2 x 1 or 4 x 1 HDMI Switch 4K
Switch between two or four different HDMI sources
to a single display.
Supports up to 4 K (UHD) resolutions (3840 x 2160).
Automatically switches to a source when it becomes available.
Customer
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S.
Support
call 724-746-5500) • FREE technical support 24 hours a day, 7 days
Information
a week: Call 724-746-5500 or fax 724-746-0746 • Mailing address:
Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: info@blackbox.com
VSW-HDMI2X1-4K
VSW-HDMI4X1-4K
BLACK BOX
®
Advertisement
Table of Contents
Related Manuals for Black Box VSW-HDMI2X1-4K
Summary of Contents for Black Box VSW-HDMI2X1-4K
-
Page 1: Black Box
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. Support call 724-746-5500) • FREE technical support 24 hours a day, 7 days Information a week: Call 724-746-5500 or fax 724-746-0746 • Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Web site: www.blackbox.com • E-mail: info@blackbox.com... - Page 2 Trademarks Used in this Manual Trademarks Used in this Manual Black Box and the Double Diamond logo are registered trademarks of BB Technologies, Inc. Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.
-
Page 3: Instrucciones De Seguridad
FCC and IC RFI Statements/NOM Statement FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause inter ference to radio communication. - Page 4 NOM Statement 4. Todas las instrucciones de operación y uso deben ser seguidas. 5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc. 6.
- Page 5 NOM Statement 16. El cable de corriente deberá ser desconectado del cuando el equipo no sea usado por un largo periodo de tiempo. 17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean derramados sobre la cubierta u orificios de ventilación. 18.
-
Page 6: Table Of Contents
Introduction ..................9 Features ....................9 What's Included ................. 10 Hardware Description ................11 2.4.1 4 x 1 HDMI Switch 4K (VSW-HDMI2X1-4K) ......11 2.4.2 2 x 1 HDMI Switch 4K (VSW-HDMI4X1-4K) ......11 Installation ....................14 Device Connection ................14 Connection Pattern ................15 Operation ..................... -
Page 7: Specifications
25–297 MHz Material Steel Mode Configuration Switch/Autosensing/Priority/Matrix MTBF 50,000 hours Serial Control VSW-HDMI2X1-4K: Not applicable, VSW-HDMI4X1-4K: Yes, RJ-11 Signal Configuration Video: Auto/inventory, Audio: Auto/inventory User Controls (1) port selection switch button, (1) EDID Copy button, (1) EDID switch for EDID selection,... - Page 8 Chapter 1: Specifications Specifications (continued) Indicators VSW-HDMI2X1-4K: (2) LEDS for input status; VSW-HDMI4X1-4K: (4) LEDs for input status NOTE: Only one input LED is lit at a time. Environmental Temperature Tolerance: Operating: 32 to 104° F (0 to 40° C);...
-
Page 9: Overview
Chapter 2: Overview 2. Overview 2.1 Introduction The 2 x 1 or 4 x 1 HDMI Switch 4K enables users to quickly and easily share display devices (HDTV, Blu-ray player, HD-DVD, Xbox, Wii, PS3, satellite receiver, etc.) from your device inputs to one output device (monitor, projector, or TV). You can select the desired input source within the range of 16.4 feet (5 meters) via the remote control or push button located on the switch. -
Page 10: What's Included
• Read and store the EDID from the connecting display to the video extension. 2.3 What’s Included Both switches include: • 2 x 1 HDMI Switch 4K (VSW-HDMI2X1-4K) or 4 x 1 HDMI Switch 4K (VSW-HDMI4X1-4K) • Power adapter • IR remote controller •... -
Page 11: Hardware Description
Chapter 2: Overview 2.4 Hardware Description Figure 2-1. 4 x 1 switch front panel. Figure 2-2. 4 x 1 switch back panel. Figure 2-3. 4 x 1 switch top panel. 724-746-5500 | blackbox.com Page 11... - Page 12 Chapter 2: Overview Table 2-1. 2 x 1 and 4 x 1 switch components. Label in Component Description Fig. 2-1 and (1) Video Output connector Connect to an HDMI display Advanced Autosensing Switch/Auto-sensing/Priority Setting Switch mode setting Power Supply Apply power to the unit Serial Port Connect to a computer for serial control...
