_USER_REV1.PDF...
