- Page 1 CSI-T51080-SP78 Installation Manual...
-
Page 3: Table Of Contents
Table Of Contents Product Registration Information......... 1 Document Purpose/Intended Users......1 Application............... 1 Safety Guidelines............1 Product Introduction............2 Product Features.......... 2 Special Installation Directions......2 System Block Diagram..........3 Product Specification..........4 RF Specifications.......... 4 Power Specifications........5 Mechanical Specifications......5 Environmental Specifications...... -
Page 5: Product Registration Information
DISCLAIMER: All information and statements contained herein are accurate to the best of the knowledge of Cellular Specialties, Inc. (CSI), but Cellular Specialties makes no warranty with respect there to, including without limitation any results that may be obtained from the products described herein or the infringement by such products of any proprietary rights of any persons. Use or application of such information or statements is at the users sole risk, without any liability on the part of Cellular Specialties, Inc. -
Page 6: Product Introduction
Product Introduction The SMR-700/800 Repeater has been developed for use within enclosed structures where signal from local cell sites to operate cell phones is poor or unavailable. Adequate signal must be available outside the structure as a prerequisite to achieving in-building coverage. The SMR-700/800 Repeater is connected to an external antenna, usually on the roof, and to one or more internal antennas placed strategically throughout the area where wireless service is desired. -
Page 7: System Block Diagram
Function Block diagram The function of the SMR-700/800 is as indicated in the block diagram above. • Multiplexer Block: combines several different frequencies into one or divides several different frequencies, combines and transfers the Network and iDEN A, or iDEN B, and transfers the DL and UL signal separately. -
Page 8: Product Specification
Product Specification RF Specification Item Specification 793-805MHz 806-816MHz Sub-Band1 817-824MHz Sub-Band2 FREQ. RANGE 763-775MHz 851-861MHz Sub-Band1 862-869 MHz Sub-Band2 Sub Band Tuning UL / DL 50KHz Step Size (From edge of Pass Band) Frequency Selectivity UL / DL @-40dBc _2MHz Gain UL / DL 80dB( _1.0dB) -
Page 9: Power Specifications
Power Specification Parameters Specifications Remarks Main Power Input Voltage 110VAC @ 1.3A Internal AD DC Power Supply Mechanical Specification Parameters Specifications Remarks Size (mm) 200 x 270 x 86.5mm(L x H x D) Link/Service Antenna Ports N - Female AC Power In AC Cord 1.5M Connectors Frame Ground... -
Page 10: Alarm Interface
Alarm Interface Repeater Unit LED Condition / Troubleshooting Power Alarm Power Supply is malfunctioning (inside repeater) Blinking Blinking Blinking Checking Isolation Status GREEN Solid Normal Condition at Start up GREEN Solid Insufficient distance (Isolation) exists between the DL and UL Antennae. Remove power and re-install the DL GREEN and UL Antennae to correct isolation problem. -
Page 11: Product Appearance
Product Appearance External Arrangement - 7 -... -
Page 12: Outline Drawing
Outline Drawing - 8 -... -
Page 13: Internal Arrangement
Internal Arrangement RF Board CPU Board GUI Port Display LED LED Holder Power supply - 9 -... -
Page 14: Psu
Power Supply Unit (PSU) The PSU converts the 110VAC line voltage to +24VDC and +6VDC The unit’s Power Supply Power Supply Specification Item Specifications Remarks Normal operation @ 90VAC ~ 140VAC < output Line Regulation Voltage + 3% Normal operation @ 24V 2A, 6V 2A Load Regulation <... -
Page 15: Gui(Graphic User Interface)
This program checks and controls the operation of the control board for the SMR-700/ 800. This program will be communicated via the control board and RS-232C Port. GUI Setup Begin the installation of the program with the file “CSI SMR Setup.exe”. Figure 1: Application program installation... - Page 16 When the screen in Figure 2 appears, Click “Next” Figure 2: Program installation application Decide which folder you wish to download into, then click “Next”. Figure 3: Program installation application - 12 -...
- Page 17 When ready to install program, click “Install”. Figure 4: Program installation application Figure 5: Ongoing program installation application - 13 -...
- Page 18 Click “Finish” when setup is complete Figure 6: Program installation complete screen Run Program(CSI_SMR.exe) You should see the CSI Icon listed on your startup menu as seen above. - 14 -...
