Product Activation; Cellular Gateway Activation - Lippert Components OneControl ConnectAnywhere Owner's Manual

Product Activation

Cellular Gateway Activation

NOTE: Figures 4-6 shown without additional cabling for clarity.
1.
Unplug the barrel connector power harness (Fig. 4A).
2. Remove the plastic SIM card adapter from the SIM card slot (Fig. 5A). Do NOT discard.
3. If using a standard size SIM card, insert the card into the card slot on the cellular gateway. Make sure
the SIM card's circuit is facing up and the card's notch is positioned in the upper right corner (Fig. 6A).
Fig. 4
A
4.
If using a nano SIM card, insert the nano SIM card into the SIM card adapter to create a standard SIM
card (Fig. 7).
Nano
SIM Card
Rev: 03.25.19
SIM Card
Adapter
Fig. 5
A
Fig. 7
Page 8
Fig. 6
A
Assembled
SIM Card
CCD-0001447
