FlashLogic FLRSGM7 Install Manual page 16

MODULE
A
RF PORT/WEBLINK PORT
G
F TELEMATIC PORT
B
E
C
D
A
MS2 MS2
2 1
4 3
6 5
B
2 1
4 3
6 5
8 7
MS1 MS1
10 9
12 11
14 13
16 15
18 17
20 19
C
01 BROWN/BLACK - PARKING LIGHT (-) OUTPUT
02 GRAY (NC)
03 EMPTY
2 1 04 EMPTY
4 3 05 EMPTY
6 5 06 PURPLE/GREEN - LOCK (-) OUTPUT
8 7 07 EMPTY
08 BLUE/GREEN (NC)
10 9
12 11 09 EMPTY
10 EMPTY
11 GRAY/GREEN - HORN (-) OUTPUT
12 DKGREEN/GREEN - UNLOCK (-) OUTPUT
D
2 1
4 3
04 GRAY/WHITE - HOOD STATUS (-) INPUT
6 5
8 7
WITHOUT OEM HOOD SWITCH:
10 9
INSTALL AND CONNECT TO
AFTERMARKET HOOD SWITCH
U.S. Patent No. 8,856,780
Automotive Data Solutions Inc. © 2017
TYPE 4 - WIRING DIAGRAM - 1 OF 1
GREEN/WHITE - SWC (DATA) OUTPUT
AFTERMARKET HOOD SWITCH (-)
FLC-GM(RS)-GM7-[FLRSGM7]-EN
A1
VS4 VS4
A2
VS3 VS3
B1
VS2 VS2
B2
VS1 VS1
OBDII
SWC (DATA) - 01
OPTIONAL
X2
LOCK (-) - 19
UNLOCK (-) - 15
PAGE 16 OF 26
• 20170705
DOC.: #40640
VEHICLE IGNITION SWITCH
IGNITION CONNECTOR
IGNITION HARNESS
PK3 CONNECTOR
PK3 HARNESS
B1
B2
A1
A2
OBDII CONNECTOR
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
VEHICLE
PARKING LIGHT (-)
HORN (-)
BCM
BLUE
1 2 3 4
5 6 7 8
9 10 11 12 13 14 15
16 17 18 19 20 21
X2
22 23 24 25 26 27
www.flashlogic.com
