2014.00
2990
55
B-B
A
A-A
Max. Net
Max. Water
Weight
Capacity
Kg.
lt.
200
2050
1/4
PRE-INSTALLATION CARD
2990
250
95
65
120
20mm AVG.THK ACRYLIC
FOAM & FIBERGLASS LAYER
min 400
40
275
515
S
Max. Floor
No. massage
load capacity
sessions
Kg/m 2
400
200±40
433±40
810
10
ART. C30F
(Ø 3000 mm ≈)
1283±40
1283±40
173±40
297±40
675±40
852±40
min 400
40
A
MAX
HEIGHT
1030 ÷ 1060
S
433±40
258±40
200±40
258±40
Measurements in mm.
1
Advertisement
Related Manuals for Teuco C30F
Summary of Contents for Teuco C30F
- Page 1 ART. C30F PRE-INSTALLATION CARD (Ø 3000 mm ≈) 2014.00 1283±40 1283±40 433±40 258±40 200±40 200±40 258±40 433±40 2990 173±40 2990 297±40 675±40 852±40 20mm AVG.THK ACRYLIC FOAM & FIBERGLASS LAYER min 400 min 400 HEIGHT 1030 ÷ 1060 Measurements in mm.
- Page 2 FILLING: the recommended method of filling the Teuco is to use an ordinary hose, taking care not to immerse the end as this could allow reflux of water back into the main (3).
