POP_004407
CO Detector
Firmware Version : 1.0
Quick Start
S
This device is a wireless Z-Wave sensor. Exclusion, Inclusion are confirmed by hitting the programm
button for 1 sec when the sensor is removed from the mounting ring and the tamper switch is released. A
wakeup is performed hitting the programm button for 1 sec when the sensor is not removed from the
mounting ring and the tamper switch is not released.
Please refer to the chapters below for detailed information about all aspects of the products usage.

Product description

Carbon Monoxide is the most toxic substance people can come into contact with in their daily lives: at home,
at work, garage, car, caravan or boat. You can't see or smell carbon monoxide, but at high levels it can
poison a person in minutes. Carbon monoxide (CO) is produced whenever any fuel such as gas, oil,
kerosene, wood or charcoal is burned. If appliances that burn fuel are maintained and used properly, the
amount of CO produced is usually not hazardous. However, if appliances are not working properly or are
used incorrectly, dangerous levels of CO can result. Hundreds of people die accidentally every year from
CO poisoning caused by malfunctioning or improperly used fuel-burning appliances. Even more die from CO
produced by idling cars. Fetuses, infants, elderly people and people with anemia or with a history of heart or
respiratory disease can be especially susceptible. The concentration of this gas is measured in ppm (parts
per million) and is approximately 0.1 ppm in the atmosphere. In residential buildings the normal
concentration is 0.5 to 5 ppm. In the vicinity of gas burners e.g. concentrations of up to 15 ppm may occur.
The device will send an alarm when one of the following conditions are met:
50 ppm for 60 minutes
100 ppm for 10 minutes
300 ppm for 3 minutes
Popp Carbon Monoxide Combi Sensor is a new solution for advanced Carbon Monoxide (CO) detection in
households and businesses. This model has compact, yet spacious and stylish housing to also complies to
the Z-Wave wireless protocol. The performance of the device is enhanced by Japanese-made Nemoto
electrochemical CO sensor. The Popp CO Combi Sensor measures the CO concentration in the air and
issues an alarm when a certain level of CO is exceeded. Beside the main function of detecting Carbon

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POP 004407 and is the answer not in the manual?

Questions and answers

Summary of Contents for Popp POP 004407

  • Page 1 100 ppm for 10 minutes 300 ppm for 3 minutes Popp Carbon Monoxide Combi Sensor is a new solution for advanced Carbon Monoxide (CO) detection in households and businesses. This model has compact, yet spacious and stylish housing to also complies to the Z-Wave wireless protocol.
  • Page 2 Monoxide the device also reports and monitors the ambient temperature and humidity, which can additionally be used for the identification of smouldering. According to the directive DIN EN14604 the CO sensor gives a visual warning and the alarm siren occurres when a high CO concentration is measured. This siren has a defined volume of 85dB at a distance of 3 meters.
  • Page 3 Behavior within the Z-Wave network On factory default the device does not belong to any Z-Wave network. The device needs to join an existing wireless network to communicate with the devices of this network. This process is called Inclusion. Devices can also leave a network. This process is called Exclusion. Both processes are initiated by the primary controller of the Z-Wave network.
  • Page 4 Self-Protection Mode: If the cover of detector removed from bracket, after 8 sec the detector will send an alarm report (type:0*02, level:0*FF) to the Z-Wave Interface Controller and the yellow LED will flash continuously and the detector will sound. Silence Mode: The user could press the test switch to get into silence mode to turn off the alarm temporarily when the CO detector alarms.
  • Page 5 Z-Wave devices control other Z-Wave devices. The relationship between one device controlling another device is called association. In order to control a different device, the controlling device needs to maintain a list of devices that will receive controlling commands. These lists are called association groups and they are always related to certain events (e.g.
  • Page 6 Inverts Switching Command on Association Group 2 (Parameter Number 5, Parameter Size 1) Value Description At High send ON (Default) At High send OFF Inverts Switching Command on Association Group 4 (Smoke) (Parameter Number 7, Parameter Size 1) Value Description on Smoke send ON (Default) on Smoke send OFF Send SensorBinary- Report to Group 1 (Parameter Number 8, Parameter Size 1) When Smoke is detected...
  • Page 7 Technical Data Battery Type 1 * CR123A Explorer Frame Support Yes 4.55.00 Device Type Slave with routing capabilities Generic Device Class Alarm Sensor Specific Device Class Routing Smoke Sensor Routing FLiRS Firmware Version...