- Page 13 Chapter 2: Overview Audio/Video EDID Setting Switch See #7 in Figure 2-2 and Table 2-1. Table 2-2. Audio/video EDID setting switch functions. Mode Video Audio Auto Auto Auto Inventory Inventory Auto Inventory Inventory NOTE: For more operation details, refer to Chapter 4, Operation. Advanced Autosensing Setting Switch See #3 in Figure 2-1 and Table 2-1.
-
Page 14: Installation
Chapter 3: Installation 3. Installation WARNING: Before installation, power off all devices that will be connected to this system. Make sure that all devices you will connect are properly grounded. Place cables away from fluorescent lights, air conditioners, and machines that are likely to generate electrical noise. -
Page 15: Connection Pattern
Chapter 3: Installation 3.2 Connection Pattern PC tower Stereo Remote Media play Controller Figure 3-1. Connecting the 4 x 1 HDMI Switch 4K. 724-746-5500 | blackbox.com Page 15... -
Page 16: Operation
Chapter 4: Operation 4. Operation 4.1 LED Indicators LEDs 1–4 Figure 4-1. Top and front panel of the switch. Table 4-1. LED Indicators LEDs 1–4 Switch/Auto/Priority/Modes Status The selected LED emits green and The input video signal isn't ready. goes off 3 times per 2 seconds. The non-selected LED goes off. -
Page 17: Push Button Control
Chapter 4: Operation 4.2 Push Button Control 4.2.1 A/V Source Selection Press the pushbutton (#11 in Figure 2-3) once to select the source in sequence (S1—>S2—>S3—>S4—>S1…). The monitor immediately shows the video source once selected. The corresponding LED lights when the source is selected. 4.2.2 EDID Setting NOTE: Before starting, slide Audio/Video EDID Setting Switch (#7 in Figure 2-2) to position 2/3/4. -
Page 18: Edid Emulation
Chapter 4: Operation 4.2.3 EDID Emulation Slide the switch (#7 in Figure 2-2) to the desired position. Table 4-1. EDID emulation switch functions. Mode Video Audio Auto (Va) Auto (Va) Auto (Va) Inventory (Ai) Inventory (Vi) Auto (Aa) Inventory (Vi) Inventory (Ai) Va) Video Auto: Automatically use the EDID of the attached display (video algorithm). -
Page 19: Factory Default Setting
Chapter 4: Operation 4.2.5 Factory Default Setting To return all settings to factory state, press the BTN & EDID Copy button for 9 seconds and release right after 4 LEDs (L1–L4) flash green twice. BTN + EDID Copy (9 seconds)—>4 LEDs (L1–L4) flash green twice—>release 4.3 IR Remote Control A/V Source selection: Press 1/2/3/4: Select Source1/Source 2/Source/Source 4... -
Page 20: Serial Control
Chapter 5: Serial Control (4-Port model only) 5. Serial Control (4-Port model only) The Video Switch’s built-in serial interface allows users to control the Switch through a PC, serial controller devices, or home theater system. The controller’s serial port should be configured as shown below. Baud Rate: 38400 bps Data Bits: 8 Parity: None... - Page 21 NOTES 724-746-5500 | blackbox.com Page 21...
- Page 22 NOTES 724-746-5500 | blackbox.com Page 22...
- Page 23 NOTES 724-746-5500 | blackbox.com Page 23...
- Page 24 724-746-5500 or blackbox.com. About Black Box Black Box provides an extensive range of networking and infrastructure products. You’ll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 60 seconds or less.
