EFG 535/540/545/550
01.04
G
Operating Instructions
52016502
07.08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EFG 535 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jungheinrich EFG 535

Summary of Contents for Jungheinrich EFG 535

  • Page 1 EFG 535/540/545/550 01.04 Operating Instructions 52016502 07.08...
  • Page 2 Used to indicate standard equipment. Used to indicate optional equipment. Our trucks are subject to ongoing development. Jungheinrich reserves the right to alter the design, equipment and technical features of the truck. No guarantee of particular features of the truck should therefore be inferred from the present operating instructions.

  • Page 4: Table Of Contents

    Table of Contents Correct Use and Application of the Truck Truck Description Application ................... B 1 Assemblies and Operational Description ..........B 2 Truck ....................B 3 Standard Version Specifications ............B 4 Performance data ................B 4 Weights (all weights in kg) ..............B 6 Tyres ....................
  • Page 5 Operation Safety Regulations for the Operation of Forklift Trucks ...... E 1 Controls and Displays ................. E 2 Instrument panel switches ..............E 6 Operating panel switches ..............E 6 Multi-function display ................E 7 Warning displays, buttons and switches ..........E 8 Displays ....................
  • Page 6 Maintenance of the forklift truck Operational safety and environmental protection ........ F 1 Maintenance Safety Regulations ............F 1 Servicing and inspection ..............F 3 EFG Maintenance Checklist ............... F 4 EFG lubrication schedule ..............F 7 Fuels, coolants and lubricants ............. F 8 Maintenance and Repairs ..............
  • Page 8 Appendix JH Traction Battery Operating Instructions These operating instructions apply only to Jungheinrich battery models. If using another brand, refer to the manufacturer's operating instructions.
