12/20 Bosch Rexroth AG | Mobile Hydraulics

Unit Dimensions, Sizes 80, 90

78,5
32 20
10
29
15
R
11
T
196
223,5
Shaft ends
Sizes 80, 90
A Splined shaft, DIN 5480
W 40x2x30x18x9g
p = 400 bar
N
T
1
2
M12; 17 deep
255
Size 80
Z Splined shaft, DIN 5480
W 35x2x30x16x9g
p = 400 bar
N
Before finalising your design, please request a certified drawing.
165
Connections
B(A) Service line ports
420 bar (6000 psi) high pressure series
S Suction port
280 bar (4000 psi) standard series
T ,T Drain port (1 port plugged)
1 2
R Air bleed (plugged)
Sizes 80, 90
B Parallel shaft with key,
AS 12x8x56, DIN 6885
p = 350 bar
N
A2FO | RE 91 401/09.00
Note:
For anti-clockwise rotation port
plate is rotated through 180º
58,7
32
S
B (A)
73 25
M10; 17 deep
SAE 1"
SAE 1 1/4"
M18x1,5
M12x1,5
Size 80
P Parallel shaft with key,
AS 10x8x56, DIN 6885
p = 350 bar
N
