Smeg Oven SC106ALU Instruction Manual

Smeg oven instruction manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

1.
PRECAUTIONS FOR USE ................................................................... 33
2.
3.
SAFETY PRECAUTIONS ..................................................................... 35
4.
GET TO KNOW YOUR OVEN .............................................................. 36
5.
BEFORE INSTALLATION..................................................................... 36
6.
DESCRIPTION OF FRONT PANEL CONTROLS ................................ 37
7.
USING THE OVEN ............................................................................... 39
8.
9.
ACCESSORIES AVAILABLE................................................................ 48
10. RECOMMENDED COOKING TABLES ................................................ 49
11. CLEANING AND MAINTENANCE ........................................................ 52
12. EXTRAORDINARY MAINTENANCE .................................................... 56
13. INSTALLING THE APPLIANCE............................................................ 59
INSTRUCTIONS FOR THE USER: these provide recommendations for
use, a description of the controls and the correct procedures for cleaning
and maintaining the appliance
INSTRUCTIONS FOR THE INSTALLER: these are intended for the
qualified engineer who is to install, commission and test the appliance
32

Table of Contents

Advertisement

Table of Contents
loading

Related Manuals for Smeg Oven SC106ALU

Summary of Contents for Smeg Oven SC106ALU

  • Page 1: Table Of Contents

    PRECAUTIONS FOR USE ... 33 DISPOSAL INSTRUCTIONS - OUR ENVIRONMENT POLICY ... 34 SAFETY PRECAUTIONS ... 35 GET TO KNOW YOUR OVEN ... 36 BEFORE INSTALLATION... 36 DESCRIPTION OF FRONT PANEL CONTROLS ... 37 USING THE OVEN ... 39 USING THE PIZZA FUNCTION (ON SOME MODELS ONLY) ... 46 ACCESSORIES AVAILABLE...

  • Page 2: Precautions For Use

    1. PRECAUTIONS FOR USE THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE. TAKE GOOD CARE OF IT AND KEEP IT TO HAND THROUGHOUT THE OVEN'S LIFE CYCLE. WE URGE YOU TO READ THIS MANUAL AND ALL THE INFORMATION IT CONTAINS CAREFULLY BEFORE USING THE APPLIANCE.

  • Page 3: Disposal Instructions - Our Environment Policy

    Before scrapping your appliance it is important to remove doors and leave shelves in position as for use, to ensure that children cannot accidentally become trapped inside the oven during play. Also, cut the power supply lead and remove it and the plug.

  • Page 4: Safety Precautions

    THE ELECTRICAL MAINS AND CONTACT YOUR NEAREST SERVICE CENTRE. NEVER ATTEMPT TO REPAIR THE APPLIANCE. NEVER PLACE INFLAMMABLE OBJECTS IN THE OVEN: IF IT SHOULD ACCIDENTALLY BE SWITCHED ON, THIS MIGHT CAUSE A FIRE. THE APPLIANCE BECOMES VERY HOT DURING USE. TAKE CARE NOT TO TOUCH THE HEATING ELEMENTS INSIDE THE OVEN.

  • Page 5: Get To Know Your Oven

    For further information about cleaning, see point "11. CLEANING AND MAINTENANCE". When the oven and grill are used for the first time, they should be heated to the maximum temperature for long enough to burn off any oily residues left by the manufacturing process, which might contaminate foods with unpleasant smells.

  • Page 6: Description Of Front Panel Controls

    DISPLAY DSP1 With the oven off, the 4-figure LED display shows the current time; when the oven is in operation, it shows the temperature set and the cooking duration set. The display also contains the function cutout light (see point “7.6...
  • Page 7 Instructions for the user Simply turn this knob to the right or left to select the function required, from those listed below. From now on, for convenience it will be referred to as PT2. The table below provides a short description of the functions available: NO FUNCTION SET GRILL ELEMENT IN OPERATION ALTERNATING WITH BOTTOM...

  • Page 8: Using The Oven

    Precautions and General Advice All cooking operations must be carried out with the door closed When the oven and grill are used for the first time, they should be heated to the maximum temperature for long enough to burn off any oily residues left by the manufacturing process, which might contaminate foods with unpleasant smells.

  • Page 9: First Use

    Instructions for the user First use At first use, or after a power failure, the oven display (DSP1), will show a flashing must be set. (For further information about setting or adjusting the current time, see point "7.6 Secondary menu").
  • Page 10 Warning. The minute minder does not stop the cooking process. It only warns the user that the preset number of minutes have passed. To switch the oven off completely, turn PT2 to the "0" symbol. Modifying the data set Once the countdown has started, its duration can be changed while cooking is in progress.
  • Page 11 A few seconds after the required duration is set, the symbols will stop flashing, and the oven will start to wait for the starting time set. At the end, the word STOP will appear on DSP1, cooking will stop and a buzzer will sound;...

