AirPrime SL6087 User Guide
AirPrime SL6087
WA_DEV_SL6087_PTS_002
001
Jun 17, 2010

Advertisement

Table of Contents
loading

Related Manuals for Sierra Wireless AirPrime SL6087

Summary of Contents for Sierra Wireless AirPrime SL6087

  • Page 1 AirPrime SL6087 User Guide AirPrime SL6087 WA_DEV_SL6087_PTS_002 Jun 17, 2010...

  • Page 2: Wa_Dev_Sl6087_Pts

    Data may be delayed, corrupted (i.e., have errors) or be totally lost. Although significant delays or losses of data are rare when wireless devices such as the Sierra Wireless modem are used in a normal manner with a well-constructed network, the Sierra Wireless modem should not be used in situations where failure to transmit or receive data could result in damage of any kind to the user or any other party, including but not limited to personal injury, death, or loss of property.
  • Page 3 D560,911 and other patents pending. ® This product includes technology licensed from QUALCOMM Manufactured or sold by Sierra Wireless or its licensees under one or more patents licensed from InterDigital Group Copyright © 2010 Sierra Wireless. All rights reserved. Trademarks ®...

  • Page 4: Jun 17, 2010

    AirPrime SL6087 User Guide Document History Version Date Updates May 18, 2010 Creation WA_DEV_SL6087_PTS_002 Rev 001 Jun 17, 2010...

  • Page 5: Table Of Contents

    Applicable Standards Listing ................... 20 6. REFERENCES ....................22 6.1. Web Site Support ......................22 6.2. Reference Documents ..................... 22 6.2.1. Sierra Wireless Software Documentation ..............22 6.2.2. Firmware Documentation ..................23 6.2.3. Hardware Documentation ..................23 6.2.4. Other Sierra Wireless Documentation ..............24 6.2.5.
  • Page 6 AirPrime SL6087 User Guide 7.1.2. Exposure to RF Energy .................... 28 7.1.3. Efficient Terminal Operation..................28 7.1.4. Antenna Care and Replacement ................28 7.2. General Safety......................... 29 7.2.1. Driving ........................29 7.2.2. Electronic Devices ....................29 7.2.3. Vehicle Electronic Equipment .................. 29 7.2.4.

  • Page 7: Wa_Dev_Sl6087_Pts_002 Rev 001 Jun 17, 2010

    List of Figures Figure 1. Functional Architecture ....................11 Figure 2. SL6087 Embedded Module Mechanical Drawing ............13 Figure 3. LGA Pin Dimension and Location ................... 14 WA_DEV_SL6087_PTS_002 Rev 001 Jun 17, 2010...
  • Page 8 List of Tables Table 1: List of RF Frequency Ranges ..................11 Table 2: Input Power Supply Voltage .................... 12 Table 3: LGA Pads Description ..................... 15 Table 4: Antenna Specifications ....................19 Table 5: Standards Conformity for the SL6087 Embedded Module ..........20 Table 6: Applicable Standards and Requirements for the SL6087 Embedded Module ....

  • Page 9: Introduction

    1. Introduction The AirPrime SL6087 Intelligent Embedded Module is a self-contained GSM850/PCS-GPRS/EGPRS 850/1900 dual-band embedded module. 1.1. Physical Dimensions  Length: 30.0mm  Width: 25.0mm  Thickness: 2.65mm (excluding label thickness)  Weight: 3.8g 1.2. GSM/GPRS/EGPRS Features  2-Watt EGSM – GPRS 850 radio section running under 3.6 volts ...

  • Page 10: Connection Interfaces

    Environment and Mechanics 1.6.1. RoHS Directive Compliant The AirPrime SL6087 Embedded Module is compliant with RoHS Directive 2002/95/EC which sets limits for the use of certain restricted hazardous substances. This directive states that “from 1st July 2006, new electrical and electronic equipment put on the market does not contain lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls (PBB) or polybrominated diphenyl ethers (PBDE)”.

  • Page 11: Functional Specifications

    The AirPrime SL6087 Embedded Module is Sierra Wireless Software Suite compliant. With the Sierra Wireless Software Suite and the AirPrime SL6087 Embedded Module, customers can embed their own applications with the AirPrime SL6087 and turn the AirPrime SL6087 embedded module into a solution for their specific market need.

  • Page 12: Technical Specifications

    2: Maximum operating Voltage Standing Wave Ratio (VSWR) 2:1. 3.2. Mechanical Specifications The AirPrime SL6087 Embedded Module has a nearly-complete self-contained shield. The mechanical specifications are shown in the figures below, including the area needed for the AirPrime SL6087 Embedded Module to fit in an application.
  • Page 13 AirPrime SL6087 User Guide Technical Specifications Figure 1. SL6087 Embedded Module Mechanical Drawing WA_DEV_SL6087_PTS_002 Rev 001 Jun 17, 2010...
  • Page 14 AirPrime SL6087 User Guide Technical Specifications Figure 2. LGA Pin Dimension and Location WA_DEV_SL6087_PTS_002 Rev 001 Jun 17, 2010...

