MiTAC MiStation EC-900 User Manual page 19

Ref Component
Audio Output
Connector
Microphone
Indicators
Getting Started
Description
Connects a set of headphones, external
speakers with amplifier, or an audio
recording device.
Receives sound and voice for the computer.
Show the current status of the computer's
devices.
Power status indicator
Glows in green when the computer is
turned on.
Blinks in green when the computer is in the
standby mode.
Hard disk drive in-use indicator
Battery charge indicator
LED-off when the battery is fully charged.
Glows in green when the battery capacity is
between 90 to 99%.
Glows in amber when the battery capacity
is between 20 to 90%.
Blinks in amber when the battery capacity
is less than 20%.
WLAN
Glows in green when the wireless LAN
(WLAN) radio is on.
See Also
P. 2-10
P. 2-10
P. 3-3
P. 2-12
1-10
