Shimax MAC3 Series Instruction Manual

Digital controller
Hide thumbs Also See for MAC3 Series:

Advertisement

Quick Links

Thank you for purchasing SHIMAX product. Please check that the product is the one you ordered.
Please operate after you read the instruction manual and fully understand it.
「 「 「 「 Notice」 」 」 」
Please ensure that this manual is given to the final user of the instrument.
Preface ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・2
1. Matters regarding safety・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・2
2. Introduction ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・2
2-1. Check before use ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・2
2-2. Caution for use ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・2
3. Installation and wiring ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・3
3-1. Installation site (environmental conditions)・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・3
3-2. Mounting・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・3
3-3. External dimension and panel cutout ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・3
3-4. Wiring ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・3
3-5. Terminal arrangement diagram ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・4
4. Description of front panel ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・4
4-1. Names of front panel ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・4
4-2. Explanation of front panel section ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・4
5. Description of screens ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・5
5-1. How to move to another screen ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・5
5-2. Setting Method ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・5
5-3. Power-on and initial screen display・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・5
5-4. Explanation of each screen・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・5
(1)Basic screens・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・5
(2)FIX (constant value control) setting screens ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・7
(3) PROG (program control) setting screens ・・・・・・・・ ・・・・・・・・・・・・・・・・・・・・・・・・7
(4) Mode 1 screens・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・9
(5) Mode 2 screens・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・9
(6) Mode 3 screens・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・9
(7) Mode 4 screens ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・10
(8) Mode 5 screens ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・11
(9) Mode 6 screens ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・12
(10) Mode 7 screens ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・13
(11) Mode 8 screens ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・13
(12) Mode 9 screens ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・13
5-5.Measuring range code table ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・14
6. Supplementary Explanation of Function・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・14
6-1. Auto return function・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・14
6-2. Output Soft Start Function ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・14
6-3. Event Selection Alarm Operation Figure・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・14
6-4. AT (Auto Tuning) ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・14
6-5. 2 output- characteristics figure ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・14
7. Trouble Shooting ・・・・・・・・・・ ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・15
7-1. Cause and Treatment of Main Defects
7-2. Cause and Treatment of Error Display・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・16
8. Specification ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・16
9. Program pattern setting table ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・20
MAC3 Series
MAC3
MAC3
MAC3
Series
Series
Series
Digital controller Instruction Manual
Contents
・ ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・15

1
Page
MAC3 F-1 AE
January, 2005
