AS-Interface (AS-i)
Addressing the Saunders® M-VUE
Addressing the M-VUE can be performed with a standard AS-i Handheld programmer or by network configuration software. The
number of addresses depends on the AS-i version.
The default address for M-VUE is 0.
I/O and ID Parameters
I/O Code - is a hexadecimal code recorded on the AS-i chip, and determines a code to indicate the number of inputs and outputs
of the slave.
ID Code - This code also hexadecimal indicates a number of specifications and functions of the slave, called the PROFILE and is also
standardized by the AS- Interface association.
AS-Interface Versions
The sensor can be supplied in four versions:
M-VUE Code
ASI3.1
ASI3.2
ASI3.3
ASI3.1
* Replacement profile for existing installations
20 Crane ChemPharma & Energy

Addressing

ASi Version I/O
ASI v2.0
7h
Std address
ASI v2.1
7h
Ext address
ASI v3.0
7h
Ext address
ASI v2.0
7h
Std address*
ID ID1
0h Fh
Ah Fh
Ah Fh
Fh Fh
ID2 Address
Fh 7 0 F 2
7h 7 A F 7
7h 7 A F 7
Fh F F F 7h
