  • Page 1 ISL8282MEVAL1Z User’s Manual: Evaluation Board Industrial Analog and Power Rev.1.00 Jan 2019...

  • Page 2: Key Features

    PowerNavigator™ evaluation software from a PC running Microsoft Windows. The ISL8282MEVAL1Z can operate in Pin-Strap mode without needing the ZLUSBEVAL3Z adapter or PMBus communication. By default, the ISL8282MEVAL1Z is set to a 1V output voltage with a 400kHz switching frequency, 49 AV gain, and 200kΩ RR.

  • Page 3: Specifications

    ISL8282MEVAL1Z 1. Overview Specifications The ISL8282MEVAL1Z is configured and optimized for the following operating conditions: • V = 4.5V to 15V • V = 1V • I = 15A OUT-MAX • f = 400kHz • AV gain multiplier = 2x, AV gain = 49, RR = 200kΩ...

  • Page 4: Functional Description

    ISL8282M datasheet for typical application recommended values. (11) To change the soft-start ramp rate, RR, and AV gain multiplier, disconnect the ISL8282MEVAL1Z from the setup and populate 1% standard 0402 resistors at the R and R placeholder locations on the bottom layer.
  • Page 5 For best thermal performance, use enough trace width, copper weight, and proper connectors. The ISL8282MEVAL1Z is capable of operating at 15A full load current at room temperature without the need for additional cooling systems. However, if the ISL8282MEVAL1Z needs to operate at elevated ambient temperatures, the available output current needs to be derated.
  • Page 6 ISL8282MEVAL1Z 2. Functional Description Table 1. PROG 1 Resistor Reader PROG1 (DC) (kΩ) (kΩ) 49.9 12.4 0.500 45.3 12.7 0.508 42.2 13.3 0.516 38.3 13.3 0.523 35.7 13.7 0.531 14.3 0.539 31.6 14.7 0.547 29.4 0.555 15.4 0.562 26.7 16.2 0.570...
  • Page 7 ISL8282MEVAL1Z 2. Functional Description Table 1. PROG 1 Resistor Reader (Continued) PROG1 (DC) (kΩ) (kΩ) 54.9 35.7 0.812 52.3 37.4 0.820 49.9 38.3 0.828 47.5 39.2 0.836 45.3 41.2 0.844 Open 21.5 0.852 42.2 44.2 0.859 40.2 45.3 0.867 39.2 48.7...
  • Page 8 ISL8282MEVAL1Z 2. Functional Description Table 1. PROG 1 Resistor Reader (Continued) PROG1 (DC) (kΩ) (kΩ) 57.6 90.9 1.133 54.9 93.1 1.141 53.6 1.148 52.3 1.156 49.9 1.164 48.7 1.172 47.5 1.180 46.4 1.188 45.3 1.195 Open 1.203 66.5 1.211 69.8 1.219...
  • Page 9 ISL8282MEVAL1Z 2. Functional Description Table 1. PROG 1 Resistor Reader (Continued) PROG1 (DC) (kΩ) (kΩ) 1.453 1.461 1.469 1.477 1.484 1.492 21.5 Open 1.500 1.508 1.516 1.523 1.531 1.539 1.547 1.555 1.562 1.570 1.578 1.586 1.594 1.602 1.609 1.617 1.625 1.633...
  • Page 10 ISL8282MEVAL1Z 2. Functional Description Table 1. PROG 1 Resistor Reader (Continued) PROG1 (DC) (kΩ) (kΩ) 1.773 1.781 1.789 34.8 Open 1.797 1.805 1.812 1.820 1.828 1.836 1.914 1.992 2.070 2.148 2.227 2.305 2.383 2.461 2.469 2.477 2.484 2.492 52.3 Open 2.500...
  • Page 11 ISL8282MEVAL1Z 2. Functional Description Table 1. PROG 1 Resistor Reader (Continued) PROG1 (DC) (kΩ) (kΩ) 3.328 3.406 3.484 3.562 3.641 3.719 3.797 1000 3.875 3.953 4.031 4.109 4.188 4.266 4.344 4.422 4.500 4.578 4.656 4.734 4.812 4.891 4.969 4.977 4.984 4.992...