-
Page 19: Open Serial Communication Port
Open Serial Communication Port Select communication port on your PC, then press “OPEN” to enable communication with repeater. Indicates the status of communication with the repeater. - 15 -... -
Page 20: Condition Check And Control
Checking status and control of the SMR-700/800 unit This screen indicates repeater status and control. You may check each by clinking on the control buttons shown below <Status Mode> <Control Mode> - 16 -... -
Page 21: System Status Mode
System Status Mode • Manufacture: Indicates the repeater’s manufacturer • Repeater Type: Indicates the model of repeater • S/W Version: Indicates the Firmware version of the control board • Temperature: Indicates the inner temperature of repeater Note: The SYSTEM pull-down menu is not part of the Control Menu. The System Status screen Normal Mode •... -
Page 22: Alarm Status Mode
Alarm Status Mode • PLL LD: Display Alarm (GREEN = Normal; RED = Alarm) • Isolation: Display Alarm (GREEN = Normal; RED = Alarm) • ShutDown(DL/UL): Display Alarm (GREEN = Normal; RED = Alarm) • DC FAIL: Display Alarm (GREEN = Normal; RED = Alarm) Note: The Alarm pull-down menu is not part of the Control Menu. -
Page 23: Isolation Status Mode
Isolation Status Mode • Isolation Value: When power is on, an Isolation check is performed, and the values displayed. • Isolation: The Isolation check can be performed with the power on or off. • Isolation Recheck: Checks Isolation without the power on. •... -
Page 24: Downlink
Downlink • Gain[dB](NetWork): Displays the NetWork Downlink Gain. • Atten[dB](NetWork): Displays the NetWork Downlink Attenuation value. • Gain[dB](iDEN): Displays the iDEN Downlink Gain. • Atten[dB](iDEN): Displays the iDEN Downlink Attenuation value. • ALC: This allows the user to toggle the Auto Level Control function on or off. •... -
Page 25: Uplink
Uplink • Gain[dB]: Displays the status of the Uplink Gain. • Atten[dB]: Displays the Uplink Attenuation value. • ALC Atten[dB]: Displays the attenuation value of a strong signal in the initial stage when unit is powered (Control unavailable). • ALC: This allows the user to toggle the Auto Level Control function on or off. •... -
Page 26: Frequency Information
Frequency Information Frequency offset: 931.300 MHz + 1 MHz (50 KHz Steps). Frequency Status Mode Frequency Control Mode Band Select • Band 1 On/Off: Activates Band 1 Frequency (Band 2 is deactivated). • Band 2 On/Off: Activates Band 2 Frequency (Band 1 is deactivated). Band Select Status Mode Band Select Control Mode - 22 -... -
Page 27: Shutdown Period
Shutdown Period Shutdown Period (M),(S): Allows the user to set the shutdown period duration. Shutdown Status Mode Shutdown Control Mode Control Send Control Send: When the unit is fully configured, the settings can then be sent to the repeater by clicking on the “CONTROL SEND” button. - 23 -... -
Page 28: Management Mode
Management Mode Press Ctrl + F10 while in Mode Status/Control Mode to go into Management Mode Management Mode Screen - 24 -... -
Page 29: Adc
Click the appropriate “LOAD” button to display the following: • DL Out: This displays the updated A/D value of DL Out. • UL Out: This displays the updated A/D value of UL Out under load. • Volt In: This displays the updated A/D value of the Input Voltage. •... -
Page 30: Isolation Re-Check
Isolation Re-Check • Isolation: This displays the status of the Isolation Re-Check function. • Load: This allows the user to toggle the Isolation Re-Check function display on or off. Attenuation The DL Atten is controlled thru the NetWork Atten and iDEN Atten settings; UL Atten is controlled thru the User Atten and ALC Atten settings. -
Page 31: Power & Temp & Atten Table
Power & Temp & Atten Table The POWER & TEMP & Atten table displays the applied decibel value for NetWork RSSI, iDEN RSSI, & UL Output. It does not display A/D values. Apply DL Out value for ISOLATION CHECK operation. •... -
Page 32: Debugging
Debugging To begin the debugging process, click the “Debug” button in management mode. This allows the user to check the data transferring between the repeater and the PC. • Go: This displays the comunications contents that have been suspended. • Stop: This command stops the contents of the communications from scrolling. -
Page 33: Downloading
Downloading To update the firmware, begin by clicking the “Download” button in management mode. Next, perform the following steps: • Click Open: Open the firmware binary file. The Binary File Open dialog box will open. • Download: Firmware download status will be displayed. The Download Complete message will open when the procedure is complete or an error message will be displayed. - Page 34 - 30 -...
-
Page 35: Product Warranty
One Year Limited Warranty Seller warrants that its products are transferred rightfully and with good title; that its products are free from any lawful security interest or other lien or encumbrance unknown to Buyer; and that for a period of one year from the date of installation or fifteen months from the date of original shipment, which- ever period expires first, such products will be free from defects in material and workmanship which arise under proper and normal use and service. - Page 36 D960-1048-001 rev002...
