RE 91 401/09.00 | A2FO
Ordering Code / Standard Program - Size 5
Axial piston unit
Bent axis design, fixed displacement
Size
3
Displacement V
(cm
)
g
Direction of rotation
Viewed on shaft end
Series
Shaft end
Parallel shaft with key DIN 6885
Tapered shaft with spigot and spring washer DIN 6888
Service line connections
Threads at side, metric

Unit Dimensions, Size 5

8
4
51
Shaft ends
B Parallel shaft with
key A4x4x20
DIN 6885
p
= 210 bar
N
A2F 5
A2F
5
clockwise
R
anti-clockwise
L
6.0
Y
T
80
C Tapered shaft with spigot
and spring washer 3x5
DIN 6888
taper 1:10
p
= 315 bar
N
Mobile Hydraulics | Bosch Rexroth AG
6.0
7
Additional instructions in text form
Seals
The fixed pump A2F 5 is equipped with NBR-
(nitril-caoutchouc) seals in standard design.
In case of need FKM- (fluor-caoutchouc) seals
please indicate when ordering in clear text:
"with FKM-seals"
B
C
7
Before finalising your design, please request a certified drawing.
70
Connections
B, (A) Service line ports
S
Suction port
T
Drain port
7/20
= preferred program
(preferred types see page 18)
Note:
For anti-clockwise rotation port
plate is rotated through 180º
Detail Y
T
S
T
B (A)
M18x1,5
M22x1,5
M10x1, both sides
