Page 1
Please read and understand this manual BEFORE operating the tool. Please keep this manual available for other users and owners before they use the tool. This manual should be stored in a safe place. www.flexco.com www.flexco.com...
However this is no guarantee for good results. Fabricating belts does require the operator to master skills and have a certain level of craftsmanship. Results also depend on good practice, material composition and sharpness of blade. If results are not as expected, please contact Flexco. www.flexco.com www.flexco.com...
Description The Ply 130™ is used to separate between the plies of a The Ply 130™ can be used to prepare finger over finger thermoplastic conveyor belt, PVC or polyurethane. This splices and stepped splices. With the adjuster handle you splitting action is often required in preparation before determine the depth to split the belt.
Cluttered benches and dark areas invite accidents. the tool. DANGER Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes. www.flexco.com www.flexco.com —6—...
Page 7
Ply 130 General Safety Rules –Save These Instructions– ply separator ™ DANGER WARNING Do not abuse the cord. Never use the cord to carry the Do not overreach. Keep proper footing and balance at all times. Proper footing and balance tool or pull the plug from a receptacle.
Page 8
WARNING WARNING Keep your body positioned perpendicular to the material feeding direction on the opposite side of Disconnect electrical plug from the power supply the electric motor. before opening/servicing the machine. www.flexco.com www.flexco.com —8—...
Page 9
Ply 130 General Safety Rules –Save These Instructions– ply separator ™ WARNING WARNING Keep your hands away from the feeding rolls and Always wear cut-proof safety gloves and safety splitting area. Always guide the material in a way glasses when replacing blade. Blade is razor sharp, that your hands have a minimum distance of 3.94”...
Ply 130 body. A small rubber tipped chisel may be required if the faceplate is a tight fit. While tapping back edge of faceplate alternate low pulling force on each side of faceplate until removed. Discard faceplate. www.flexco.com www.flexco.com —10—...
Page 11
Installation of New Faceplate - Retrofit Kit Only With fingerguard dowel pins properly aligned, mount Step Cutter faceplate flat to Ply 130 body, lightly tapping with plastic hammer if required. Warning! Do NOT use screws to pull faceplate to Ply 130 body. Using a hex key, tightly secure the two 5 mm hex screws adhering faceplate to Ply 130...
Installation of Scale - Retrofit Kit Only Clean top surface of Ply 130 B1 B1 body nearest to infeed table. Remove backing paper from scale decal and install on Ply 130 body. Align to edge of Ply Separator body. www.flexco.com www.flexco.com —12—...
Installation of Low Volume Step Cutter Prior to blade installation ensure: • The power cable is disconnected from the power supply. • The Low Volume Step Cutter is readily available. • The operator is wearing cut-proof safety gloves and safety glasses. Loosen blade retention setscrews using 2.5 mm hex wrench.
Page 14
Note: This allows for clearance between the step cutter blade and the ply blade during installation. Loosen (do not remove) T-nut screw. Align step cutter T-nut with T-groove in faceplate. www.flexco.com www.flexco.com —14—...
Page 15
Installation of Low Volume Step Cutter Insert until tab contacts B1 C5 faceplate. Caution: Step cutter should slide in T-slot with ease and not be forced. Using the T-handle hex key, B1 C6 tighten Step-Cutter T-nut screw. —15—...
Page 16
If necessary, use the 2.5 mm hex key to loosen screw and then laterally adjust the step cut blade up to the new ply separation blade. www.flexco.com www.flexco.com —16—...
Page 17
Installation of Low Volume Step Cutter Install Guide Extension for step B1 C9 cutting less than 1.57" (40 mm). Loosen infeed table clamp nuts. Lift adjustable guide and insert guide extension under adjustable guide. Position guide to desired step cutting depth and tighten clamp nuts.
• If belt material becomes stuck in the ply separator, rotate the Ply 130 power switch to the reverse position, to dislodge the material. Inspect step cutter blade position after dislodging material and making adjustments as needed. www.flexco.com www.flexco.com —18—...
Ply 130 Maintenance – Measure and Adjust ™ Blade/Roller Clearance As Necessary Verify Blade/Roller Clearance: • Disconnect power cable from the power supply. • After replacing the ply separation blade, it may be necessary to adjust traction roller height. To evaluate clearance between the upper traction roller and top of blade, begin by positioning the adjustment handle to 0.
Page 20
Maintenance – Measure and Adjust Blade/Roller Clearance As Necessary ™ If adjustment is needed, unscrew clamp nut on adjustment guard plate. Using a 5 mm hex key, remove the handle. For easier removal of motor ensure keyway is positioned at top of drive shaft. www.flexco.com www.flexco.com —20—...
Page 21
Ply 130 Maintenance – Measure and Adjust Blade/Roller Clearance As Necessary ™ Remove the electric motor to gain sufficient access for adjustment of traction rollers by first removing the torque arm bolt using a 6 mm hex wrench. After removal of torque arm bolt set spacer aside.
Page 22
Caution: Do not allow motor to slide off of tray surface. Adjustments to Increase or Decrease the Distance Between the Upper Roller and Blade For upper roller adjustment loosen and remove gas spring fixation screw. www.flexco.com www.flexco.com —22—...
Page 23
Ply 130 Maintenance – Measure and Adjust Blade/Roller Clearance As Necessary ™ The purpose of the adjustment is to turn the eccentric shaft. It is important to turn, for both A and B, a recommended one quarter turn or less prior to rechecking with shims. For increasing the clearance between the top roller and blade: using a 5 mm hex key to engage screws, loosen screw B counterclockwise one quarter turn and tighten screw A clockwise one quarter turn or until moderately tight.
Page 24
Repeat steps E9-E13 as necessary. Adjustments to Increase or Decrease the Distance Between the Lower Roller and Blade Position and lock adjusting handle so that adjusting screws are accessible. www.flexco.com www.flexco.com —24—...
Page 25
Ply 130 Maintenance – Measure and Adjust Blade/Roller Clearance As Necessary ™ The purpose of the adjustment is to turn the eccentric shaft. It is important to turn, for both A and B, a recommended one quarter turn or less prior to rechecking with shims. For increasing the clearance between the blade and the lower traction roller: using a 5 mm hex key to engage screws, loosen screw C counterclockwise one quarter turn and tighten screw D clockwise one quarter turn or until moderately tight.
Page 26
Maintenance – Measure and Adjust Blade/Roller Clearance As Necessary ™ Once adjustments have been made, reinstall the guard plate. Start by reinstalling the handle. Then reinstall the clamp nut. Reinstall motor. Align shaft key with key slot. www.flexco.com www.flexco.com —26—...
Page 27
Ply 130 Maintenance – Measure and Adjust Blade/Roller Clearance As Necessary ™ Reassemble the motor to the frame placing the spacer between the motor torque arm and ply base. Insert 8 mm hex bolt with washer and tighten. G12e Note: Ensure rubber grommet is in place prior to reassembly.
