EnerSys DataSafe HX Installation, Operation And Maintanance Manual page 4

INTER-UNIT CONNECTOR LAYOUT
TYPICAL LAYOUTS ON STEEL STANDS
SINGLE ROW STAND
Note! End terminal position will depend upon
number of units in row, ie. whether "ODD" or
"EVEN" number
Type Length Width
HX205 8.9 5.5
HX300 10.1 6.9
HX330 11.9 6.9
HX400 13.3 6.8
HX500 13.3 6.8
All measurements are in inches
Global Headquarters
P.O. Box 14145
Reading, PA 19612-4145 USA
Tel: +1-610-208-1991
+1-800-538-3627
Fax: +1-610-372-8613
www.enersysinc.com
DOUBLE ROW STAND
CC RC A B
5.6 9.1 2.1 1.9
6.9 10.3 2.7 2.2
6.9 12.1 2.7 2.5
6.8 13.5 2.6 3.0
6.8 13.5 2.6 3.0
EnerSys EMEA
Brussels, Belgium
Tel: +32 (0)2 247 94 47
EnerSys Asia
Guangdong, China
Tel: +86-755-2689 3639
C 1 2
9.0 866880 HRD2328 866881
11.2 866881 HRD2328 866883
11.2 866882 HRD2327 866883
11.1 866884 HRD2327 866883
11.1 866884 HRD2327 866883
3 4 5
HRD2328 866885 HRD2329
HRD2327 866886 HRD2330
HRD2327 866886 HRD2330
HRD2327 866886 HRD2330
HRD2327 866886 HRD2330