  • Page 15: Interfaces

    4. Interfaces 4.1.1. Pin Description Refer to the following table for the LGA pads description. Table 3: LGA Pads Description Signal Name Pin # I/O Type Voltage I/O* Reset State Description Dealing with Unused Pins Nominal (RXD1) Add a test point for CT104-RXD1 GPIO5 VCC_2V8...
  • Page 16 AirPrime SL6087 User Guide Interfaces Signal Name Pin # I/O Type Voltage I/O* Reset State Description Dealing with Unused Pins Nominal GPIO2 Open Drain I²C Data GPIO1 Open Drain I²C Clock Add a test point / a jumper/ a switch to VCC_1V8 (Pin 5) in case...
  • Page 17 AirPrime SL6087 User Guide Interfaces Signal Name Pin # I/O Type Voltage I/O* Reset State Description Dealing with Unused Pins Nominal GPIO23 VCC_2V8 ADC1/BAT- Analog Analog temperature Pull to GND TEMP CHG-IN CHG-IN Charger input ADC0/VBATT VBATT Power Supply ON/~OFF...
  • Page 18 AirPrime SL6087 User Guide Interfaces Signal Name Pin # I/O Type Voltage I/O* Reset State Description Dealing with Unused Pins Nominal 1 and LED0 Open Drain LED0 Output Undefined If INT0 is not used, it should be INT0 GPIO3 VCC_1V8...

  • Page 19: Rf Interface

    4.2.1. RF Connections The RF input/output of the AirPrime SL6087 Embedded Module is through one of the LGA pins (pin 22, ANT), with grounded LGA pins at both sides. The ANT pin of the AirPrime SL6087 Embedded Module is ESD protected for both ±4KV contact and ±8KV air discharge.

  • Page 20: Certification Compliance And Recommended Standards

    RSS-132 Issue 2 RSS-133 Issue 5 5.2. Applicable Standards Listing The table hereafter gives the basic list of standards applicable for the AirPrime SL6087 Embedded Module (2G (R99/Rel. 4)). Note: References to any features can be found from these standards.
  • Page 21 A label must be affixed to the outside of the end product into which the AirPrime SL6087 Intelligent Embedded Module is incorporated, with a statement similar to the following: This device contains FCC ID: N7NSL6087 This equipment contains device certified under IC: 2417C‐SL6087...

  • Page 22: References

    For more details, several reference documents can be consulted. The Sierra Wireless documents referenced herein are provided in the Sierra Wireless documentation package; however, the general reference documents which are not Sierra Wireless owned are not provided in the documentation package.

  • Page 23: Firmware Documentation

    AirPrime SL6087 User Guide References 6.2.2. Firmware Documentation Firmware 7.4b AT Commands Manual (Sierra Wireless Software Suite 2.32) Reference: WM_DEV_OAT_UGD_079 (Version 14) AT Commands Interface Guide Reference: WM_DEV_OAT_UGD_014 AT Commands Interface Guide (Bluetooth) Reference: WM_ASW_BLU_UGD_001 [10] Firmware 7.4 Customer Release Note Reference: TBC 6.2.3.

  • Page 24: Other Sierra Wireless Documentation

    STMicroElectronics L5973AD Power Supply with automotive VIN = 5.5...32V constraints VOUT = 3.8V Especially designed to meet Sierra Wireless Intelligent Embedded Module requirements. CAN Interface over SPI based on: CAN Interface (high speed) - MicroChip MCP2515 CAN Controller, - Philips PCA82C250T CAN Transceiver.

  • Page 25: List Of Abbreviations

    AirPrime SL6087 User Guide References 6.3. List of Abbreviations Abbreviation Definition Alternative Current Analog to Digital Converter Analog to Digital conversion Audio-Frequency ATtention (prefix for modem commands) AUXiliary Controller Area Network Cell Broadcast Circular Error Probable CLocK CMOS Complementary Metal Oxide Semiconductor...
  • Page 26 AirPrime SL6087 User Guide References Abbreviation Definition GPRS General Packet Radio Service Global Positioning System Global System for Mobile communications Half Rate Input / Output Light Emitting Diode Land Grid Array Low Noise Amplifier MAXimum MICrophone MINimum Multimedia Message Service...
  • Page 27 AirPrime SL6087 User Guide References Abbreviation Definition SPeaKer SRAM Static RAM To Be Confirmed TDMA Time Division Multiple Access Test Point Transient Voltage Suppressor Transmit TYPical UART Universal Asynchronous Receiver-Transmitter Universal Serial Bus USSD Unstructured Supplementary Services Data VSWR Voltage Standing Wave Ratio...

  • Page 28: Safety Recommendations (For Information Only)

    7. Safety Recommendations (For Information Only) For the efficient and safe operation of your GSM application based on the AirPrime SL6087 Embedded Module, please read the following information carefully. 7.1. RF Safety 7.1.1. General Your GSM terminal is based on the GSM standard for cellular technology. The GSM standard is spread all over the world.

  • Page 29: General Safety

    Safety Recommendations (For AirPrime SL6087 User Guide Information Only) Buy or replace the antenna only from the approved suppliers list. Using unauthorized antennas, modifications or attachments could damage the terminal and may contravene local RF emission regulations or invalidate type approval.

  • Page 30: Children

    Safety Recommendations (For AirPrime SL6087 User Guide Information Only) 7.2.6. Children Do not allow children to play with your GSM terminal. It is not a toy. Children could hurt themselves or others (by poking themselves or others in the eye with the antenna, for example). Children could damage the modem, or make calls that increase your modem bills.