  • Page 12 ISL8282MEVAL1Z 2. Functional Description Table 2. PROG 2 Resistor Reader (Continued) Temperature PROG2 (DD) (kΩ) (kΩ) Comp (°C) PM_ADDR (7-Bit) Open Enabled 45.3 12.7 Enabled 42.2 13.3 Enabled 38.3 13.3 Enabled 35.7 13.7 Enabled 14.3 Enabled 31.6 14.7 Enabled 19.6 Enabled 19.6...
  • Page 13 ISL8282MEVAL1Z 2. Functional Description Table 2. PROG 2 Resistor Reader (Continued) Temperature PROG2 (DD) (kΩ) (kΩ) Comp (°C) PM_ADDR (7-Bit) 42.2 44.2 Enabled 40.2 45.3 Enabled 39.2 48.7 Enabled 37.4 49.9 Enabled 36.5 52.3 Enabled 34.8 54.9 Enabled 57.6 Enabled 33.2...
  • Page 14 ISL8282MEVAL1Z 2. Functional Description Table 2. PROG 2 Resistor Reader (Continued) Temperature PROG2 (DD) (kΩ) (kΩ) Comp (°C) PM_ADDR (7-Bit) 52.3 Enabled 49.9 Enabled 48.7 Enabled 47.5 Enabled 46.4 Enabled 45.3 Enabled 34.8 Open Enabled 78.7 Enabled 80.6 Enabled 84.5 Enabled 86.6...
  • Page 15 ISL8282MEVAL1Z 2. Functional Description Table 2. PROG 2 Resistor Reader (Continued) Temperature PROG2 (DD) (kΩ) (kΩ) Comp (°C) PM_ADDR (7-Bit) Disabled Disabled Disabled Disabled Disabled Disabled Disabled Open Disabled 93.1 Disabled 95.3 Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled...
  • Page 16 ISL8282MEVAL1Z 2. Functional Description Table 2. PROG 2 Resistor Reader (Continued) Temperature PROG2 (DD) (kΩ) (kΩ) Comp (°C) PM_ADDR (7-Bit) Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled...
  • Page 17 ISL8282MEVAL1Z 2. Functional Description Table 2. PROG 2 Resistor Reader (Continued) Temperature PROG2 (DD) (kΩ) (kΩ) Comp (°C) PM_ADDR (7-Bit) Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Open Disabled Disabled Disabled Disabled Disabled...
  • Page 18 ISL8282MEVAL1Z 2. Functional Description Table 2. PROG 2 Resistor Reader (Continued) Temperature PROG2 (DD) (kΩ) (kΩ) Comp (°C) PM_ADDR (7-Bit) Disabled Disabled Disabled Disabled Disabled Disabled Open Disabled Table 3. PROG 3 Resistor Reader AV Gain Ultrasonic Fault PROG3 (DE) (kΩ)
  • Page 19 ISL8282MEVAL1Z 2. Functional Description Table 3. PROG 3 Resistor Reader (Continued) AV Gain Ultrasonic Fault PROG3 (DE) (kΩ) (kΩ) Behavior (kHz) 43.2 Disabled Retry Open Disabled Retry Open 21.5 Disabled Retry 26.7 Disabled Retry 36.5 97.6 27.4 Disabled Retry 30.5 90.9...
  • Page 20 ISL8282MEVAL1Z 2. Functional Description Table 3. PROG 3 Resistor Reader (Continued) AV Gain Ultrasonic Fault PROG3 (DE) (kΩ) (kΩ) Behavior (kHz) 88.7 57.6 Disabled Latch 24.5 84.5 60.4 Disabled Latch 80.6 61.9 Disabled Latch 76.8 63.4 Disabled Latch 73.2 66.5...
  • Page 21 ISL8282MEVAL1Z 2. Functional Description Table 3. PROG 3 Resistor Reader (Continued) AV Gain Ultrasonic Fault PROG3 (DE) (kΩ) (kΩ) Behavior (kHz) 95.3 Disabled Latch 1000 24.5 90.9 Disabled Latch 1000 88.7 Disabled Latch 1000 86.6 Disabled Latch 1000 82.5 Disabled...
  • Page 22 ISL8282MEVAL1Z 2. Functional Description Table 4. PROG 4 Resistor Reader (Continued) PROG4 (DF) (kΩ) (kΩ) SS Rate (mV/µs) RR (kΩ) AVMLTI Open 21.5 68.1 31.6 63.4 32.4 45.3 41.2 43.2 42.2 57.6 33.2 61.9 21.5 Open Open 34.8 51.1 52.3 73.2...