  • Page 12: Secondary Menu

    3 (P2: OF / ON) Activate or deactivate the Show Room function, which disables all the heating elements so that only the control panel works. To allow the oven to be used normally, P2:OFF must be set. 4 (P3: OF / ON) Activate or deactivate the function which limits the maximum power absorption to 2300 W.
  • Page 13 The secondary menu appears the first time the appliance is used or after a power blackout, or can be accessed by keeping PT1 depressed for 3 seconds with the oven in OFF status (see point “7.2 Operating modes”). Changing the settings of the secondary menu parameters is very easy.

  • Page 14: Inside Light

    (Pyrolysis) starts. Operation of the fans generates a normal air flow which comes out above and underneath the door and may continue for a short time even after the oven is switched off. Inside light The oven light comes on: •...

  • Page 15: Using The Pizza Function (On Some Models Only)

    Simply place the cover over it, taking care to fit it securely. • Never use any oven function if the pizza plate or cover is not in position. • The appliance becomes very hot during use. Oven gloves should always be worn.
  • Page 16 Instructions for the user To save energy The pizza stone acts as a heat reservoir. This allows energy consumption to be reduced, especially in cooking operations requiring pre-heating or medium-long times. In these cases, simply turn the thermostat to zero 10- 12 minutes before the end of the cooking time.

  • Page 17: Using The Pizza Function (On Some Models Only)

    Instructions for the user 9. ACCESSORIES AVAILABLE The oven is fitted with 4 runners for placing trays and shelves at different heights. Shelf: useful to support pans containing the food for cooking. Tray grid: for placing on top of a tray for cooking foods which may drip.

  • Page 18: Recommended Cooking Tables

    10. RECOMMENDED COOKING TABLES The oven must be preheated before all cooking operations. Do not place the foods inside the oven until the degrees Centigrade symbol on the display stops flashing and the beep has sounded to confirm that the set temperature has been reached.

  • Page 19: Hot Air Cooking

    CROISSANTS JAM TARTS ANGEL CAKE DEFROSTING FOODS NATURAL YEAST DOUGHS For successful proving, a container of water should be placed in the bottom of the oven. HOT AIR COOKING RUNNER POSITION FROM THE BOTTOM 1 - 2 1 - 2 PROVING - DEFROSTING TEMPERATURE °C...
  • Page 20 Instructions for the user PORK CUTLET PORK FILLET FILLET STEAK SLICED LIVER VEAL ESCALOPES HALF CHICKEN SAUSAGE MEATBALLS FISH FILLET TOASTED SANDWICHES GRILLING RUNNER POSITION FROM THE BOTTOM TIME IN MINUTES 1ST SIDE 2ND SIDE 7 - 9 5 - 7 9 - 11 5 - 9 9 - 11...

  • Page 21: Cleaning And Maintenance

    Before carrying out any operations, disconnect the appliance from the electricity supply. Never use a jet of steam for cleaning the inside of the oven. 11.1 Cleaning stainless steel To keep stainless steel in good condition, it must be cleaned regularly, after each use of the oven, after allowing it to cool.

  • Page 22: Cleaning The Oven

    Lift the base a few mm and then extract it from the oven. • Now lift the end of the heating element next to the door of the oven and clean the bottom. When the operation is complete, damp parts should...
  • Page 23 • To put the pizza plate base back in place, push it firmly down against the oven's bottom panel and ensure it engages with plate of the the pizza heating element (detail A Fig. 2)
  • Page 24 11.5.1 Using the self-cleaning liners To keep the inside of the oven clean and free from food residues and unpleasant smells, it should periodically be operated empty at a temperature of at least 200° C for a time varying between 30 and 60 minutes.

  • Page 25: Extraordinary Maintenance

    Instructions for the user 12. EXTRAORDINARY MAINTENANCE Occasionally, the oven will require minor servicing procedures or the replacement of parts subject to wear and tear, such as gaskets, light bulbs, etc. The specific operations for each procedure of this kind are provided below.

  • Page 26: Removing The Door

    Close the door to an angle of about 45° and lift it off. To reassemble, fit the hinges into their grooves, then lower the door into place and extract the pins. 12.3 Removing the gasket To allow thorough cleaning of the oven, the door gasket can be removed.

  • Page 27: Removing The Inside Glass With The Door Cold

    Instructions for the user 12.4 Removing the inside glass with the door cold The glass in the door should always be kept thoroughly clean. For easier cleaning, the door glazing can be fully removed by proceeding as described below. After opening the door and locking it in place as described in point “12.2 Removing the door”, remove the three panes of glass.

  • Page 28: Installing The Appliance

    13.1 Electrical connection: The nameplate with the technical data, serial number and mark is in a visible position on the oven door surround. The nameplate must never be removed. The appliance must be connected to earth in compliance with electrical system safety regulations.

  • Page 29: Positioning The Oven

    1 (ref. B). See the instructions supplied with the hob for the relative positioning and fixing procedures. Never use the door for leverage when inserting the oven in the cabinet. Never apply excessive pressure to the open door.
