8/20 Bosch Rexroth AG | Mobile Hydraulics

Unit Dimensions, Sizes 10, 12, 16

64,5
12
20
6
18,2
5
R
23,5
T
2
130,5
Shaft ends
Sizes 10, 12, 16
A Splined shaft, DIN 5480
W 25x1,25x30x18x9g
p = 400 bar
N
T
1
147
167,5
Sizes 10, 12
Z Splined shaft, DIN 5480
W 20x1,25x30x14x9g
p = 400 bar
N
Before finalising your design, please request a certified drawing.
95
Connections
B(A) Service line ports
S Suction port
T ,T Drain port (1 port plugged)
1 2
R Air bleed (plugged)
Sizes 10, 12, 16
B Parallel shaft with key,
AS 8x7x32, DIN 6885
p = 350 bar
N
A2FO | RE 91 401/09.00
Note:
For anti-clockwise rotation port
plate is rotated through 180º
S
B (A)
42,5
16
M22x1,5
M33x2
M12x1,5
M8x1
Sizes 10, 12
P Parallel shaft with key,
AS 6x6x32, DIN 6885
p = 350 bar
N