  • Page 23: Pcb Layout Guidelines

    3. PCB Layout Guidelines PCB Layout Guidelines The ISL8282MEVAL1Z is a 3x3.4 inch six-layer FR-4 board with 2oz. copper on all layers. This board can be used as a single 15A reference design. For board layout information, see Figures 7...
  • Page 24 ISL8282MEVAL1Z 3. PCB Layout Guidelines Figure 4. Top of Board Figure 5. Bottom of Board R12UZ0038EU0100 Rev.1.00 Page 24 of 37 Jan 31, 2019...
  • Page 25 Schematic Figure 6. Schematic...

  • Page 26: Bill Of Materials

    ISL8282MEVAL1Z 3. PCB Layout Guidelines Bill of Materials Reference Package Designators Value Tol. Voltage Power Type Manufacturer Part Number Description 330µF ±20% 2917 Kemet T521X337M016ATE025 POSCAP C2, C36 1µF ±10% 0603 Taiyo Yuden TMK107BJ105KA-T Ceramic Capacitor C10, C11, C19, 22µF ±10%...

  • Page 27: Board Layout

    5002 Miniature PC TP7, TP9-TP11 Hole Test Point, Silver Plating 0.040” (1.02mm) Hole Diameter Mounting Type 12x11 HDA Renesas ISL8282MFRZ 15A Step- Down Power Module Board Layout Figure 7. Silkscreen Top R12UZ0038EU0100 Rev.1.00 Page 27 of 37 Jan 31, 2019...
  • Page 28 ISL8282MEVAL1Z 3. PCB Layout Guidelines Figure 8. Top Layer Component Side Figure 9. Inner Layer 2 R12UZ0038EU0100 Rev.1.00 Page 28 of 37 Jan 31, 2019...
  • Page 29 ISL8282MEVAL1Z 3. PCB Layout Guidelines Figure 10. Inner Layer 3 Figure 11. Inner Layer 4 R12UZ0038EU0100 Rev.1.00 Page 29 of 37 Jan 31, 2019...
  • Page 30 ISL8282MEVAL1Z 3. PCB Layout Guidelines Figure 12. Inner Layer 5 Figure 13. Bottom Layer Solder Side R12UZ0038EU0100 Rev.1.00 Page 30 of 37 Jan 31, 2019...
  • Page 31 ISL8282MEVAL1Z 3. PCB Layout Guidelines Figure 14. Silkscreen Bottom R12UZ0038EU0100 Rev.1.00 Page 31 of 37 Jan 31, 2019...

  • Page 32: Typical Performance Data

    ISL8282MEVAL1Z 4. Typical Performance Data Typical Performance Data The following data was acquired using the ISL8282MEVAL1Z evaluation board at +25°C ambient temperature and free air 0LFM. See the “ISL8282M Design Guide Matrix of Typical Applications” table in the ISL8282M datasheet for recommended configurations of different output voltages.

  • Page 33: Typical Performance Curves

    ISL8282MEVAL1Z 5. Typical Performance Curves Typical Performance Curves Operating conditions: V = 12V, f = 400kHz, AV gain = 49, RR = 200kΩ, C = 4 x 220µF Ceramic, PWM Mode, unless otherwise noted. AV Gain = 49 AV Gain = 49...
  • Page 34 ISL8282MEVAL1Z 5. Typical Performance Curves Operating conditions: V = 12V, f = 400kHz, AV gain = 49, RR = 200kΩ, C = 4 x 220µF Ceramic, PWM Mode, unless otherwise noted. (Continued) = 10V/Div = 0.5V/Div EN = 2V/Div PGOOD = 2V/Div = 10A/Div = 0.5V/Div...

  • Page 35: Revision History

    ISL8282MEVAL1Z 6. Revision History Revision History Rev. Date Description 1.00 Jan 31, 2019 Initial release R12UZ0038EU0100 Rev.1.00 Page 35 of 37 Jan 31, 2019...

  • Page 36: Corporate Headquarters

    Koto-ku, Tokyo 135-0061, Japan version of a document, or your nearest sales office, please visit: www.renesas.com www.renesas.com/contact/ Trademarks Renesas and the Renesas logo are trademarks of Renesas Electronics Corporation. All trademarks and registered trademarks are the property of their respective owners.
