Attaching a Trailer

Secure the trailer with an appropriately sized clevis pin
(A, Figure 11) and clip (B).
DANGER
Towed loads can be hazardous and cause
loss of control on slopes.
• The max gross (trailer & load) weight of trailer is
200 lbs.
• Do not operate on slope exceeding 5 degrees.
• Reduce speed and use extreme caution on slopes.
A
B

Cutting Height Adjustment

The cutting height adjust pedal adjusts the mower cutting
height. The cutting height is adjustable between 1.5" (3,8
cm) and 4.5" (11,4 cm).
To adjust cutting height:
1. Fully depress the cutting height adjust pedal (A, Fig-
ure 12) until the transport release rod (B) locks the
deck into the highest position (transport position).
2. Remove the pin (C) from the adjustment bracket, and
insert it in the desired hole.
NOTE: Make sure the pin is inserted into the holes
in both upper and lower plates of the adjustment
bracket.
3. Depress the cutting height adjust pedal, move the
transport release rod outward, and slowly release the
pedal until it rests against the pin.

Mower Removal and Installation

Refer to the Mower Deck Manual for instructions on
removing and installing the mower deck.
Figure 11

Mower Deck Leveling

Refer to the Mower Deck Manual for instructions on lev-
eling the mower deck.
A
C
B
Figure 12
