- Page 1 Installation Manual HomeLine | 26.03.2018...
-
Page 2: Table Of Contents
Table of contents 1. Safety regulations ....................3 Transport and storage ......................4 2. Product description ....................4 General ..........................4 Online - Model with modem and BackOffice ................. 4 Safety ............................. 4 Mode 3 Controller........................4 Operation ..........................5 Warranty .......................... -
Page 3: Safety Regulations
1. Safety regulations WARNING: RISK OF ELECTRIC SHOCK. • Please read the documentation provided with the charging station to acquaint yourself with the safety instructions and directions before you use the charging station. • This charging station is designed and tested in accordance with international standards. •... -
Page 4: Transport And Storage
Transport and storage Ensure that the main power source has been disconnected when storing or transporting the charging station. No liability can be accepted for damage during the transportation, if the charging station is transported in anything other than the original packaging. Store the charging station in a dry environment. -
Page 5: Operation
Operation A charging session may be started by holding an authorized RFID card (Mifare Classic, 13.56Mhz) against the front of the charging station at the round surface showing a hand with a RFID card (Figure 1). See also Chapter 3. Warranty EV-Box warranties its equipment and software against errors and defects in materials and workmanship for twenty four (24) months from the date of delivery, during which time it will... -
Page 6: Control
3. Control Charging stations with RFID reader Start charging 1. Use your charging cable to connect the EV-Box station to your vehicle. Present your charging card (RFID Card) to the card reader. The charging station will react with a tone. This indicates your card is being validated. It’s possible that the LED ring will light up yellow for a couple of seconds. -
Page 7: Led Ring Indicator
LED ring indicator The socket is surrounded by an LED ring. It shows the status of the charging station, so that you can see which mode the charging station is in (see Chapter 8). A blinking yellow LED-ring (once every second) indicates a paused charging session. This is only possible in a Hub- Satellite configuration (see chapter 6). -
Page 8: Installation
4. Installation Safety requirements Connecting and installing this charging station must be done by a qualified technician. The owner or user is responsible for the installation, operation and maintenance of the charging station, whereby both the law regarding the safety of persons, animals and property must be observed, as well as the installation instructions and regulations in force in the country of use. -
Page 9: Location
• Ensure that there is always adequate free space (at least 20cm) around the charging station for ventilation purposes. Location Position the charging station, where possible, in surroundings not subject to extreme sunlight and where damage from outside cannot occur. The charging station can be installed on the stainless steel pole with bracket supplied with the charging station. -
Page 10: Pole Mounting
• Remove the cover (Figure 4), it is attached with 4 bolts at the backside of the base unit. Mount the base unit onto the wall with a pipe wrench tightening the nuts evenly and crosswise so that the base unit is not deformed. The cover needs to lock in tightly to ensure IP54 protection. -
Page 11: Finishing Installation
Finishing installation Make sure the circuit breaker / residual current device in the meter cabinet is in the “On” position and that the main switch in the charging station is off. Check the grounding resistance. This should be as low as possible but not to exceed 150 Ohms. -
Page 12: Maintenance
Maintenance Dirt on the outside of the charging station can be cleaned off using a damp soft cloth. The owner or user is responsible for the maintenance of the charging station, whereby both the law regarding the safety of persons, animals and property must be observed, as well as the installation instructions in force in the country of use. -
Page 13: Installing The Modem Externally
5. Installing the modem externally A GSM link with the charging station is essential for the charging station to work properly. However, a good link cannot always be obtained in enclosed spaces, for instance in a closed or underground car park. In cases such as this, the modem can be positioned outside the charging station along with the GSM/GPS antenna and connected to the charging station. -
Page 14: Adding Extra Connectors (Satellites)
Adding extra connectors (Satellites) Several charging stations without a modem (Satellites) can be linked to a charging station with a modem in a hub / satellite connection thus forming a grid. The grid can support up to a total of 20 sockets. The advantages are that control of the charging stations is simpler and that, for locations with a poor GSM link, only a single modem has to be installed externally. -
Page 15: Technical Specifications
7. Technical Specifications These are general specifications for the HomeLine charging station. You can find more about the technical specifications for your specific model in the “Downloads” section of EV-Box.com Item Description 1-phase or 3-phase, 50Hz, between 2.5 – 10mm2 Connection capacity Output power per connector 1-phase or 3-phase, 230V –... -
Page 16: Troubleshooting
8. Troubleshooting EV-Box highly recommends the installation work to be done by a qualified electrician and or installation partner. Problem Possible cause Solution Charging station does not • No power to charging station • Are the residual current device and react circuit breaker in the meter cabinet on? ( check by user) - Page 17 Problem Possible cause Solution LED ring continues to light • Charging station waiting for the • Are the plugs properly inserted in the up yellow vehicle vehicle and charging station? ( check by • Vehicle is fully charged user) • Faulty charging cable •...
-
Page 18: Eu Declaration Of Conformity
9. EU Declaration of Conformity MANUFACTURER'S DECLARATION (in accordance with Appendix II-B of the Machinery Directive) EV-Box B.V., NL registration KvK 32165082_000018683428 Pedro de Medinalaan 31, 1086XP Amsterdam, The Netherlands declares under its’ sole responsibility that the following products: Article H116X-XXXX: EV-Box Charging station, 1-phase 16A Article H132X-XXXX: EV-Box Charging station, 1-phase 32A Article H316X-XXXX: EV-Box Charging station, 3-phase 16A Article H332X-XXXX: EV-Box Charging station, 3-phase 32A...
