FlashLogic FLRSGM7 Install Manual page 11

MODULE
A
RF PORT/WEBLINK PORT
G
F TELEMATIC PORT
B
E
C
D
A
MS2 MS2
2 1
4 3
6 5
B
2 1
4 3
6 5
8 7
MS1 MS1
10 9
12 11
14 13
16 15
18 17
20 19
C
01 BROWN/BLACK - PARKING LIGHT (-) OUTPUT
02 GRAY (NC)
03 EMPTY
2 1 04 EMPTY
4 3 05 EMPTY
6 5 06 PURPLE/GREEN (NC)
8 7 07 EMPTY
08 BLUE/GREEN (NC)
10 9
12 11 09 EMPTY
10 EMPTY
11 GRAY/GREEN - HORN (-) OUTPUT
12 DKGREEN/GREEN (NC)
D
2 1
4 3
04 GRAY/WHITE - HOOD STATUS (-) INPUT
6 5
8 7
WITHOUT OEM HOOD SWITCH:
10 9
INSTALL AND CONNECT TO
AFTERMARKET HOOD SWITCH
U.S. Patent No. 8,856,780
Automotive Data Solutions Inc. © 2017
TYPE 2 - WIRING DIAGRAM - 1 OF 1
VS4 VS4
OR
VS3 VS3
(NC)
GREEN/WHITE - SWC (DATA) OUTPUT
AFTERMARKET HOOD SWITCH (-)
FLC-GM(RS)-GM7-[FLRSGM7]-EN
WITH
ADS-HRN(RS)-GMC07-2
VS5 VS5
JS1 JS1
VS6 VS6
WITHOUT
ADS-HRN(RS)-GMC07-2
CUT CONNECTOR
FROM HARNESS
RED 12V (+) - 04
VS4 VS4
YELLOW MUX - 05
PINK IGNITION (+) - 02
BROWN ACCESSORY (+) - 03
VS2 VS2
VS1 VS1
SWC (DATA) - 01
OPTIONAL
PAGE 11 OF 26
DOC.: #40640
VEHICLE IGNITION SWITCH
A1
IGNITION CONNECTOR
1 2 3 4 5 6
A2
IGNITION HARNESS
A1
B1
B2
A1
A2
B1
PK3 CONNECTOR
B2
PK3 HARNESS
OBDII CONNECTOR
OBDII
1 2 3 4 5 6
9 10 11 12 13 14
PARKING LIGHT (-)
www.flashlogic.com
• 20170705
7 8
15 16
VEHICLE
HORN (-)
