3. Ensure that the DIN-rail is secured tightly on the
track.

Starting Web management

The following section describes how to start up the Web
management function of the wall-mount managed
switch. Note that the wall-mount managed switch is
configured through an Ethernet connection. Ensure that
the manager computer is set to the same IP subnet
address.
For example, if the default IP address of the wall-mount
managed switch is 192.168.0.100, then the manager
computer should be set to 192.168.0.x (where x is a
number between 1 and 254, except 100) and the default
subnet mask is 255.255.255.0.
Figure 4: IP management diagram
Logging in to the wall-mount managed switch
1. Use the Internet Explorer 11.0 or later Web browser
and type the IP address http://192.168.0.100 to
access the Web interface.
NS3562-8P-2S Quick Installation Guide
2. When the following dialog box appears, type "admin"
in both the default user name and password fields.
The login screen in Figure 5 below appears.
Default Username: admin
Default Password: admin
Figure 5: Web login screen
3. Click LOGIN. The main screen appears as shown in
Figure 6 below.
Figure 6: Main web screen of the wall-mount managed switch
The switch menu on the left side of the Web page
permits access to all of the commands and statistics
provided by the wall-mount managed switch.
