Safety and Operating Manual
Alligator
Staple Gold Class
Plus
®
™
WARNING
This manual contains important information about product function and safety. Please read and understand
this manual BEFORE operating the tool. Please keep this manual available for other users and owners
.
before they use the tool. This manual should be stored in a safe place. Also available online at flexco.com
www.flexco.com
www.flexco.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Flexco Alligator Staple Gold Class Plus
Summary of Contents for Flexco Alligator Staple Gold Class Plus
- Page 1 This manual contains important information about product function and safety. Please read and understand this manual BEFORE operating the tool. Please keep this manual available for other users and owners before they use the tool. This manual should be stored in a safe place. Also available online at flexco.com www.flexco.com...
-
Page 2: Table Of Contents
Alligator Staple Gold Class Plus ® ™ Table of Contents Introduction .....................pg. 3 Main Components ...................pg. 3 General Safety Rules ................pgs. 4-5 Maintenance and Instructions for Installation ......pgs. 6-7 Spare Parts ....................pg. 8 www.flexco.com —2—... -
Page 3: Introduction
™ Introduction The Alligator® Staple Gold Class™ Plus tool is designed to be used in conjunction with the Alligator® Gold Class Power Driver. Together these tools will install the complete line of Flexco Alligator® Ready Set™ Staple fasteners. Main Components 1. -
Page 4: General Safety Rules
Use safety equipment. Always wear eye protection, dust mask, non-skid safety shoes, and hard hat. Hearing protection must be used for appropriate conditions. WARNING Never alter or remove safety devices. WARNING Keep hands and fingers away from all moving parts at all times. www.flexco.com —4—... - Page 5 4. SERVICE AND MAINTENANCE WARNING CAUTION Always use tool on a level, firm surface. When servicing a tool, use only Flexco or equivalent replacement parts. Use of unauthorized parts or failure to follow CAUTION maintenance instructions may create a risk of injury.
-
Page 6: Maintenance And Instructions For Installation
Operation 1. Do not remove regulatory whip assembly. 2. (a) Square belt ends.(b) Cut belt using a 3. (a) Skive rough-top belt using Flexco Connect the Alligator® Staple Gold Class™ Flexco belt cutting tool. skiving products. Select correct fastener size Driver to a clean, dry air line with a by using the chart on page 7. - Page 7 Alligator Staple Gold Class Plus ® ™ 10. Follow the sequence shown above to 11. Squeeze both release handles to allow the 12. Move the handle from initial position drive all remaining fasteners. Staples will be tool to change position. into final position to move anvil into partially clinched.
-
Page 8: Spare Parts
ST8-A-SN200 55589 2525 Wisconsin Avenue • Downers Grove, IL 60515-4200 • USA Tel: (630) 971-0150 • Fax: (630) 971-1180 • E-mail: info@flexco.com Visit www.flexco.com for other Flexco locations and products. ©2014 Flexible Steel Lacing Company. 08-01-18. For reorder: X2415 —8—...
