Equipment Supplied - PS Engineering PAC45A Installation And Operation Instructions Manual

1.6

EQUIPMENT SUPPLIED

The following units comprise the PAC45A System:
Model
HUB45AR Remote-mounted Audio Hub for analog I/O and processing
CTL45A
CTL45A-M
CTL45A-NVG NVG Panel-mounted Control Head for pilot and copilot po-
CTL45M-NVG
PAC45A Installation Kit: 250-045-0801
Part Number Description
625-015-9215 Connector Backshell DB26 pin
625-037-9237 Connector Backshell DB62 pin
425-026-5601 Male Connector Shell DB26 pin
425-062-8177 Male Connector Shell DB62 pin
425-044-2043 Hi-density Male Pins
475-045-3341 Thumbscrew Kit for DB Connector
Part Number Description
625-015-9215 Connector Backshell DB26 pin
625-037-9237 Connector Backshell DB62 pin
425-026-1800 Female Connector Shell DB26 pin
425-062-4701 Female Connector Shell DB62 pin
425-030-7354 Hi-density Female Pins
475-045-3341 Thumbscrew Kit for DB Connector
Part Number Description
625-009-1724 Connector Backshell DB9 pin
425-009-0777 Male Connector Shell DB9 pin
425-020-5089 Standard Density Male Pins
475-045-3341 Thumbscrew Kit for DB Connector
CTL45 9-Pin Female Connector Kit 250-543-0100 ( J455)
Part Number Description
200-045-1000
Description
Control Head for pilot or copilot positions
Panel-mounted Control Head for Observers
sitions
NVG Panel-mounted Control Head for Observers
Male Connector Kit 250-045-8177 (P452, P454)
Female Connector Kit 250-045-8277 J451, J453)
9-Pin Connector Kit 250-045-0009 ( P455)
Page 1-3
MFR MFR PN
3M 3357-9215
3M 3357-9237
Harting 9562005601
Harting 9564005601
AMP 204370-2
3M 3341-7
MFR MFR PN
3M 3357-9215
3M 3357-9237
Norcomp 180-026-273L000
Harting 99564004701
Amphenol M39029/57-354
3M 3341-7
MFR MFR PN
3M 3357-9209
Amphenol L777-RR-E-09-P
Deutsch M39029/64-369
3M 3341-7
MFR MFR PN
Rev. 2, March 2019
Part Number
050-045-1001
050-045-2000
050-045-3000
050-045-4000
050-045-5000
Quantity
1
1
1
1
88
4
Quantity
1
1
1
1
88
4
Quantity
1
9
9
2
Quantity
