FlashLogic FLRSGM7 Install Manual

Hide thumbs Also See for FLRSGM7:

Advertisement

Quick Links

Download this manual See also: Installation Manual
FLC-GM(RS)-GM7-EN
notice
The manufacturer will accept no responsability for any electrical
damage resulting from improper installation of this product, be that either
damage to the vehicle itself or to the installed device. This device must be in-
stalled by a certified technician. Please review the Installation Guide carefully
before beginning any work.
Automotive Data Solutions Inc. © 2013
instaLL guiDe
Document numbeR
12028
Revision Date
20130911
FiRmwaRe
FLC-GM(RS)-GM7
haRDwaRe
FLRSGM7
accessoRies
FLPROG (REQUIRED)
FLRF2 (REQUIRED)
CARLINK ASCL2 (OPTIONAL)
beFoRe instaLLation
1- Connect module to computer
2- Login to Weblink account
3- Flash firmware to module (module is not preloaded with firmware)
4- Use accessories accordingly (accessories are sold separately)
www.flashlogic.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the FLRSGM7 and is the answer not in the manual?

Questions and answers

Related Manuals for FlashLogic FLRSGM7

Summary of Contents for FlashLogic FLRSGM7

  • Page 1 FLC-GM(RS)-GM7-EN Document numbeR 12028 Revision Date 20130911 FiRmwaRe FLC-GM(RS)-GM7 haRDwaRe FLRSGM7 accessoRies FLPROG (REQUIRED) FLRF2 (REQUIRED) CARLINK ASCL2 (OPTIONAL) notice beFoRe instaLLation The manufacturer will accept no responsability for any electrical damage resulting from improper installation of this product, be that either 1- Connect module to computer damage to the vehicle itself or to the installed device.
  • Page 2 • • Terrain Flip-Key AT 10-13 1 • • • • • • • • • • • • • • * Available only if vehicle is equipped with factory hood switch. Automotive Data Solutions Inc. © 2013 FLC-GM(RS)-GM7-EN www.flashlogic.com...
  • Page 3 Light switch 16 pin 01 Green (DATA) OBDII Trax Parking Light Green/Gray Light switch 16 pin 01 Green (DATA) OBDII Terrain 10-13 Parking Light LtBlue Light switch * Early production. ** Late production. Automotive Data Solutions Inc. © 2013 FLC-GM(RS)-GM7-EN www.flashlogic.com...
  • Page 4 GREEN/WHITE - SWC (DATA) OUTPUT SWC (DATA) - 01 01 BROWN/BLACK - PARKING LIGHT (-) OUTPUT 02 GRAY (NC) 11 GRAY/GREEN - HORN (-) OUTPUT VEHICLE PARKING LIGHT (-) HORN (-) OPTIONAL Automotive Data Solutions Inc. © 2013 FLC-GM(RS)-GM7-EN www.flashlogic.com...
  • Page 5 DOC.: #12028 MODULE VEHICLE 03 GRAY/BLACK (NC) WITHOUT OEM HOOD SWITCH: AFTERMARKET HOOD SWITCH (-) 04 GRAY/WHITE - HOOD STATUS (-) INPUT INSTALL AND CONNECT TO AFTERMARKET HODD SWITCH TELEMATIC RF KIT Automotive Data Solutions Inc. © 2013 FLC-GM(RS)-GM7-EN www.flashlogic.com...
  • Page 6 Turn key to OFF position. Turn key to OFF position. Module Programming Procedure completed. START START Remove key. Remove key. START START LED will turn solid RED. Insert key into ignition. START Automotive Data Solutions Inc. © 2013 FLC-GM(RS)-GM7-EN www.flashlogic.com...
  • Page 7 Turn key to OFF position then to ON position fi ve times [5x] rapidly. START Wait, LED 1 will turn solid RED for 2 seconds. Turn key to OFF position. START Automotive Data Solutions Inc. © 2013 FLC-GM(RS)-GM7-EN www.flashlogic.com...
  • Page 8 Remote PRogRamming - 1 OF 1 • 20130911 DOC.: #12028 aFteRmaRKet Remote PRogRamming: notes I All aftermarket remotes must be programmed to the RF-Kit. Refer to the RF-Kit user guide for aftermarket remote features and programming procedures. Automotive Data Solutions Inc. © 2013 FLC-GM(RS)-GM7-EN www.flashlogic.com...
  • Page 9 Failure to exit the Module Navigation will drain button as many times as the menu number Navigation and redo the Module Navigation vehicle battery. indicates. LED 1 will fl ash GREEN an equal Procedure. amount of times continuously. Automotive Data Solutions Inc. © 2013 FLC-GM(RS)-GM7-EN www.flashlogic.com...
  • Page 10 35 MIN 15 min 02 sec 05 SEC 08 SEC 10 SEC WAIT TO START DELAY 15 SEC 20 SEC 25 SEC 30 SEC *Vehicle will shutdown when a door is opened. Automotive Data Solutions Inc. © 2013 FLC-GM(RS)-GM7-EN www.flashlogic.com...
  • Page 11 HORN EVENT TRIGGER LOCK + UNLOCK + START CONFIGURATION DOUBLE LOCK + START 30 msec HORN CHIRPS WIDTH 15 mSec 60 mSec 02-07 Technical Support only *Vehicle will shutdown when a door is opened. Automotive Data Solutions Inc. © 2013 FLC-GM(RS)-GM7-EN www.flashlogic.com...
  • Page 12 System is in Valet Mode. Vehicle is moving (VSS). Glow plug timeout error. RS not synchronized. Start vehicle with OEM key for 15 sec before trying a new RS sequence. CAN communication failure during RS sequence. Automotive Data Solutions Inc. © 2013 FLC-GM(RS)-GM7-EN www.flashlogic.com...
  • Page 13 Module not programmed. Waiting for more vehicle information. Flashing GREEN False ground when running status from remote starter. WITH IGNITION OFF Solid GREEN then OFF Reset in progress. Module at rest and ready for a remote start sequence. Automotive Data Solutions Inc. © 2013 FLC-GM(RS)-GM7-EN www.flashlogic.com...
  • Page 14 BLACK 20-PIN connector. DTC or a CHECK ENGINE error message. Wait, LED 1 will flash RED. RELEASE programming button. LED 1 will turn RED for 2 seconds. Module RESET completed. Automotive Data Solutions Inc. © 2013 FLC-GM(RS)-GM7-EN www.flashlogic.com...
