TCX1000 Inline Amplifier Quick Start Guide
About This Quick Start Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Step 1: Prepare Your Site for the TCX1000-ILA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Step 2: Unpack the TCX1000-ILA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Step 3: Mount the Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Step 4: Connect the Grounding Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Step 5: Connect to the Management Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Step 6: Power On the TCX1000-ILA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connecting AC Power to the TCX1000-ILA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connecting DC Power to the TCX1000-ILA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Step 7: Perform the Initial Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Safety Warnings Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Power Cable Warning (Japanese) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
NEBS Compliance Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Compliance Statements for EMC Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
European Community . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Israel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Japan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
United States . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
TCX1000 Series Documentation and Release Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Requesting Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Self-Help Online Tools and Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Opening a Case with JTAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
About This Quick Start Guide
This Quick Start Guide contains information you need to install and connect the Juniper Networks TCX1000 Inline Amplifier (ILA).
For complete installation instructions, see the TCX1000 Inline Amplifier Hardware Guide at
https://www.juniper.net/documentation/
WARNING:
This Quick Start Guide contains a summary of safety warnings in
For a complete list of warnings for the TCX1000-ILA, including translations, see the TCX1000 Inline Amplifier Hardware
Guide at
https://www.juniper.net/documentation/.
The Juniper Networks TCX1000 Inline Amplifier is a standalone erbium-doped fiber amplifier (EDFA) with dual AC or DC power
supplies.The TCX1000-ILA supports dual optical inline amplification-two functionally separate amplifiers. The TCX1000-ILA
provides amplification of a dense wavelength-division multiplexing (DWDM) signal to enable long-distance transmission over
fiber-optic cable. The TCX1000-ILA is used in conjunction with the TCX1000-RDM20.
.
"Safety Warnings Summary" on page
12.
Advertisement
Table of Contents
Related Manuals for Juniper TCX1000
Summary of Contents for Juniper TCX1000
-
Page 1: Table Of Contents
Opening a Case with JTAC ................14 About This Quick Start Guide This Quick Start Guide contains information you need to install and connect the Juniper Networks TCX1000 Inline Amplifier (ILA). For complete installation instructions, see the TCX1000 Inline Amplifier Hardware Guide at https://www.juniper.net/documentation/... -
Page 2: Step 1: Prepare Your Site For The Tcx1000-Ila
Management host, such as a PC laptop, with a serial port (not provided). Step 2: Unpack the TCX1000-ILA For detailed instructions on how to unpack the box and verify the parts received for the TCX1000-ILA, see the TCX1000 Inline Amplifier Hardware Guide at https://www.juniper.net/documentation/... -
Page 3: Step 3: Mount The Chassis
TCX1000 Inline Amplifier Quick Start Guide Step 3: Mount the Chassis To mount the TCX1000-ILA on two posts or four posts in a rack by using the provided mounting kit (see Figure NOTE: The 19-inch brackets are attached to the TCX1000-ILA when they are shipped. If you want to attach the 21-inch or 23-inch brackets, unscrew the 19-inch brackets from the chassis, and attach the 21-inch or 23-inch brackets by using the same screws. -
Page 4: Step 4: Connect The Grounding Cable
To connect a grounding cable to the TCX1000-ILA: Connect one end of the grounding cable to a proper site earth ground, such as the rack in which the TCX1000-ILA is mounted. Unscrew the screws that are attached to the chassis. -
Page 5: Step 5: Connect To The Management Console
TCX1000 Inline Amplifier Quick Start Guide Step 5: Connect to the Management Console The TCX1000-ILA has a console port with an RJ-45 connector. Use the console port to connect the device directly to a management console, such as a laptop, or to a console server. - Page 6 Verify that the status LEDs on each power supply are lit green. If any LED is lit red, remove power from the power supply, and replace the power supply (see “Maintaining the TCX1000-ILA Power System” in the TCX1000 Inline Amplifier Hardware Guide). Do not remove the power supply until you have a replacement power supply ready: either power supplies or blank cover panels must be installed in the TCX1000-ILA to ensure proper airflow.
-
Page 7: Connecting Dc Power To The Tcx1000-Ila
Ensure that you have connected the TCX1000-ILA chassis to earth ground. CAUTION: Before you connect power to the TCX1000-ILA, a licensed electrician must attach a cable lug to the grounding and power cables that you supply. A cable with an incorrectly attached lug can damage the switch (for example, by causing a short circuit). - Page 8 Use a ratcheting torque screwdriver to apply a torque of 4.5 lb-in. (0.5 Nm) to each of the terminal block captive screws (see Figure Insert the DC connector in the TCX1000-ILA DC power supply. Tighten the attached screws (top and bottom) on the DC power connector to apply a torque of 4.5 lb-in. (0.5 Nm). See...
-
Page 9: Step 7: Perform The Initial Configuration
You must perform the initial configuration of the TCX1000-ILA through the command-line interface (CLI). The TCX1000-ILA supports two command line modes. When you first log in to the TCX1000-ILA, you are placed into user mode. In user mode, you can issue basic commands such as ping but you do not have access to regular CLI commands. To get access to the regular CLI, you need to log in to the administrative mode from user mode. - Page 10 SSH to connect to the TCX1000-ILA and log in to the user mode with the username (admin) and the password (admin). Make sure your PC is on the same subnet as the TCX1000-ILA IP address. The user mode username and password are used if you are using SSH to connect to the CLI interface.
- Page 11 ) to the DCN to verify the IP address you configured. Use SSH to connect to the TCX1000-ILA and log in with the username (admin) and the configured password. Use the proNX Optical Director to provision, monitor, and activate services on the TCX1000-ILA. See the proNX Optical Director documentation at: https://www.juniper.net/documentation/product/en_US/pronx-optical-director...
-
Page 12: Safety Warnings Summary
Before installing the device, read the planning instructions in the in the TCX1000 Inline Amplifier Hardware Guide to make sure that the site meets power, environmental, and clearance requirements for the TCX1000-ILA. If the rack or cabinet has stabilizing devices, install them in the rack before mounting or servicing the TCX1000-ILA in the rack or cabinet. -
Page 13: Power Cable Warning (Japanese)
TCX1000 Inline Amplifier Quick Start Guide Power Cable Warning (Japanese) The attached power cable is only for this product. Do not use this cable for another product. Contacting Juniper Networks For technical support, see https://www.juniper.net/support/requesting-support.html NEBS Compliance Statements The equipment is suitable for installation as part of the Common Bonding Network (CBN). -
Page 14: United States
For a list of the complete TCX1000 Series documentation including the release notes, see https://www.juniper.net/documentation/ en_US/release-independent/tcx/information-products/pathway-pages/index.html To obtain the most current version of all Juniper Networks technical documentation, see the product documentation page on the Juniper Networks website at https://www.juniper.net/documentation/. - Page 15 Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc. in the United States and other countries. All other trademarks, service marks, registered marks, or registered service marks are the property of their respective owners. Juniper Networks assumes no responsibility for any inaccuracies in this document.
